2004 LINCOLN NAVIGATOR headlamp

Replacing headlamp bulbs
1. Make sure the headlamp control is in the OFF position.
2. Open the hood.
3. At the back of the headlamp lens,
remove the three headlamp
assembly retainers bolts.
4. Pull the headlamp assembly
forward slightly to expose the
electrical connectors.
5. Rotate the bulb covers
counterclockwise and remove.
6. Once the bulb covers are
removed, the bulbs can be removed
by turning them counterclockwise
and then pulling the bulbs straight
out.
Handle a halogen headlamp bulb carefully and keep out of
children ’ s reach. Grasp the bulb only by its plastic base and do
not touch the glass. The oil from your hand could cause the bulb to
break the next time the headlamps are operated.
7. Insert the glass end of the new bulb into the headlamp assembly.
When the grooves in the plastic base are aligned, push the bulb into the
lamp assembly until the plastic base contacts the rear of the lamp
assembly. Turn the bulb counterclockwise to install.
8. Reinstall the bulb cover and secure it in place by turning
counterclockwise.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Lights
105

Replacing HID headlamp bulbs (if equipped)
The low beam headlamps on your vehicle use a “ high intensity discharge ”
source. These lamps operate at a high voltage. The bulb is NOT
replaceable. When the bulb is burned out, the lamp assembly must be
replaced by your dealer or a qualified technician.
Replacing front parking lamp/turn signal bulbs
1. Make sure the headlamp control is in the OFF position.
2. Open the hood.
3. At the back of the headlamp lens,
remove the three headlamp
assembly bolts.
4. Pull the headlamp assembly
forward slightly to expose the
electrical connectors.
5. Rotate the bulb socket
counterclockwise and remove.
6. Pull the bulb straight out of the
socket and push in the new bulb.
7. To complete installation of the
parking lamp/turn signal assembly,
follow the removal procedures in
reverse order.
Replacing foglamp bulbs
Handle a halogen headlamp bulb carefully and keep out of
children ’ s reach. Grasp the bulb only by its plastic base and do
not touch the glass. The oil from your hand could cause the bulb to
break the next time the headlamps are operated.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Lights
106

1. Make sure the headlamp switch is
in the OFF position.
2. Disconnect the electrical
connector from the foglamp bulb.
3. Rotate the foglamp bulb
counterclockwise and remove from
the foglamp (the rear side of the
foglamp is shown).
4. Install the foglamp bulb in
foglamp by rotating clockwise.
5. Connect the electrical connector
to the new foglamp bulb
Replacing tail lamp bulbs
1. Make sure the headlamp switch is
in the OFF position.
2. Open the liftgate to expose the
lamp assembly screws.
3. Remove the two screws from the
lamp assembly.
4. Carefully pry the lamp assembly
away from the vehicle, by pulling
the assembly directly straight out, to
expose the bulb socket. DO NOT
TIP THE LAMP ASSEMBLY SIDEWAYS.
5. Rotate the bulb socket counterclockwise and remove from lamp
assembly.
6. Pull bulb straight out of socket and push in the new bulb.
7. Install the bulb socket into the lamp assembly and rotate clockwise.
8. Install the lamp assembly on the vehicle and secure with two screws.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Lights
107

Replacing back-up lamp bulbs
The back-up lamp bulbs are located behind the liftgate trim panels.
To change the back-up lamp bulbs:
1. Make sure the headlamp switch is
in the OFF position.
2. Remove the liftgate trim panel by
removing the retaining nuts to
expose the bulb socket.
3. Turn the bulb socket
counterclockwise and pull it out of
the back-up lamp assembly.
4. Pull out the old bulb and replace
it by pushing in a new bulb.
5. Push the connector back into the back-up lamp assembly and turn it
clockwise to secure it in place.
6. Reinstall the liftgate trim panel.
Replacing liftgate tail lamp bulb
1. Make sure the headlamp switch is
in the OFF position.
2. Raise the liftgate and remove the
two retaining nuts on the underside
of the liftgate.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Lights
108

Replacing license plate lamp bulb
The license plate bulbs are located in the license plate housing assembly
on the liftgate. To change the license plate bulbs:
1. Make sure the headlamp switch is
in the OFF position.
2. Remove the license lamp screw
from the assembly.
3. Pull the lamp down and twist the
bulb socket counterclockwise.
Remove the bulb socket from the
lamp.
4. Pull out the old bulb and push in
the new bulb.
5. Install the bulb socket in the lamp assembly by turning it clockwise.
6. Install the lamp assembly and secure it with the retaining screw.
Approach lamp/mirror turn signal bulb removal (if equipped)
To change the bulbs:
1. Make sure the headlamp switch is
in the OFF position and then fold
the mirror forward.
2. Remove the torx screw on the
bottom of the turn signal lens using
a T-10 torx driver.
3. Pull the turn signal lens down to
remove it from the mirror assembly
4. Disconnect the bulb assembly
from the lens.
5. Remove and replace the bulb.
6. Reverse the order to reassemble lamp and lens.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Lights
111

Do not sit on top of a buckled safety belt to avoid the Belt
Minder
chime. Sitting on the safety belt will increase the risk
of injury in an accident. To disable (one-time) or deactivate the Belt
Minder
feature please follow the directions stated below.
One time disable
Any time the safety belt is buckled and then unbuckled during an
ignition ON cycle, BeltMinder
will be disabled for that ignition cycle
only.
Deactivating/activating the BeltMinder  feature
Read step s1-9 thoroughly before proceeding with the
deactivation/activation programming procedure.
The BeltMinder
feature can be deactivated/activated by performing the
following procedure:
Before following the procedure, make sure that:
• The parking brake is set
• The gearshift is in P (Park) (automatic transmission)
• The ignition switch is in the OFF position
• All vehicle doors are closed
• The driver ’ s safety belt is unbuckled
• The parklamps/headlamps are in OFF position (If vehicle is equipped
with Autolamps, this will not affect the procedure.)
To reduce the risk of injury, do not deactivate/activate the
BeltMinder
feature while driving the vehicle.
1. Turn the ignition switch to the RUN (or ON) position. (DO NOT
START THE ENGINE)
2. Wait until the safety belt warning light turns off. (Approximately 1 – 2
minutes)
• Steps 3 – 5 must be completed within 60 seconds or the procedure will
have to be repeated.
3. Buckle then unbuckle the safety belt three times, ending with the
safety belt unbuckled. This can be done before or during BeltMinder

warning activation.
4. Turn on the parklamps/headlamps, turn off the parklamps/headlamps.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Seating and Safety Restraints
193

If you smell exhaust fumes inside your vehicle, have your dealer
inspect your vehicle immediately. Do not drive if you smell
exhaust fumes.
Important safety precautions
A computer system controls the engine ’ s idle revolutions per minute
(RPM). When the engine starts, the idle RPM runs higher than normal in
order to warm the engine. If the engine idle speed does not slow down
automatically, have the vehicle checked. Do not allow the vehicle to idle
for more than 10 minutes at the higher engine RPM.
Before starting the vehicle:
1. Make sure all vehicle occupants have buckled their safety belts. For
more information on safety belts and their proper usage, refer to the
Seating and Safety Restraints chapter.
2. Make sure the headlamps and vehicle accessories are off.
3. Make sure the gearshift is in P
(Park).
4. Make sure the parking brake is
set.
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus)Driving
218

Fuse/Relay
Location Fuse Amp
Rating Passenger Compartment Fuse Panel
Description
5 7.5A* Brake On/Off (stoplamp) switch, Powertrain
Control Module (PCM) (keep alive power),
EATC control head, Body Security Module
(BSM) (keep alive power), Speed control
deactivation switch, Speed control servo,
SecuriLock LED, 3rd row seat relay coils,
Power liftgate module, Clock, Brake Shift
Interlock (BSI) solenoid
6 15A* Headlamp switch (parklamps and switch
backlighting feed), Parklamps, License
lamps, Foglamp relay coil, Trailer tow
electric brake controller (illumination), BSM
(autolamp parklamps), Floor console gear
selector lighting, Switch backlighting
module, Foglamp indicator
7 7.5A* Radio (Start signal)
8 10A* Rear window defroster switch, Heated
outside mirrors, Rear window defroster
indicator (climate control head)
9 — Not used
10 20A* Trailer tow back-up lamps relay, Trailer tow
7 – wire connector (back-up lamps), Trailer
tow parklamps relay, Trailer tow 7 – and
4 – wire connectors (parklamps)
11 10A* A/C compressor clutch relay, A/C
compressor clutch solenoid, Air suspension
compressor relay, 4x4 Integrated Wheel
Ends (IWE) solenoid
12 10A* Speed control relay, Speed control servo
2004 Navigator (nav)
Owners Guide (post-2002-fmt)
USA English (fus) Roadside Emergencies
