IN CASE OF AN EMERGENCY
474
Manual emergency calling
You can place an emergency call manually. Open the
cover and push the emergency button. You will hear
Placing an emergency call to Lexus Link Center.º Upon
reception of your call, the Advisor will locate your vehicle
and contact you to assess the situation. If necessary, the
Advisor will alert the nearest emergency service provider.
This emergency call should only be made in
life-threatening situations.If your vehicle is stolen, call the Lexus Link Call Center at
1-800-25-LEXUS (Toll-Free) (1-800-255-3987). The
Center will locate, track and provide location information to the
appropriate police authority. To protect subscriber privacy, the
Lexus Link Call Center will not provide the location of a vehicle
to anyone other than a law enforcement authority.

IN CASE OF AN EMERGENCY
475
NOTICE
This system is only operational in GPS and analog
cellular coverage areas. Upon subscription expiration,
all Lexus Link services (i.e. automatic notification,
emergency call functions, service call functions, door
locking/unlocking function) are deactivated.

IN CASE OF AN EMERGENCY
476
Other Services
When you push the SERVICESº button, you will hear
Calling the Lexus Link Centerº. When the Advisor
receives your location and ID from the system, the Advisor
provides you with the service. The services provided will
depend on the level of service package selected.
For details about various services that are available, contact
your Lexus dealer, or push the SERVICESº button and speak
to the Lexus Link Advisor, or you may dial toll free 1-800-25
Lexus (Toll-Free) (1-800-255-3987) and select the option for
Lexus Link.
To cancel a services call, push the SERVICESº button a
second time. Lexus Link call cancelledº will be announced.If any problem concerning the Lexus Link System occurs
during driving, the system will announce A Lexus Link System
error has been detected. Please contact your Lexus dealer.º
If you hear this message, take your vehicle to your Lexus
dealer.
Lexus Link services may not be available if:
The components or wire harnesses for the system are
damaged;
The Lexus Link Call Center is not operational;
The antenna does not work properly due to vehicle damage;
In a weak or non-analog cellular coverage area;
In area where the GPS signal is weak or cannot be received;

IN CASE OF AN EMERGENCY
477 The Lexus Link subscription has expired.
NOTICE
Upon subscription expiration, all Lexus Link services
(i.e. automatic notification, emergency call functions,
service call functions) are deactivated.

IN CASE OF AN EMERGENCY
478
Door Locking/Unlocking by Lexus Link
System
The Lexus Link System will allow your vehicle to be locked
and unlocked remotely.
If you find that your vehicle has not been locked, call the Lexus
Link Call Center 1-800-25-LEXUS (Toll-Free)
(1-800-255-3987), the Lexus Link Advisor can assist in
locking your vehicle.In case you are locked out, call the Lexus Link Call Center
1-800-25 Lexus (Toll-Free) (1-800-255-3987), a Lexus Link
Advisor can assist in unlocking your vehicle.
NOTICE
You must provide the Lexus Link operator with your
Lexus Link PIN (Personal Identification Number) or
personal security word, before they lock/unlock your
vehicle. However, the Lexus Link System will not be
able to lock or unlock your vehicle if it has been parked
for 48 hours or more after the ignition is turned off.
Upon subscription expiration, all Lexus Link services
(i.e. automatic notification, emergency call functions,
service call functions, door locking/unlocking function)
are deactivated.

IN CASE OF AN EMERGENCY
479
Memo record

1RECº button2PLAYº button
3- VOL +º button
During a service call, you can record a conversation with the
Lexus Link Call Center Advisor. This function is very
convenient for drivers so they do not have to take notes while
driving.
RECº button: Push this button to record information or a
conversation with Lexus Link Call Center. To stop recording,
push the button again. Up to 5 minutes of recording time is
available.
When you push the RECº button, all previous messages are
deleted and the system begins recording your new message.At the start of recording, Recordingº will be announced. At the
end of recording, you will hear Recording completeº. If there
are only 15 seconds left for recording, two chimes sound. If the
recording memory is full, Recording time exceededº will be
announced and recording will be terminated.
If you push this button while you are hearing a playback of
recording, it terminates the playback and recording will start.
At this time, the previous recording will be erased.
PLAYº button: Push this button to play the recorded
conversation. Playback Completeº is announced when the
playback is complete. To stop the operation, push the button
again. Playback Cancelledº is announced. The volume has
a total of eight positions/levels available.
- VOL +º button: Push this button on either side to adjust the
volume. When you change the volume, one chime sounds.

IN CASE OF AN EMERGENCY
480

IN CASE OF AN EMERGENCY
481
Audible voice prompts
The following table shows the voice responses from the Lexus Link System.
Voice phrase: Explanation about Lexus Link System
This is the Lexus Link system. Integrating
global positioning satellite and wireless
communication technology into your
Lexus and providing enhanced safety,
security, and convenience. At the touch of
a button, or automatically in the event of
an accident, you are connected to a Lexus
Link Advisor who will assist you Ð 24
hours a day, 7 days a week where GPS
and cellular coverage is available. The
Lexus Link System also has an audio
recorder allowing you to record reminders
to yourself or information from a Lexus
Link Advisor.
To contact a Lexus Link Advisor, press the
SERVICESº button. The Lexus Link
System will inform the advisor of your
vehicle's current location and your
identity. The advisors can handle a wide
variety of services, such as giving
directions to shops, gas stations, ATMs,
restaurants and roadside assistance with
location. Services available will depend
on the service package you selected.In an emergency, press the emergency
services button on your Lexus Link
console. It is marked with a red
ambulance. Upon receiving your call, the
advisor will assess the situation and, if
necessary, alert the nearest emergency
services provider. The emergency button
should only be used in life threatening
situations.
If your Lexus detects that an airbag
deployment may have occurred, the
Lexus Link System will automatically send
an emergency message to the Lexus Link
Call Center.
The system will also automatically contact
the call center if the security system alarm
goes off. An advisor will first contact you
to determine if the alarm is valid. Upon
your confirmation, the advisor will then
provide the vehicle location to the police.If you accidentally set off the alarm, press
the remote door unlock, or insert your key
in the door lock or ignition within 55
seconds. This will prevent the Lexus Link
System from placing a theft call.
The volume control lets you adjust the
volume level for Lexus Link calls, system
prompts, and memos. Press the plus key
to increase volume and the minus key to
decrease it.
To record a memo or a call, press the key
labeled RECº. When you are finished
recording, press the RECº button again.
To listen to the memo, press the PLAYº
button. You can record one message up
to five minutes long. When you record a
new memo, all of the previous memos will
be erased.
For more detailed information on the use,
features and limitations of this system,
please consult your Lexus Link Owner's
Manual.
