GW-18
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
Rear Door (LH or RH) / With Front Power Window Anti-pinch System
REAR POWER WINDOW SWITCH (LH OR RH) OPERATION
WINDOW UP
When the rear power window switch (LH or RH) is pressed in the up position
Power is supplied

through rear power window switch (LH or RH) terminal 5

to rear power window motor (LH or RH) terminal 2.
Ground is supplied

to rear power window motor (LH or RH) terminal 1

through rear power window switch (LH or RH) terminal 4

through rear power window switch (LH or RH) terminal 3

through power window main switch terminal 3 (LH) or 5 (RH).
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the rear power window switch (LH or RH) is pressed in the down position
Power is supplied

through rear power window switch (LH or RH) terminal 4

to rear power window motor (LH or RH) terminal 1.
Ground is supplied

to rear power window motor (LH or RH) terminal 2

through rear power window switch (LH or RH) terminal 5

through rear power window switch (LH or RH) terminal 2

through power window main switch terminal 1 (LH) or 7 (RH).
Then, the motor lowers the window until the switch is released.
POWER WINDOW MAIN SWITCH OPERATION
WINDOW UP
When the rear LH or RH switch in the power window main switch is pressed in the up position
Power is supplied

through power window main switch terminal 1 (LH) or 7 (RH)

to rear power window switch (LH or RH) terminal 2

to rear power window switch (LH or RH) terminal 5

to rear power window motor (LH or RH) terminal 2.
Ground is supplied

to rear power window motor (LH or RH) terminal 1

through rear power window switch (LH or RH) terminal 4

through rear power window switch (LH or RH) terminal 3

through power window main switch terminal 3 (LH) or 5 (RH)
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the rear LH or RH switch in the power window main switch is pressed in the down position
Power is supplied

through power window main switch terminal 3 (LH) or 5 (RH)

through rear power window switch (LH or RH) terminal 3

through rear power window switch (LH or RH) terminal 4

to rear power window motor (LH or RH) terminal 1.
Ground is supplied

to rear power window motor (LH or RH) terminal 2

through rear power window switch (LH or RH) terminal 5

through rear power window switch (LH or RH) terminal 2

to power window main switch terminal 1 (LH) or 7 (RH)
Then, the motor raises the window until the switch is released.

POWER WINDOW SYSTEM
GW-19
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Rear Door (LH or RH) / With Front and Rear Power Window Anti-pinch System
REAR POWER WINDOW SWITCH (LH OR RH) OPERATION
WINDOW UP
When the rear power window switch (LH or RH) is pressed in the up position
Power is supplied

through rear power window switch (LH or RH) terminal 8

to rear power window motor (LH or RH) terminal 3.
Ground is supplied

to rear power window motor (LH or RH) terminal 1

through rear power window switch (LH or RH) terminal 9.
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the rear power window switch (LH or RH) is pressed in the down position
Power is supplied

through rear power window switch (LH or RH) terminal 9

to rear power window motor (LH or RH) terminal 1.
Ground is supplied

to rear power window motor (LH or RH) terminal 3

through rear power window switch (LH or RH) terminal 8.
Then, the motor lowers the window until the switch is released.
POWER WINDOW MAIN SWITCH OPERATION
Signal is sent

to rear power window switch (LH or RH) terminal 16

though power window main switch terminal 14.
The operation of power window after receive the signal is as same as operate the rear power window switch
(LH or RH).
AUTO OPERATION
The power window AUTO feature enables the driver to open or close the window without holding the window
switch in the down or up position.
Two types of auto operation system are applied to model S50.
The one is applied only for front doors and the other is for all doors.

GW-20
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
POWER WINDOW SERIAL LINK
With Front Power Window Anti-pinch System
Power window main switch, front power window switch (passenger side), and BCM transmit and receive the
signal by power window serial link.
The under mentioned signal is transmitted from BCM to power window main switch and front power window
switch (passenger side)

Keyless power window down signal.
The under mentioned signal is transmitted from power window main switch to front power window switch (pas-
senger side)

Front passenger side door window operation signal.

Power window control by key cylinder switch signal.

Power window lock signal.

Retained power operation signal.
With Front and Rear Power Window Anti-pinch System
Power window main switch, front power window switch (passenger side), rear power window switches and
BCM transmit and receive the signal by power window serial link.
The under mentioned signal is transmitted from BCM to power window main switch and front power window
switch (passenger side).

Keyless power window down signal.
The under mentioned signal is transmitted from power window main switch to front power window switch (pas-
senger side)

Front passenger side door window operation signal.

Power window control by key cylinder switch signal.

Power window lock signal.

Retained power operation signal.
The under mentioned signal is transmitted from power window main switch to rear power window switch (LH
or RH)

Rear LH or RH side door window operation signal.

Power window lock signal.

Retained power operation signal.
POWER WINDOW LOCK
With Front Power Window Anti-pinch System
The power window lock is designed to lock operation of all windows except for driver side door window.
When the lock position, ground of the rear power window switches in the power window main switch is discon-
nected. The power window lock signal is transmitted to front power window switch (passenger side) by power
window serial link. This prevents the power window motors from operating.
With Front and Rear Power Window Anti-pinch System
The power window lock is designed to lock operation of all windows except for driver side door window.
When the lock position, the power window lock signal is transmitted to front power window switch (passenger
side) and rear power window switches by power window serial link. This prevents the power window motors
from operating.

POWER WINDOW SYSTEM
GW-21
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
RETAINED POWER OPERATION
When the ignition switch is turned to the OFF position from ON or START position.
Power is supplied for 45 seconds / with front power window anti-pinch system

through BCM terminal 53

to power window main switch terminal 10

to rear power window switch (LH and RH) terminals 1.
Power is supplied for 45 seconds / with front and rear power window anti-pinch system

through BCM terminal 53

to power window main switch terminal 10.
When power and ground are supplied, the BCM continues to be energized, and the power window can be
operated.
The retained power operation is canceled when the driver or passenger side door is opened.
RAP signal period can be changed by CONSULT-II. Refer to GW-40, "
CONSULT-II Inspection Procedure" .
ANTI-PINCH SYSTEM
With front power window anti-pinch system
Power window main switch and front power window switch (passenger side) monitors the power window motor
operation and the power window position (full closed or other) for driver side and passenger side power win-
dow by the signals from encoder and limit switch in front power window motor (driver side and passenger
side).
When power window main switch detects interruption during the following close operation,

automatic close operation when ignition switch is in the “ON” position

automatic close operation during retained power operation

manual close operation during retained power operation
power window main switch or front power window switch (passenger side) controls each power window motor
for open and the power window will be lowered about 150 mm (5.91 in).
With front and rear power window anti-pinch system
Power window main switch and each power window switch monitors the power window motor operation and
the power window position (full closed or other) for each power window by the signals from encoder and limit
switch in power window motor.
When power window switch detects interruption during the following close operation,

automatic close operation when ignition switch is in the “ON” position

automatic close operation during retained power operation

manual close operation during retained power operation
Power window main switch or each power window switch controls each power window motor for open and the
power window will be lowered about 150 mm (5.91 in).
POWER WINDOW CONTROL BY THE KEY CYLINDER SWITCH
When ignition key switch is OFF, front power window can be opened or closed by turning the key cylinder
switch UNLOCK / LOCK position more than 1.5 second over condition.

Power window can be opened as the door key cylinder is kept fully turning to the UNLOCK position.

Power window can be closed as the door key cylinder is kept fully turning to the LOCK position.
The power window DOWN stops when the following operations are carried out.

While performing open / close the window, power window is stopped at the position as the door key cylin-
der is placed on NEUTRAL.

When the ignition switch is turned ON while the power window DOWN is operated.

POWER WINDOW SYSTEM
GW-29
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Terminal and Reference Value for Power Window Main Switch / With Front
Power Window Anti-pinch System
AIS004Q3
Terminal Wire color Item ConditionVoltage [V]
(Approx.)
1YRear LH power window
UP signalWhen rear LH switch in
power window main switch is
UP at operated.Battery voltage
2 SB Limit switch and encoder ground — 0
3RRear LH power window
DOWN signalWhen rear LH switch in
power window main switch is
DOWN at operated.Battery voltage
4PDoor key cylinder switch
LOCK signalKey position
(Neutral → Locked)5 → 0
5GRear RH power window
DOWN signalWhen rear RH switch in
power window main switch is
DOWN at operated. Battery voltage
6ORDoor key cylinder switch
UNLOCK signalKey position
(Neutral → Unlocked)5 → 0
7LGRear RH power window
UP signalWhen rear RH switch in
power window main switch is
UP at operated. Battery voltage
8LFront driver side
power window motor UP signalWhen front LH switch in
power window main switch is
UP at operated Battery voltage
9 GY Limit switch signalDriver side door window is
between fully-open and just
before fully-closed position (ON)0
Driver side door window is
between just before fully-closed
position and fully-closed position
(OFF)5
10 BR Rap signalIGN SW ON Battery voltage
Within 45 second after ignition
switch is turned to OFFBattery voltage
When driver side or passenger
side door open in power window
timer is operates0
11 BFront driver side
power window motor DOWN signalWhen front LH switch in
power window main switch is
DOWN at operated Battery voltage
13 PU Encoder pulse signalWhen power window motor oper-
ates.
14 Y Power window serial linkIGN SW ON or power window
timer operating.
15 W Encoder power supplyWhen ignition switch ON or
power window timer operates10
OCC3383D
PIIA2344J

POWER WINDOW SYSTEM
GW-31
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Schematic (With Front and Rear Power Window Anti-pinch System)AIS004Q5
TIWH0055E

GW-32
POWER WINDOW SYSTEM
Revision: 2004 November 2004 FX35/FX45
Wiring Diagram —WINDOW— (With Front and Rear Power Window Anti-pinch
System)
AIS004Q6
TIWH0056E

POWER WINDOW SYSTEM
GW-37
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Terminal and Reference Value for BCM / With Front and Rear Power Window
Anti-pinch
AIS004Q7
Terminal Wire color Item ConditionVoltage [V]
(Approx.)
12 P/BFront door switch
passenger side signalON (Open) 0
OFF (Close) Battery voltage
22 OR Power window serial linkIGN SW ON or power window
timer operating.
38 W/L Ignition switch (ON or START) Ignition switch
(ON or START position)Battery voltage
39 L CAN - H — 0
40 R CAN - L — 0
42 L/R Battery power supply — Battery voltage
49 B Ground (signal) — 0
52 B Ground (power) — 0
53 Y/B Rap signalIGN SW ON Battery voltage
Within 45 second after ignition
switch is turned to OFFBattery voltage
When driver side or passenger
side door is open in power win-
dow timer is operates0
54 W Power window power supply — Battery voltage
55 G Battery power supply — Battery voltage
62 WFront door switch
driver side signalON (Open) 0
OFF (Close) Battery voltage
PIIA2344J
