2004 INFINITI FX35 Power steering switch

PRECAUTIONS
BL-5
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
AIS004L9
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectAIS005WT
NOTE:

This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).

Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.

Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
Precautions for WorkAIS004LA

After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check
their operation.

Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

BL-88
INTELLIGENT KEY SYSTEM
Revision: 2004 November 2004 FX35/FX45

When door lock/unlock is performed using Intelligent Key remote controller button operation, operation
confirmation is conducted by making hazard lamps flash and Intelligent Key warning buzzer sound.
OPERATION CONDITION
Door lock/unlock operation is necessary for all doors close.
Map Lamp And Keyhole Illumination Function
When the following conditions come:

condition of map lamp switch is DOOR position;

door switch OFF (when all the doors are closed);
Remote control button of Intelligent Key turns on interior lamp (for 30 seconds) with input of UNLOCK signal
from Intelligent Key.
Panic Alarm Function
When key switch is OFF and ignition knob is not pushed (when mechanical key is not inserted in ignition
knob), BCM turns ON and OFF horn and headlamp intermittently with input of PANIC ALARM signal from
Intelligent Key. The alarm automatically turns off after 25 seconds or when Intelligent Key unit receives any
signal from Intelligent Key.
Panic alarm operation mode can be changed using “WORK SUPPORT” mode in “PANIC ALARM DELAY”.
Refer to BL-115, "
WORK SUPPORT" .
Remote Control Power Window Down (open) Operation
When Intelligent Key unlock switch is turned ON with ignition switch OFF, and Intelligent Key unlock switch is
detected to be on continuously for 3 seconds, the driver's door and passenger's door power windows are
simultaneously opened.
Power window is operated to open and the operation continues as long as the Intelligent Key unlock switch is
pressed.
Remote control power window down operation mode can be changed using “P/W DOWN DELAY” mode in
“WORK SUPPORT”. Refer to BL-115, "
WORK SUPPORT" .
Key Reminder Function
As an operation verification function, when doors are locked or unlocked using Intelligent Key remote control-
ler button operation, hazard lamps flash and horn sounds.
ENGINE STARTUP FUNCTION
Operation Description

When ignition knob is pressed, Intelligent Key unit sends request signal from inside key antenna, key-ID
verification is conducted with Intelligent Key using two-way communication, and if verification is success-
ful, an ignition rotation prohibition latch release signal is sent to steering lock unit. Steering lock unit
releases ignition knob rotation prohibition latch. (Ignition knob can now be turned.)

When it becomes possible to rotate the ignition knob, “KEY” warning lamp in combination meter lights up
green to notify driver that ignition knob can be turned.
NOTE:
When it becomes impossible to rotate the ignition knob, “KEY” warning lamp in combination meter lights
up red.

When key-ID verification is successful and ignition knob switch is in the ON state, Intelligent Key unit uses
CAN communication to send engine start permission signal to BCM.

When BCM receives engine start permission signal, it uses CAN communication to sent starter request
signal to IPDM E/R so that the engine will start when ignition knob is rotated to START position.
Operation Range
Engine can be started when Intelligent Key is in the vehicle. However, sometimes engine might not start when
Intelligent Key is on instrument panel, rear parcel shelf, or in glove box.
NOTE:
luggage room can enable detection of Intelligent Key by a CONSULT-II function. Refer to BL-115, "
WORK
SUPPORT" .
Vehicle operation Hazard lamp Horn
Door unlocking operation Once —
Door locking operation Twice Once

INTELLIGENT KEY SYSTEM
BL-109
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for INTELLIGENT KEY UNITAIS004N0
Te r -
minal
No.Wire
colorItemMeasuring condition
Standard (V)
Approx. Ignition knob
positionOperation or conditions
1R/WSteering lock unit power
supplyLOCK — 5
2 L CAN-H — — —
3 R CAN-L — — —
4LGIntelligent Key warning
buzzerLOCKOperate remote con-
troller button or door
request switch.Buzzer OFF Battery voltage
Sound buzzer 0
5W/LDoor request switch
(driver side)—Door request switch operation: Press
(ON).0
Other than the above (OFF) 5
6 G/R Ignition power supply ON or START — Battery voltage
7 B/W key switch LOCKInsert mechanical key into ignition key
cylinder.Battery voltage
Remove mechanical key from ignition
key cylinder.0
10 LG/R ACC power supply ACC or ON — Battery voltage
11 L/R Battery power supply — — Battery voltage
12 B GND — — 0
13 YInside key antenna (+)
(Luggage room)
LOCKAny door open → all doors shut
(Door switch: ON → OFF)
14 BRInside key antenna (-)
(Luggage room)
15 W/RInside key antenna (+)
signal
(Dashboard)
LOCKAny door open → Close (Door switch:
ON → OFF)
Ignition knob switch: ON (press ignition
knob.)
16 B/RInside key antenna (-)
signal
(Dashboard)
17 OR/L Back door antenna (+)
LOCKBack door request switch operation
(Switch: ON)
18 PU/R Back door antenna (-)
19 SB Outside antenna LH (+)
LOCKDriver door request signal operation
(Switch: ON)
20 R/G Outside antenna LH (-)
25 W/RDoor request switch
(passenger side)—Door request switch operation: Press
(ON)0
Other than the above (OFF) 5
SIIA1910J
SIIA1910J
SIIA1910J
SIIA1910J

INTELLIGENT KEY SYSTEM
BL-111
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for Steering Lock unitAIS004N1
Terminals and Reference Value for BCMAIS004N2
Terminal
numberWire
colorSignal DesignationMeasuring condition
Standard (V)
Ignition knob
positionOperation or conditions
1 L/R Battery power supply LOCK — Approx. 12
2R/WSteering lock unit
power supplyLOCK — Approx. 5
3R/BSteering lock unit com-
munication signalLOCKPress ignition knob with Intelligent
Key inside vehicle.
Other than the above Approx. 5
4Y/BSteering lock unit
ground—— Approx. 0
SIIA1911J
TERMI-
NALWIRE
COLORITEM CONDITIONVOLTAGE (V)
Approx.
1PUKey ring illumination output sig-
nal Key ring illumination is lighting. Battery voltage
Key ring illumination is being turned off. 0
12 P/BFront door switch (Passenger
side)Door open (ON) → Close (OFF) 0 → Battery voltage
13 P/L Rear door switch RH Door open (ON) → Close (OFF) 0 → Battery voltage
37 B/W Key switchInsert mechanical key from ignition key
sylinder.Battery voltage
Remove mechanical key from ignition
key cylinder.0
38 W/L Ignition switchIgnition switch is in ON or START posi-
tionBattery voltage
39 L CAN-H — —
40 R CAN-L — —
41 R/B Battery saver output signal30 minutes after ignition switch is turned
to OFF0
Ignition switch is in ON position Battery voltage
42 L/R Battery power supply (fuse) — Battery voltage
44 YDriver door lock actuator
(Unlock)Door lock / unlock switch
(Free → Unlock)0 → Battery voltage
45 G/W Left turn signal lampWhen door lock or unlock is operated
using Intelligent Key.*
1
(ON → OFF)Battery voltage → 0
46 BR/W Right turn signal lampWhen door lock or unlock is operated
using Intelligent Key.*
1
(ON → OFF)Battery voltage → 0
47 Y/R Step lamp output signalStep lamp is lighting. 0
Step lamp is being turned off. Battery voltage
48 PU/W Room lamp output signalRoom lamp is lighting.*
20
Room lamp is being turned off.*
2Battery voltage
49 B Ground — 0

BL-120
INTELLIGENT KEY SYSTEM
Revision: 2004 November 2004 FX35/FX45
ENGINE START FUNCTION MALFUNCTION
Intelligent Key Operation Inspection
Mechanical Key Operation Inspection
WARNING CHIME FUNCTION MALFUNCTION
Before conducting the diagnosis in the following table, check “key reminder function” with power door lock sys-
tem.
Symptom Diagnoses service procedure Refer to page
Ignition knob can not turn
KEY warning lamp on combination meter
lights up in red when ignition knob is
pressed. (door lock functions normal)1. Intelligent Key inspectionBL-147
2. Check inside key antennaBL-138
3. Replace Intelligent Key unitBL-146
KEY warning lamp on combination meter
lights up in green when ignition knob is
pressed.1. Check ignition knob switchBL-1272. Check steering lock unitBL-139
3. Check Intelligent Key unit power supply and ground circuitBL-124
4. Replace Intelligent Key unitBL-146
Ignition knob turns even without both Intelli-
gent Key and mechanical key.Replace steering lock unit —
Security indicator will still flash when igni-
tion knob is pressed.1. Check key switch (Intelligent Key unit input)BL-124
2. Replace Intelligent Key unitBL-146
Security indicator does not flash with igni-
tion knob released at LOCK position. (push
switch OFF)1. CAN communication systemBL-123
2. Ignition knob switch systemBL-127
3. Intelligent Key unit power supply and ground circuitBL-124
Starter motor does not cranking.
(Ignition knob can turn)1. Check detention switchBL-1422. Check stop lamp switchBL-141
3. Replace Intelligent Key unitBL-146
Symptom Diagnoses service procedure Refer to page
Ignition knob can not turn
Security indicator remains flashing with
mechanical key inserted.1. Check key switch (BCM input)BL-126
2. Replace Intelligent Key unitBL-146
KEY indicator and security indicator does
not flashing with mechanical key inserted.1. Check stop lamp switchBL-141
2. Replace Intelligent Key unitBL-146
Starter motor does not cranking.
(Ignition knob can turn)1. Check detention switchBL-1422. Check stop lamp switchBL-141
3. Replace Intelligent Key unitBL-146
Symptom Diagnoses service procedure Refer to page
Ignition key warning chime is inoperative.
(When mechanical key used)1. Check CAN communicationBL-123
2. Check key switch (Intelligent Key unit input)BL-124
3. Check door switchBL-128
4. Inspect combination meter (warning)DI-4
5. Replace Intelligent Key unitBL-146
Ignition knob OFF position warning
chime (for inside vehicle) does not
sound.
(Ignition key warning chime operates)1. Check CAN communicationBL-1232. Check ignition knob switchBL-127
3. Check key switch (Intelligent Key unit input)BL-124
4. Replace Intelligent Key unitBL-146

INTELLIGENT KEY SYSTEM
BL-141
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2004 November 2004 FX35/FX45
4. STEERING LOCK UNIT COMMUNICATION CIRCUIT INSPECTION
1. Disconnect Intelligent Key unit and steering lock unit connectors.
2. Check continuity between Intelligent Key unit connector M34 terminals 1, 31, 32 and steering lock unit
connector M26 terminals 2, 3, 4.
3. Check continuity between steering lock unit connector M26 ter-
minals 2, 3, 4 and ground.
OK or NG
OK >> Replace steering lock unit.

After replacing steering lock unit, perform registration procedure. Refer to “CONSULT-II Opera-
tion Manual NATS-IVIS/NVIS”.
NG >> Repair or replace harness between steering lock unit and Intelligent Key unit.
Check Stop Lamp SwitchAIS004NM
1. STOP LAMP SWITCH POWER SUPPLY CIRCUIT INSPECTION
1. Disconnect stop lamp switch connector.
2. Check voltage between stop lamp switch connector E210 termi-
nal 1 (GY) and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace harness between stop lamp switch
and fuse.
2. STOP LAMP SWITCH OPERATION INSPECTION
Check continuity between stop lamp switch connector E210 terminal
1 and 2.
OK or NG
OK >> GO TO 3.
NG >> Replace stop lamp switch.1 (R/W) - 2 (R/W) : Continuity should exist.
31 (Y/B) - 4 (Y/B) : Continuity should exist.
32 (R/B) - 3 (R/B) : Continuity should exist.
2 (R/W) - Ground : Continuity should not exist.
3 (R/B) - Ground : Continuity should not exist.
4 (Y/B) - Ground : Continuity should not exist.
PIIA6799E
1 (GY) - Ground : Battery voltage
PIIA6811E
1 - 2
Brake pedal depressed : Continuity should exist.
Brake pedal not
depressed: Continuity should not exist.
PIIA6800E

BL-212
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for Steering Lock Unit/with Intelligent Key Sys-
tem
AIS004PF
Terminals and Reference Value for Intelligent Key Unit/with Intelligent Key Sys-
tem
AIS004PG
Te r -
minal
No.Wire
colorSignal DesignationMeasuring condition
Voltage (V)
Approx. Ignition knob
positionOperation or conditions
1 L/R Battery power supply LOCK — Battery voltage
2R/WSteering lock unit
power supplyLOCK — 5
3R/BSteering lock unit com-
munication signalLOCKPress ignition knob with Intelligent Key
inside vehicle.
Other than the above 5
4Y/BSteering lock unit
ground—— 0
SIIA1911J
Te r -
minal
No.Wire
colorSignal designationMeasuring condition
Voltage (V)
Approx. Ignition knob
positionOperation or conditions
1R/WSteering lock unit
power supplyLOCK — 5
2 L CAN communication H — — —
3 R CAN communication L — — —
6 G/R Ignition power supply ON — Battery voltage
7 B/W Key switch LOCKInsert mechanical key into ignition key
cylinder.Battery voltage
Remove mechanical key from ignition
key cylinder.0
11 L/R Battery power supply — — Battery voltage
12 B GND — — 0
27 L/W Ignition knob switch —Press ignition knob. Battery voltage
Return ignition knob to LOCK position. 0
31 Y/BSteering lock unit
ground—— 0
32 R/BSteering lock unit com-
munication signalLOCKPress ignition knob with Intelligent Key
inside vehicle.
Other than the above 5
SIIA1911J

BRC-1
BRAKE CONTROL SYSTEM
F BRAKES
CONTENTS
C
D
E
G
H
I
J
K
L
M
SECTION BRC
A
B
BRC
Revision: 2004 November 2004 FX35/FX45
BRAKE CONTROL SYSTEM
VDC/TCS/ABS
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Brake System .................................. 3
Precautions for Brake Control .................................. 3
PREPARATION ........................................................... 5
Special Service Tools ............................................... 5
Commercial Service Tools ........................................ 5
ON-VEHICLE SERVICE ............................................. 6
Adjustment of Steering Angle Sensor Neutral Posi-
tion ........................................................................... 6
Calibration of Decel G-sensor (AWD Model) ............ 6
SYSTEM DESCRIPTION ............................................ 8
System Diagram ....................................................... 8
VDC Function ........................................................... 8
TCS Function ........................................................... 8
ABS Function ........................................................... 8
EBD Function ........................................................... 9
Fail-Safe Function .................................................... 9
VDC / TCS SYSTEM ............................................. 9
ABS, EBD SYSTEM .............................................. 9
Hydraulic Circuit Diagram ...................................... 10
CAN COMMUNICATION ...........................................11
System Description ................................................. 11
TROUBLE DIAGNOSIS ............................................ 12
How to Proceed With Diagnosis ............................. 12
BASIC CONCEPT ............................................... 12
DIAGNOSIS FLOWCHART ................................ 13
ASKING COMPLAINTS ...................................... 14
EXAMPLE OF DIAGNOSIS SHEET ................... 14
Component Installation Location ............................ 15
Schematic .............................................................. 16
Wiring Diagram — VDC — ..................................... 17
Control Unit Input/Output Signal Standard ............. 23
REFERENCE VALUE FROM CONSULT-II ......... 23
CONSULT-II Functions ........................................... 25
CONSULT-II MAIN FUNCTION ........................... 25
CONSULT-II BASIC OPERATION PROCEDURE ... 26
SELF-DIAGNOSIS .............................................. 27
DATA MONITOR ................................................. 30
ACTIVE TEST ..................................................... 33
For Fast and Accurate Diagnosis ........................... 35
PRECAUTIONS FOR DIAGNOSIS ..................... 35
Basic Inspection ..................................................... 36
BASIC INSPECTION 1: BRAKE FLUID
AMOUNT, LEAKS, AND BRAKE PADS INSPEC-
TION .................................................................... 36
BASIC INSPECTION 2: POWER SYSTEM TER-
MINAL LOOSENESS AND BATTERY INSPEC-
TION .................................................................... 36
BASIC INSPECTION 3: ABS WARNING LAMP,
VDC OFF INDICATOR LAMP, SLIP INDICATOR
LAMP AND BRAKE WARNING LAMP INSPEC-
TION .................................................................... 37
Inspection 1: Wheel Sensor System ....................... 37
Inspection 2: Engine System .................................. 39
Inspection 3: VDC/TCS/ABS Control Unit System ... 40
Inspection 4: Pressure Sensor System .................. 40
Inspection 5: Steering Angle Sensor System ......... 42
Inspection 6: Yaw Rate/Side G-Sensor (2WD
model), Yaw Rate/Side/Decel G-sensor (AWD mod-
els) System ............................................................. 44
Inspection 7: Solenoid and VDC Change-Over
Valve System .......................................................... 46
Inspection 8: Actuator Motor System ...................... 47
Inspection 9: ABS Actuator and Electric Unit (Con-
trol Unit) Power Supply and Ground System .......... 48
Inspection 10: Stop Lamp Switch System .............. 50
Inspection 11: Brake Fluid Level Switch System .... 51
Inspection 12: When “ST ANG SEN SIGNAL”
Appears on Self-Diagnosis Results Display ........... 52
Inspection 13: When “DECEL G SEN SET” Appears
on Self-Diagnosis Results Display (AWD Model) ... 52
Inspection 14: CAN Communication System .......... 53
Component Inspection ............................................ 53
VDC OFF SWITCH ............................................. 53
Symptom 1: Excessive ABS Function Operation
