2004 Hyundai Coupe child seat

FEATURES OF YOUR HYUNDAI 1- 3
B040A02Y-AAT DOOR LOCKS WARNING:
o Unlocked doors can be dangerous. Be-
fore you drive away (especially if there are children in the car), be sure that all thedoors are securely closed and locked sothat the doors cannot be inadvertentlyopened from the inside. This helps ensurethat the doors will not be opened acciden- tally. Also, when combined with the proper use of seat belts, locking the doors helpskeep occupants from being ejected fromthe car in case of an accident.
o Before opening the door, always look for and avoid oncoming traffic.
o In case of accident, the door is unlocked automatically (If installed).
B880C02A-GAT Key Numbers
AX10030A-1
The vehicle key number is recorded upon a metal tag attached to the keys when the vehicleis first delivered to you.The key number should be recorded and kept ina safe place in case the need to order furtherkeys arises. New keys are available from anyHyundai dealer by quoting the relevant key num-ber.In the interest of security, the metal tag attachedto the keys which bears the key number shouldbe removed from the key ring after you receiveyour new vehicle. In addition, key numbers can-not be provided by Hyundai for security reasons.If you need additional keys or if you should loseyour keys, your authorized Hyundai dealer canmake new keys. B880D01GK-GAT Limp Home Procedures In case the immobilizer system is out of order, you cannot start the engine without the limphome procedures with ignition key.The following procedure is how to start the en-gine with the function of the limp home. (0, 1, 2,3 as a sample password). NOTE: You can get the limp home password whenthe vehicle is first delivered to you. If you donot have the password, consult your autho-rized Hyundai dealer.
1. To set the password, you may turn the ignition
key "ON" and then turn it "OFF" according to the digit numbers. For example, turn the igni- tion key once for digit number "1", and twice for "2", and so on. However, for the digitnumber "0", you must turn the ignition key for10 times.
2. Wait for 3~10 seconds.
3. You may set the remaining number of digits by following the same procedures 1 and 2.
4. If all of four digits have been tried success- fully, from this time, you have to start yourengine within 30 seconds. If you start yourengine after 30 seconds, your engine will notstart.
After doing the limp home procedure, you have toconsult with your authorized Hyundai dealer assoon as possible.
CAUTION: If you cannot start your engine in spite of limphome procedure, have your vehicle towed byan authorized Hyundai dealer.

FEATURES OF YOUR HYUNDAI 1- 11
B150C02A-AAT Larger ChildrenChildren who are too large for child restraint systems should always occupy the rear seat anduse the available lap/shoulder belts. The lapportion should be fastened snug on the hips andas low as possible. Check belt fit periodically. Achild's squirming could put the belt out of posi-tion. Children are afforded the most safety in theevent of an accident when they are restrained bya proper restraint system in the rear seat. If alarger child (over age 13) must be seated in thefront seat, the child should be securely restrainedby the available lap/shoulder belt and the seatshould be placed in the rearmost position. Chil-dren under the age of 13 should be restrainedsecurely in the rear seat. NEVER place a childunder the age of 13 in the front seat. NEVERplace a rear facing child seat in the front seat ofa vehicle. B150D01A-AAT Pregnant WomenThe use of a seat belt is recommended for pregnant women to lessen the chance of injury inan accident. When a seat belt is used, the lap beltportion should be placed as low and snugly aspossible on the hips, not across the abdomen.For specific recommendations, consult a physi-cian.
WARNING:The purpose of the fold-down rear seatbacksis to allow you to carry longer objects thancould otherwise be accommodated. Neverallow passengers to sit on top of the foldeddown seat back while the car is moving asthis is not a proper seating position and noseat belts are available for use. This couldresult in injury in case of an accident orsudden stop. Objects carried on the foldeddown seatback should not extend higher thanthe top of the front seats. This could allowcargo to slide forward and cause injury ordamage during sudden stops.
B150A02A-GAT SEAT BELT PRECAUTIONS All occupants of the vehicle should wear their
seat belts at all times. Indeed, your province'slaws may require that some or all occupants ofthe vehicle use seat belts.The possibility of injury or the severity of injury inan accident will be decreased if this elementarysafety precaution is observed. In addition, followthe other instructions provided in this section. B150B01A-GAT Infant or Small Child Some countries require the use of child restraint systems for infants and small children. Whetherthis is required by law or not, it is stronglyrecommended that a child restraint seat or infantrestraint system be used for infants or small
children weighing less than 18 kilograms (40pounds).
B140A01S-AAT REAR SEAT WARNING
B140A01GK
For the safety of all passengers, luggage or other
cargo should not be piled higher than the top of
the seatback. In addition, do not place objects on
the rear shelf as they may move forward during braking or in an accident and strike vehiclepassengers.

FEATURES OF YOUR HYUNDAI
1- 12 B160D01A-AAT When to Replace Seat Belts
Entire in-use seat belt assembly or assemblies should be replaced if the vehicle has been in-volved in an accident. This should be done evenif no damage is visible. Additional questionsconcerning seat belt operation should be direct-ed to your Hyundai Dealer.
The shoulder belt can't do its job because itwon't be against your body. Instead, it will bein front of you. In a crash you could go into itwith great force, receiving serious neck orother injuries.The lap belt can't do its job either. In a crashthe belt could go up over your abdomen. Thebelt forces would be applied there, not at yourstrong pelvic bones.This could cause serious internal injuries.For proper protection when the vehicle is inmotion, have the seatback upright. Then sitback in the seat and wear your seat beltproperly.
B160A01S-GAT CARE OF SEAT BELTS Seat belt systems should never be disassembled or modified. In addition, care should be taken toassure that seat belts and belt hardware are notdamaged by seat hinges, doors or other abuse. B160B01A-AAT Periodic InspectionIt is recommended that all seat belts be inspected periodically for wear or damage of any kind.Parts of the system that are damaged should bereplaced as soon as possible. B160C01A-AAT Keep Belts Clean and DrySeat belts should be kept clean and dry. If belts become dirty, they can be cleaned by using amild soap solution and warm water. Bleach, dye,strong detergents or abrasives should not beused because they may damage and weaken thefabric.
B150E01A-AAT Injured PersonA seat belt should be used when an injured person is being transported. When this is neces-sary, you should consult a physician for recom-mendations. B150F01A-AAT One Person Per Belt Two people (including children) should never attempt to use a single seat belt. This couldincrease the severity of injuries in case of anaccident. B150G01A-AAT Do Not Lie Down To reduce the chance of injuries in the event of an accident and to achieve maximum effectivenessof the restraint system, all passengers should besitting up and the front seats should be in anupright position when the car is moving. A seatbelt cannot provide proper protection if the per-son is lying down in the rear seat or if the frontseat is in a reclined position. WARNING: Sitting in a reclined position or lying downwhen your vehicle is in motion can be dan-gerous. Even if you buckle up, your seat beltscan't do their job when you're reclined.

FEATURES OF YOUR HYUNDAI
1- 14 WARNING:
o A child restraint system must be placed in
the rear seat. Never install a child or infantseat on the front passenger's seat.Should an accident occur and cause thepassenger side airbag to deploy, it couldseverely injure or kill an infant or childseated in an infant or child seat. Thus, onlyuse a child restraint in the rear seat of yourvehicle.
o Since a safety belt or child restraint sys- tem can become very hot if it is left in aclosed vehicle, be sure to check the seatcover and buckles before placing a childthere.
o When the child restraint system is not in use, store it in the trunk or fasten it with asafety belt so that it will not be thrownforward in the case of a sudden stop or anaccident.
o Children who are too large to be in a child restraint should sit in the rear seat and berestrained with the available lap/shoulderbelts. Never allow children to ride in thefront passenger seat.
o Always make sure that the shoulder belt portion of the outboard lap/shoulder beltis positioned midway over the shoulder,never across the neck or behind the back.Moving the child closer to the center of thevehicle may help provide a good shoulderbelt fit. The lap belt portion of the lap/
B210A01A-AAT To Release the Seat Belt The seat belt is released by pressing the release button in the locking buckle. When it is released,the belt should automatically draw back into theretractor.If this does not happen, check the belt to be sureit is not twisted, then try again.
FUA1090R
B230A03A-GAT CHILD RESTRAINT SYSTEM (If Installed) Children riding in the car should sit in the rear seat and must always be properly restrained tominimize the risk of injury in an accident, suddenstop or sudden maneuver. According to accidentstatistics, children are safer when properly re-strained in the rear seats than in the front seat.Larger children not in a child restraint should useone of the seat belts provided.You are required by law to use safety restraintsfor children. If small children ride in your vehicleyou must put them in a child restraint system(safety seat).Children could be injured or killed in a crash iftheir restraints are not properly secured. Forsmall children and babies, a child seat or infantseat must be used. Before buying a particularchild restraint system, make sure it fits your carseat and seat belts, and fits your child. Follow allthe instructions provided by the manufacturerwhen installing the child restraint system.

FEATURES OF YOUR HYUNDAI 1- 15
B230G01A-GAT Installation on the Outboard Rear Seats
B230G01GK
On outboard rear seats
To install a child restraint system in the outboard rear seats, extend the shoulder/lap belt from itsretractor. Install the child restraint system, bucklethe seat belt and allow the seat belt to take up anyslack. Make sure that the lap portion of the belt istight around the child restraint system and theshoulder portion of the belt is positioned so thatit cannot interfere with the child's head or neck.After installation of the child restraint system, tryto move it in all directions to be sure the childrestraint system is securely installed.If you need to tighten the belt, pull more webbingtoward the retractor. When you unbuckle theseat belt and allow it to retract, the retractor willautomatically revert back to its normal seatedpassenger emergency locking usage condition.
shoulder belt must always be positionedas low as possible on the child's hips andas snug as possible.
o If the seat belt will not properly fit the child, Hyundai recommends the use of anapproved booster seat in the rear seat inorder to raise the child's seating height sothat the seat belt will properly fit the child.
o Never allow a child to stand up or kneel on the seat.
o Never use an infant carrier or child safety seat that "hooks" over a seatback; it maynot provide adequate security in an acci-dent.
o Never allow a child to be held in a person's arms while they are in a moving vehicle, asthis could result in serious injury to thechild in the event of an accident or asudden stop. Holding a child in a movingvehicle does not provide the child withany means of protection during an acci-dent, even if the person holding the childis wearing a seat belt.
o If the child restraint seat is not anchored properly, the risk of a child being seri-ously injured or killed in a collision greatlyincreases. NOTE:
o Before installing the child restraint sys-
tem, read the instructions supplied by thechild restraint system manufacturer.
o If the seat belt does not operate as de- scribed, have the system checked imme-diately by your authorized Hyundai dealer.
WARNING:Do not install any child restraint system in thefront passenger seat. Should an accidentoccur and cause the passenger side airbagto deploy, it could severely injure or kill aninfant or child seated in an infant or childseat. Therefore, only use a child restraintsystem in the rear seat of your vehicle.

FEATURES OF YOUR HYUNDAI
1- 16 1. Route the child restraint seat strap over the
seatback. For vehicles with adjustable headrests, routethe tether strap under the headrest and be-tween the headrest posts, otherwise routethe tether strap over the top of the seatback.
2. Remove the load space cover.
3. Connect the tether strap hook to the child restraint hook holder and tighten to securethe seat.
B230B02GK-GAT Using a Child Restraint System with "Tether Anchorage" System For small children and babies, the use of a child seat or infant seat is required. This child seat orinfant seat should be of appropriate size for thechild and should be installed in accordance withthe manufacturer's instructions. It is further re-quired that the seat be placed in the vehicle's rearseat since this can make an important contribu-tion to safety. Your vehicle is provided with twochild restraint hook holders for installing the childseat or infant seat.
B230B01Y
Cover, Child Restraint Hook Holder
Bolt, Holder (5/16"-30 mm) Washer, Conical Spring
B230E01GK
Back panel
Front of Vehicle
Tether strap hook
B230E02GK-GAT Securing a Child Restraint System with "Tether Anchorage" System Two child restraint hook holders are located on the vertical back panel.
Load Space Cover
Holder, Child Restraint Hook Spacer, Hook Holder Cover Spacer (10 mm), Child Restraint Hook Holder Retainer Washer

FEATURES OF YOUR HYUNDAI 1- 17
B230D01GK-GAT Securing a Child Restraint System with "ISOFIX" System and "Tether Anchor-age" System (If installed)
B230F01GK
ISOFIX is a standardised method of fitting child seats that eliminates the need to use the stan-dard adult seat belt to secure the seat in thevehicle. This enables a much more secure andpositive location with the added benefit of easierand quicker installation. An ISOFIX-seat can only be installed if it has vehicle-specific approval in accordance with therequirements of ECE-R44. For your Hyundai,the Hyundai ISOFIX GR1 / Hyundai Duo / RömerISOFIX GR1 and the Römer Duo ISOFIX / BritaxDuo ISOFIX is approved according to the re-quirement ECE-R44. This seat has been testedextensively by Hyundai and is recommended foryour Hyundai. NOTE:At present, this seat is the only one comply-ing with that provision. In case that othermanufacturers will furnish proof of a respec-tive certification, Hyundai is going to evalu-ate this seat carefully and will give a recom-mendation provided that seat complies to thelaw. Please ask your Hyundai dealer in thisrespect.
B230D02GK
ISOFIX AnchorISOFIX Anchor
Position
Indicator
On each side of the rear seat, between the cushion and backrest, are located a pair of ISOFIXanchorage points together with a top tether mount-ing on the luggage compartment. During theinstalling, the seat has to be engaged at theanchorage-points in a way you can hear it click-ing (check by pulling!) and has to be fixed with theTop Tether-belt on the belonging point in theluggage-compartment. The installing and the useof a child-seat has to be done according to theinstalling-manual, which is added to the ISOFIX-seat. NOTE:An ISOFIX-child-seat can only be installed ifthe seat has a vehicle-specific approval ac-cording to ECE-R44. Before using the ISOFIX-child-seat, which was bought for another car,ask your Hyundai-dealer whether this seat-type is approved and recommended for yourHyundai. To secure the child restraint seat
1. To engage the child restraint seat to the
ISOFIX anchor, insert the child restraint seat latch into the ISOFIX anchor. Listen for theaudible "click" sound.
2. Connect the tether strap hook to the child restraint hook holder and tighten to securethe seat. Refer to "Securing a Child RestraintSystem with the Tether Anchorage System"on page 1-16.
HGK261

FEATURES OF YOUR HYUNDAI
1- 18 B180B01GK-GAT Pre-tensioner Seat Belt (If Installed)Your Hyundai vehicle is equipped with driver's and front passenger's pre-tensioner seat belts.The purpose of the pre-tensioner is to make surethat the seat belts fit tightly against the occu-pant's body in certain frontal collisions.The pre-tensioner seat belts can be activatedalone or, where the frontal collision is severeenough, together with the airbags.
B180B01S
NOTE: This vehicle is equipped with thether anchor-age and ISOFIX system to supply most suit-able safety (EC ONLY). we recommend to buya child restraint system to use thether an-chorage and ISOFIX system. The pre-tensioner seat belt operates in a similiar way as an Emergency Locking Retractor (ELR)type of seat belt. When the vehicle stops sudden-
B230H03GK-GAT Child Seat Restraint Suitability For Seat Position (If installed) Use child safety seats that have been officially approved and are appropriate for your children.
Age Group
0 : Up to 10 kg (0 ~ 9 months)0+ : Up to 13 kg(0 ~ 2 years)I : 9kg to 18kg(9 months ~4 years)II & III : 15kg to 36kg(4 ~ 12 years)
U :Suitable for "universal" category restraints approved for use in this mass group
UF :Suitable for forward-facing "universal" cat- egory restraints approved for use in thismass group
L1: Suitable for "Römer ISOFIX GR1" approved for use in this mass group(Approval No: E1 R44-03301133)
X : Seat position not suitable for children in this mass group
N/A: No seating position is provided
WARNING:
o There is no center rear seating position.
o Do not install a child restraint seat at the
center of the rear seat using the vehicle'sISOFIX anchors. The ISOFIX anchors areonly provided for the left and right out-board of the rear seat. Do not misuse theISOFIX anchors by attempting to attach achild restraint seat in the middle of therear seat to the ISOFIX anchors. In a crash,the child restraint seat ISOFIX attachmentsmay not be strong enough to secure thechild restraint seat properly in the centerof the rear seat and may break, causingserious injury or death.
o Do not mount more than one child re- straint to a child restraint lower anchor-age point. The improper increased loadmay cause the anchorage points or tetheranchor to break, causing serious injury ordeath.
o Attach the ISOFIX or ISOFIX-compatible child restraint seat only to the appropriatelocations shown in the illustration.
o Always follow the installation and use instructions provided by the manufacturerof the child restraint. Seating Position
1st
Passenger Rear
Outboard
X X
L1
X
XX X XN/A N/A N/A N/A
Rear
Center
