2004 HONDA ODYSSEY Button

The clock displays the time with the
ignition switch in any position.
To set the clock:Turn the ignition switch to ON (II). Press and hold the H button until
the hour advances to the desired
time.
Press and hold the M button until
the numbers advance to the
desired time.
You can use R to quickly set the time
to the nearest hour. If the displayed
time is before the half hour, pressing
Rsetstheclockbacktotheprevious
hour. If the displayed time is af ter
the half hour, pressing R sets the
clock f orward to the beginning of the
next hour.
For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00. To use the center table, pull up the
outside edge of the table until it
latches. To store it, pull the lever and
lower the table.
2.
3.
1.
CONT INUED
On models without navigation system
Interior Convenience Items
Clock Center Table
Inst rument s and Cont rols105
HM R

The lights go out about six seconds
after all the doors and the tailgate
are closed.
With the light control switch in the
Door Activated position, all the
individual map lights and the cargo
area light (with its switch in the
center position) come on when you
unlock the door with the remote
transmitter (see page ).
Withanydoororthetailgateleft
open, the lights stay on about 3
minutes, then go out.Turn on the f ront individual map
lights by pushing the button next to
each light. Push the button again to
turn it off. You can also operate
these lights with the light control
switch (see page ).Turn on each rear individual map
light by pushing the lens when the
ignition switch is in the
ACCESSORY (I) or ON (II) position.
Push the lens again to turn it off.
You can also operate these lights
with the light control switch (see
page ).
112
81
112
On EX and EX-L models
Interior Lights
Inst rument s and Cont rols
Individual Map L ights
113
FRONTREAR

The heating and air conditioning
systems in your Honda provide a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section de-
scribes those f eatures and how to
use them. (If you selected an
optional audio system, ref er to the
operating instructions that came
with it.)
The security system helps to dis-
courage vandalism and thef t of your
Honda. Your Honda has an anti-thef t audio
system that requires a code number
to enable it..............
Vents, Heating, and A/C . 116
.........................
Airflow Buttons .117
Using Automatic Climate ...................................
Control .121
...................
Rear Climate Control . 124
..............
Climate Control Sensors . 125
..........................
Playing the Radio .126
............................
Radio Reception .130
..................................
Playing a CD .132
Operating the Optional CD .....................................
Changer .134
....................
Protecting Your CDs .135
.........
CD Player Error Messages . 136
.....
CD Changer Error Messages . 137
...............................
Playing a Tape .139
.............
Steering Wheel Controls . 143
.................
Radio Thef t Protection . 144
........
Rear Entertainment System . 145
..............................
Playable DVDs .154
............................
Security System .159
...............................
Cruise Control .160
HomeLink Universal ................................
Transceiver .163
On EX and EX-L models
Comf ort and Convenience Features
Comf ort and Convenience Feat ures115

Vents, Heating, and A/C
Comf ort and Convenience Feat ures
LX modelEX model and EX-L model wit hout Navigat ion Syst em EX-L model wit h Navigat ion Syst em
116
MODE BUTTONS
REAR A/C
CONTROL DIAL
FAN CONTROL
DIAL
RECIRCULATION
BUTTON REAR WINDOW DEFOGGER BUTTONTEMPERATURE CONTROL
DIAL
TEMPERATURE
CONTROL DIAL AUTO
BUTTON
OFF BUTTON
DEFROST BUTTON
TEMPERATURE
DISPLAY
RECIRCULATION
BUTTON
MODE ICONS AIR CONDITIONING (A/C) ICONS
AIR CONDITIONING BUTTON AIR CONDITIONING BUTTON TEMPERATURE BUTTON
MODE BUTTON FAN CONTROL ICONS
FULL AUTO
DISPLAY
OFF BUTTON FAN CONTROL DIAL
REAR A/C CONTROL DIAL
AUTO BUTTON
RECIRCULATION BUTTON DEFROST BUTTON MODE
ICONS
REAR WINDOW
DEFOGGER BUTTON
REAR WINDOW
DEFOGGER BUTTON

ÛÝ
For automatic climate control and
manual operation on EX and EX-L
models, see page .
Turn this dial clockwise to increase
fan speed and increase the airflow.
You can manually select the f an
speed. Press the A/C button to view
the display, then press any of the fan
control icons. Turning this dial clockwise increases
the temperature of the airflow.
To select the desired temperature,
press either side of the temperature
(TEMP) button ( or ).
This button turns the air
conditioning on and of f . On LX
models, the light in the button is on
when the A/C is on. On EX and EX-L
models, you will see A/C ON or A/C
OFF selected in the display.Press the A/C button to view the
display. Touching ON or OFF in the
display turns the air conditioning on
andoff.YouwillseeA/CONorA/C
OFF in the display.
When you turn the A/C of f , the
system cannot regulate the inside
temperature if you set the
temperature control below the
outside temperature.
121
On all models without Navigation
System
On EX-L model with Navigation System On all models without Navigation
System
On EX-L model with Navigation System
On all models without NavigationSystem On EX-L model with Navigation System
On EX and EX-L models
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
Fan Control T emperature Control
Air Conditioning (A/C) Button/
Icons
Airf low Buttons
117

When the light in/above the button
is on, air f rom the vehicle’s interior is
sent throughout the system again.
When the light is of f , air is brought
in f rom the outside of the vehicle
(Fresh Air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
ThesystemshouldbeleftinFresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to Recirculation mode when
driving through dusty or smoky
conditions, then return to Fresh Air
mode.This button turns the rear window
def ogger of f and on (see page ).
Use the mode control buttons or
icons to select the vents the air f lows
f rom. Some air will f low f rom the
dashboard corner vents in all modes.
Air flows from the center
and corner vents in the dashboard.
Air f lows f rom the f loor
vents. Air f lows f rom the def roster
vents at the base of the windshield.
When you select or ,
the system automatically switches to
Fresh Air mode and turns on the
A/C.
When you select , the system
automatically switches to Fresh Air
mode.
With this dial, you can adjust the
rear A/C unit heating, cooling, and
airflow (see page ).
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield. 73
123
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
Recirculation Button Rear Window Def ogger Button
Mode Control
Rear A /C Control Dial
118

ÛÝ
The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear side
panels.
Set the temperature control dial or
the button to the lower limit.
Make sure the A/C is of f .
Select and Fresh Air mode.
Set the f an to the desired speed. The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system.
Select .
When you select , the system
automatically switches to Fresh
Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial. Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally.
Press the A/C button to show the
A/C screen.
Select the desired mode and f an
speed icons on the screen.
Adjustthewarmthwiththe
temperature button ( or ). Press the A/C button. The light
above the button comes on when a
f an speed is selected.
Make sure the temperature
control dial is set to the lower limit.
Select .
If the outside air is humid, select
the Recirculation mode. If the
outside air is dry, select the Fresh
Air mode.
Set the f an to the desired speed.
1.
2.
3.
4.
1.
2.
3.
1.
2.
3.1.
2.
3.
4.
5.67
CONT INUED
All except EX-L model with Navigation
System
EX-L model with Navigation System All except EX-L model with Navigation
System
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
Ventilation Using the Heater Using the A /C
119

Press the A/C button to show the
A/C screen.
Select the ON icon on the screen.
Select the desired temperature
and MODE selections. If the
outside air is humid, select the
Recirculation mode. If the outside
air is dry, select the Fresh Air
mode.you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in Fresh Air mode.
The vehicle has two A/C and
heater units. These units are
controlled by the f ront panel controls,
unless the RR A/C control dial is in
the OFF position. The rear
passengers can also adjust the
direction and the amount of airf low. Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and Fresh Air mode.
Adjust the temperature control
dial or button to your pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C). Set the f an to the desired speed, or
high f or f aster def rosting.
Select . The system
automatically switches to Fresh
Air mode and turns on the A/C.
Adjust the temperature control
dial or button so the airf low f eels
warm.
Select to help clear the
rear window.
To increase airf low to the
windshield, close the side vents.
To remove f og f rom the inside of the
windows:
When you switch to another mode
f rom , the A/C stays on.
Press the A/C button to turn it of f .
1.
2.
3.
4.
1.
2.
3.
4.
5.
1.
2.
3.
If the interior is very warm,
EX-L model with Navigation System
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
Dehumidif y the Interior
T o Def og and Def rost
120
