2004 HONDA CIVIC COUPE check engine light

Check the level in the windshield
washer reservoir at least monthly
during normal usage.Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather.
When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer f luid
on a clean cloth. This will help to
condition the blade edges.
The low washer
level indicator will light when the
level is low.
On Canadian models:
Windshield Washers
Maint enance156
NOTICE: Do not use engine antif reeze
or a vinegar/water solution in the
windshield washer reservoir. Antif reeze
can damage your vehicle’s paint, while
a vinegar/water solution can damage
the windshield washer pump. Use only
commercially-available windshield
washer f luid.
——y

y
(%y
y

Diagnosing why your engine won’t
start f alls into two areas, depending
on what you hear when you turn the
key to START (III):You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. Check these things:
When you turn the ignition switch to
START (III), you do not hear the
normal noise of the engine trying to
start. You may hear a clicking sound
or series of clicks, or nothing at all.
Check the transmission interlock.
If you have a manual transmission,
the clutch pedal must be pushed
all the way to the f loor or the
starter will not operate. With an
automatic transmission, it must be
in Park or Neutral.
Turn the ignition switch to ON (II).
Turn on the headlights and check
their brightness. If the headlights
are very dim or don’t light at all,
the battery is discharged. See on page . Turn the ignition switch to START
(III). If the headlights do not dim,
check the condition of the f uses. If
the f uses are OK, there is
probably something wrong with
the electrical circuit f or the
ignition switch or starter motor.
You will need a qualif ied
technician to determine the
problem (see
on page ).
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is dis-
charged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
191 203
178
191
If theEngineWon’tStart
Nothing Happens or the Starter
Motor Operates Very Slowly
Jump Starting Emergency T owing
T aking Care of t he Unexpect ed189
——y
y
(%y
y

µ
´ ´
Although this seems like a simple
procedure, you should take several
precautions.
You cannot start a Honda with an
automatic transmission by pushing
or pulling it.
Connect the second jumper cable
to the negative ( ) terminal on
the booster battery. Connect the
other end to the grounding strap
as shown. Do not connect this
jumper cable to any other part of
the engine.
If the booster battery is in another
vehicle, have an assistant start
that vehicle and run it at a fast idle.
Open the hood and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or like ice, do not try
jump starting until it thaws.
Turn of f all the electrical acces-
sories: heater, A/C, climate
control, stereo system, lights, etc.
Put the transmission in Neutral or
Park, and set the parking brake.
Connect one jumper cable to the
positive ( ) terminal on your
battery. Connect the other end to
the positive ( ) terminal on the
booster battery.
3.
5.
1. 2.
4.
CONT INUED
Jump Starting
T aking Care of t he Unexpect ed
To Jump Start Your Vehicle:
191
NOTICE:
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyonenearby.
Keep all sparks, open flames,
and smoking materials away
from the battery. If a battery sits in extreme
cold, the electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.
——y
y
(%y
y

CONT INUED
BatteryCharging System ...........................
Indicator . 56, 195
............................
Jump Starting . 191
..............................
Maintenance . 178
............................
Specif ications . 209
..............................
Bef ore Driving . 113
....................................
Belts,Seat .8,19
...........................
Beverage Holders . 87
..................................
Booster Seats . 45
Brakes
...........
Anti-lock System (ABS) . 139
.............
Break-in, New Linings . 114
....................
Bulb Replacement . 164
...........................................
Fluid . 163
.......................................
Parking . 131
.................
System Indicator . 57, 197
........................
Wear Indicators . 138
.............................
Braking System . 138
........................
Break-in, New Car . 114 ..
Brightness Control, Instruments . 66
........................
Brights, Headlights . 65
Bulb Replacement
..........................
Back-up Lights . 167
..............................
Brake Lights . 167
................
Front Parking Lights . 166
........
Front Side Marker Lights . 166
.................................
Headlights . 164
.........
High-mount Brake Light . 168
.........
Rear Side Marker Lights . 167
............................
Specif ications . 209
....................
Turn Signal Lights . 166
..............................
Bulbs, Halogen . 164
............................
Capacities Chart . 208
.............
Carbon Monoxide Hazard . 47
.............................
Carrying Cargo . 122
Cassette Player
............................................
Care . 106
...................................
Operation . 104
..............
CAUTION, Explanation of . ii
.........................................
CD Care . 101
....................................
Accessories . 120
ACCESSORY (Ignition Key
.......................................
Position) . 71
...............
Accessory Power Socket . 88
....................
Additives, Engine Oil . 152
.............................
Airbag (SRS) . 10, 22
................
Air Conditioning System . 91
.........................
Air Outlets (Vents) . 90
.......................
Air Pressure, Tires . 172
..................
High Speed Driving . 173
.........................
Normal Driving . 172
.......................
Alcohol in Gasoline . 212
......................................
Antif reeze . 157
Anti-lock Brakes (ABS)
....................
Indicator Light . 57, 139
...................................
Operation . 139
Anti-thef t Steering Column ..............................................
Lock . 71
..................................
Audio System . 94
.............
Automatic Speed Control . 110
..............
Automatic Transmission . 130
..........................
Capacity, Fluid . 208
...............
Checking Fluid Level . 160
.......................................
Shif ting . 130 .
Shif t Lever Position Indicator . 130
................
Shif t Lever Positions . 130
....................
Shif t Lock Release . 133
Index
A
B
C
I
——yy
(%yy

................
DANGER, Explanation of . ii
................
Daytime Running Lights . 65
.................................
Dead Battery . 191 ............
Def ects, Reporting Saf ety . 220
..........................
Def og and Def rost . 93
................
Def ogger, Rear Window . 67
................
Def rosting the Windows . 93
....................................
Dimensions . 208
...............
Dimming the Headlights . 65
Dipstick
..........
Automatic Transmission . 160
..................................
Engine Oil . 118
..........................
Directional Signals . 65
........
Disc Brake Wear Indicators . 138
.....................
Disposal of Used Oil . 155
Doors
..............
Locking and Unlocking . 72
......................
Power Door Locks . 72
..........
DOT Tire Quality Grading . 210
Downshif ting, 5-speed Manual
.............................
Transmission . 128
...........
Driver and Passenger Safety . 5
...........................................
Driving . 125
....................................
Economy . 119
...................................
CD Changer . 100
.......
CD Changer Error Messege . 103
.......................
CD Error Messege . 102
.........................................
CD Player . 99
....................................
Ceiling Light . 85
........................
Certif ication Label . 206
............................................
Chains . 177
....................
Changing a Flat Tire . 183
Changing Oil
........................................
How to . 152
......................................
When to . 145
...
Charging System Indicator . 56, 195
.....................................
Child Saf ety . 29
..............................
Booster Seats . 45
...................................
Child Seats . 36
.....
Important Saf ety Reminders . 29
..........................................
Inf ants . 34
............................
Large Children . 43
.........................................
LATCH . 38
......................
Risks with Airbags . 34
.............................
Small Children . 34
.........................................
Tethers . 42
.........
Where Should a Child Sit? . 30
Child Seats ...........................
Lower Anchors . 38
..........
Tether Anchorage Points . 42 ..............................................
Clock . 108
.........................
Clock, Setting the . 108
...................................
Clutch Fluid . 163
........................
CO in the Exhaust . 213
........................................
Coat Hook . 86
............
Cold Weather, Starting in . 126
..............................
Compact Spare . 182
.................
Consumer Inf ormation . 218
.............
Controls, Instruments and . 51
Coolant
........................................
Adding . 157
....................................
Checking . 118
.........................
Proper Solution . 157
...................................
Replacing . 158
...................
Temperature Gauge . 61
Crankcase Emissions Control ........................................
System . 212
................
Cruise Control Indicator . 58
............
Cruise Control Operation . 110
..........
Customer Relations Of f ice . 218
Index
D
II
——yy
(%yy

CONT INUED
........................................
Introduction . i
..................................................
Keys . 69 ...................
Neutral Gear Position . 131
..................
New Vehicle Break-in . 114
.....................
Normal Shif t Speeds . 129
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 206
...
Octane Requirement, Gasoline . 114
.........................................
Odometer . 60
...............................
Odometer, Trip . 60
Oil
........................
Change, How to . 154
......................
Change, When to . 145
......................
Checking Engine . 117
..............
Pressure Indicator . 56, 195
Selecting Proper Viscosity
......................................
Chart . 153
.................
Jacking up the Vehicle . 184
.......................................
Jack, Tire . 183
................................
Jump Starting . 191
.......................
Label, Certif ication . 206
.................
Lane Change, Signaling . 65
..................
Lap/Shoulder Belts . 14, 19
Lights
....................
Bulb Replacement . 164
.......................................
Indicator . 56
.........................................
Parking . 57
..................................
Turn Signal . 58
.....................................
Load Limit . 123
......
LOCK (Ignition Key Position) . 71
Locks
.......
Anti-thef t Steering Column . 71 ............................
Fuel Fill Door . 115
.................................
Power Door . 72
...........................................
Trunk . 72
........................
Low Coolant Level . 118
.........................
Low Fuel Indicator . 58
................................
Lower Anchors . 38
...
Lower Gear, Downshif ting to a . 128
...
Low Oil Pressure Indicator . 56, 195
...
Lubricant Specif ications Chart . 208
.........................................
Luggage . 122
..................................
Maintenance . 141
...
Owner Maintenance Checks . 144
.................................
Record . 149-150
......................
Required Indicator . 62
..........................................
Saf ety . 142
.............................
Schedule . 145-148
.
Malf unction Indicator Lamp . 58, 196
...................
Manual Transmission . 128
........
Manual Transmission Fluid . 162
...............................
Meters, Gauges . 60
...................
Methanol in Gasoline . 114
..........................
Mirrors, Adjusting . 83
...............
Modif ying Your Vehicle . 121 .........................................
Moonroof . 82
......................
Closing Manually . 198
.....................................
Operation . 82
Index
N
K
J L
M
O
V
——y
y
(%yy

Î
...........
ON (Ignition Key Position) . 71
Onboard Ref ueling Vapor
....................................
Recovery . 212
..............................
Outside Mirrors . 83
....................
Overheating, Engine . 192
.......
Owner Maintenance Checks . 144
.........................
Oxygenated Fuels . 212
..............
Panel Brightness Control . 66
........................
Park Gear Position . 131
...........................................
Parking . 137
.................................
Parking Brake . 84
Parking Brake and Brake
.........................
System Indicator . 57
...............................
Parking Lights . 166
..
Parking Over Things that Burn . 214
.............................
PGM-FI System . 213
..........................
Power Door Locks . 72
.................
Power Socket Locations . 88
..............................
Power Windows . 81
.........
Pregnancy, Using Seat Belts . 17
.........
Protecting Adults and Teens . 11
...
Additional Safety Precautions . 18
.....
Advice f or Pregnant Women . 17 ........................
Protecting Children . 29
.......................
General Guideline . 29
................
Installing a Child Seat . 37
.......................
Protecting Inf ants . 34
.......
Protecting Larger Children . 43
.........
Protecting Small Children . 35
..................
Selecting Child Seats . 36
Using Child Seats with
.....................................
Tethers . 42
................
Using Lower Anchors . 38
...................
Radiator Overheating . 192
Radio/CD/Cassette
..............................
Sound System . 94
...................
Readiness Codes . 196, 215
Rear Lights, Bulb
..............................
Replacement . 167
..........................
Rear Seat, Folding . 79
............................
Rear View Mirror . 83
.................
Rear Window Def ogger . 67
...............
Reclining the Seat Backs . 76
.......
Recommended Shif t Speeds . 129
.............................
Reminder Lights . 56
.......................
Remote Transmitter . 74 Replacement Inf ormation
..............
Dust and Pollen Filter . 169
................
Engine Oil and Filter . 154
..........................................
Fuses . 199
................................
Light Bulbs . 164
....................................
Schedule . 143
................................
Spark Plugs . 208
................................
Timing Belt . 162
...........................................
Tires . 172
.............................
Wiper Blades . 170
Replacing Seat Belts Af ter a ............................................
Crash . 21
Reserve Tank, Engine ...............................
Coolant . 118, 157
...............................
Restraint, Child . 29
..................
Reverse Gear Position . 131
......................................
Roof Rack . 124
................................
Rotation, Tire . 175
..................................
Saf ety Belts . 8, 19
.........
Safety Defects, Reporting . 220
.................................
Saf ety Features . 7
.........................................
Airbags . 10
.......................................
Seat Belts . 8
Index
R
P
S
VI
——y
y
(%y
y
