2004 FIAT CROMA buttons

40
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
REGIONAL MODE function
(regional broadcast reception)
Certain national broadcasters, at determinate times of
the day, transmit regional programmes which differ
from region to region. This function makes it possible
to tune in only on local stations (regional). However if
a regional programme is heard and you wish to stay
tuned to it, the function must be activated.
To turn the function on/off use button
7 (
÷) or 5 (˜).
The display will show the current status of the
function:
❒“REGIONAL MODE: ON” (function on);
❒“REGIONAL MODE: OFF” (function off);
If the function is off and a regional programme is tuned
that works in a determinate area and the car enters a
different area, the regional station of the new area is
received.
IMPORTANT When the function is off (“REGIONAL
MODE: OFF”) and the AF function is on (alternative
frequencies) the radio automatically tunes to the
frequency of the station selected with the strongest
signal.CD DISPLAY function
(Compact Disc data display)
With this function it is possible to choose the
information shown on the display,when listening to a
Compact Disc.
After choosing “CD” in the menu using buttons 3 (
N)
or 6 (
O), the display shows “CD DISPLAY”. To
change the setting use buttons 7 (
÷) or 5 (˜).
The display shows the setting among the two possible:
❒“TIME” (time elapsed from start of track);
❒“NAME” (CD name).
CDC DISPLAY function
(CD Changer data display) (if installed)
This function can be chosen only if a CD Changer is
connected. In this case the display will show “CDC
DISPLAY”.
To change the function use buttons 7 (
÷) or 5
(
˜).
The display shows the setting among the three
possible:
❒“TIME” (time elapsed from start of track);
❒“CD NR” (CD number);
❒“NAME” (CD name).

41
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
SENSITIVITY function
(tuner sensitivity adjustment)
With this function it is possible to change the
sensitivity of automatic station searching. When low
sensitivity “SENSITIVITY:LOCAL” is set only stations
with excellent reception are sought; when high
sensitivity “SENSITIVITY: DISTANCE” is set all
stations are sought. Therefore, if the car is in an area
with a considerable number of stations and you want
to choose only those with a strong signal, set to low
sensitivity “SENSITIVITY: LOCAL”.
To set the sensitivity, use button 7 (
÷) or 5 (˜).
The display will show the current status of the
function:
❒“SENSITIVITY: LOCAL” (low sensitivity);
❒“SENSITIVITY: DISTANCE” (high sensitivity).
SVC SETTING function
(volume changing with speed)
The SVC function makes it possible to automatically
adapt the volume level to the speed of the car,
increasing it as the speed increases to maintain the
ratio with the noise level in the passenger
compartment.
To turn the function on/off use button
7 (
÷) or 5 (˜). The display will show the current
status of the function:
❒“SVC SETTING: ON” (function on);
❒“SVC SETTING: OFF” (function off).CD NAMING function
(allocating a name to a CD)
Use the CD NAMING function to give a name (max.
name length = 8 characters) to max. 30 CDs.
This function can be selected only if in Compact Disc
or CD Changer mode. To turn this function on, use
button 7 (
÷) or 5 (˜): the display shows “CD
NAMING FUNCTION”. If the CD already has a name,
this will be shown on the display, if not, eight dashes
will be shown. If storage is no longer available for a
new name, the display will show the first name stored.
To change the name or give a name to the new CD
press button 7 (
÷) or 5 (˜). Press the buttons
again to choose the position of the character to be
changed. Press buttons 3 (
N) or 6 (O) to choose or
change the character.
To store the name, press button 12 (MENU-PRESET
SCAN) again. The display will show “CD NAME”.
To clear a name, turn the function on and press
button 16 (2-CLR) for about 5 seconds. The system
beeps and the display shows “ONE NAME DELETED”
for about 2 seconds. At this point the procedure can
be started to give a new name.
To clear all the names, turn the function on and keep
button 16 (2-CLR) pressed for over 8 seconds. The
set gives two beeps and the display shows “ALL
NAMES DELETED” for about 2 seconds. At this point
it is possible to start the name allocation procedure.

42
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
VOICE SETTINGS function
(telephone volume adjustment)
With this function it is possible to adjust (setting from
1 to 66) or cut off (OFF setting) the telephone sound.
To turn the function on/off use button 7 (
÷) or 5
(
˜).
To adjust,turn the button/knob 19 (ON/OFF
VOLUME).
The display will show the current status of the
function:
❒“VOICE VOLUME 23”: function on with volume
setting 23
❒“VOICE FUNCTION OFF”: function off.HICUT function (treble reduction)
Using this function it is possible to reduce the treble
tones, in accordance with the signal transmitted. To
turn the function on/off use button 7 (
÷) or 5
(
˜).
The display will show the current status of the
function:
❒“HICUT FUNCTION: ON” (function on);
❒“HICUT FUNCTION: OFF” (function off).
IGNITION TIMER function
(system power off mode)
This function enables to switch off the sound system
according to two different modes. To turn this
function on/off, use buttons 7 (
÷) or 5 (˜).
The display will show the chosen mode:
❒“00 MIN”: deactivation dependent on ignition key.
Sound system will switch off automatically when
turning the ignition key to OFF;
❒“20 MIN”: deactivation independent of ignition key.
After having turned the ignition key to OFF, the
sound system will stay on for 20 minutes max.

47
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
The TPM function cannot be activated if no track
sequence has been set. Pressing button 17 (1-TPM) the
display will show “NO TPM AVAILABLE”.
To store tracks,select the track required, then keep
button 17 (1-TPM) pressed until hearing the beep; the
display will show “TRACK IS STORED”. Repeat this
procedure for all the other tracks to be stored.
IMPORTANT It is possible to store max. 40 tracks per
CD.
CLR function
(clearing CD track storage)
With the CLR (Clear) function it is possible:
❒to clear only one or all CD tracks stored with the
TPM function.
❒to clear the tracks stored with the TPM function
from all the CDs contained in the CD Changer.To clear one track,select it with buttons 7 (÷) or 5
(
˜) when the TPM function is on, then keep button
16 (2-CLR) pressed for about 3 seconds. The TPM
function is turned off, a beep is heard and the display
shows “ONE TRACK DELETED”.
To clear all the tracks stored of a CD, insert the
required CD, turn on the TPM function then press
button 16 (2-CLR) for about 6 seconds. The TPM
function is turned off, a double beep is heard after
about 2 and 4 seconds and the display shows “ALL
TRACKS DELETED”.
To clear all the tracks of all the CDs contained in the
CD changer, press button 16 (2-CLR) for over 8
seconds. Three beeps are heard after about 2, 4 and 8
seconds and the display shows “COMPLETE TPM
CLEARED”.

52
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
TPM function (CD playing sequence storage)
With the TPM function (Track Program Memory) it is
possible to store the sequence for playing tracks of a
CD, to be able to play them later in the sequence set.
To turn the function on briefly press button
17 (1-TPM), while listening to a CD. When the
function is on, the display shows “TPM ON”. After
playing the track, the display will show again the word
“TPM ON” for about 2 seconds.
The TPM function cannot be activated if no track
sequence has been set. Pressing button 17 (1-TPM) the
display will show “NO TPM AVAILABLE”.
To store tracks, select the track required, then keep
button 17 (1-TPM) pressed until hearing the beep; the
display will show “TRACK IS STORED”. Repeat this
procedure for all the other tracks to be stored.
IMPORTANT It is possible to store max. 40 tracks per
CD.CLR function
(clearing CD track storage)
With the CLR (Clear) function it is possible:
❒to clear only one or all CD tracks stored with the
TPM function;
❒to clear the tracks stored with the TPM function
from all the CDs contained in the CD Changer.
To clear one track, select it with buttons 7 (
÷) or
5 (
˜) when the TPM function is on, then keep button
16 (2-CLR) pressed for about 3 seconds.
The TPM function is turned off,a beep is heard and
the display shows “ONE TRACK DELETED”.
To clear all the tracks stored of a CD, insert the
required CD, turn on the TPM function then press
button 16 (2-CLR) for about 6 seconds. The TPM
function is turned off, a double beep is heard after
about 2 and 4 seconds and the display shows “ALL
TRACKS DELETED”.
To clear all the tracks of all the CDs contained in the
CD changer, press button 16 (2-CLR) for over 8
seconds. Three beeps are heard after about 2, 4 and 8
seconds and the display shows “COMPLETE TPM
CLEARED”.

56
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
1
2
3
4
5
6
7
8
9
10
SOURCE-SCAN
Display
N
˚
˜
O
÷
6-MP3 |
AUDIO-LOUDNESS
5-MIXSelect audio source/Scan function
Manual station tuning
Eject CD
Manual station tuning
Automatic station tuning
Manual station tuning
Audio settings 6/
MP3 INFO function
Audio settings/Loudness
Audio settings 5/MIX functionSelect CD, CD Changer
(if installed) or Radio
Manual station tuning
TP: seek +
PTY: seek -
AF: seek +
Eject CD
Manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Automatic station tuning
TP: seek -
PTY: seek -
AF: seek -
Manual station tuning
TP: seek -
PTY: seek -
AF: seek -
FM/AM:call preset
station 6
Bass (B)
Treble (T)
Fader (F)
Balance (B)
FM/AM: call preset
station 5FM/AM station scan
Fast manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Fast manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Fast automatic station tuning
TP: seek -
PTY: seek -
AF: seek -
Fast manual station tuning
TP: seek -
PTY: seek -
AF: seek -
FM/AM: store preset
station 6
Loudness
on/off
FM/AM: store preset
station 5
ButtonButtons and front panel
Letters or symbol FunctionRADIO mode
Short-push function (less than 2 sec.) Long-push function (over 2 sec.)

58
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
11
12
13
14
15
16
17
18
19
20
4-RPT
MENU-PRESET SCAN
BAND-AUTOSTORE
3-II
AF-TA
2-CLR
1-TPM
PTY
ON/OFF VOLUME
CD slotPreset station 4/REPEAT function
Menu function/Scan function
Frequency band selection
Preset station 3/Playing pause
Alternative frequency (AF)/Traffic
information (TA)
Preset station 2/CLR function
(CD track storage clearing)
Preset station 1/TPM function
(CD track sequence storing)
Programme Type
Radio on/off/
Volume adjustmentFM/AM: call preset station 4
Menu on/off
MF1, FM2, FMT, MW, LW
FM/AM: call preset station 3
TA ON/OFF
FM/AM: call preset station 2
FM/AM: call preset station 1
PTY ON/OFF
With radio on: Audio Mute on/off
With radio off: radio on
Volume adjustment:
turn leftwards: to decrease
turn rightwards: to increaseFM/AM: store preset station 4
Scan preset stations
AF ON/OFF
FM/AM: store preset station 3
AF ON/OFF
FM/AM: store preset station 2
FM/AM: store preset station 1
PTY: displays selected programme
type
With radio on:radio off
With radio off:radio on
ButtonButtons and front panel
Letters or symbol FunctionRADIO mode
Short-push function (less than 2 sec.) Long-push function (over 2 sec.)

67
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
MENU
Functions of button 12 (MENU-PRESET SCAN)
To activate the menu function, briefly press button 12
(MENU-PRESET SCAN). The display shows the word
“MENU”.
To scroll the menu functions use buttons 3 (
N) or 6
(
O). To change the setting of the function selected,
use buttons 7 (
÷) or 5 (˜).
The display will show the current status of the
function selected.
The functions controlled by the menu are the
following:
❒PRESET/USER/CLASSIC/ROCK/JAZZ (turning
on/off and choosing predefined equalizer
adjustments);
❒USER EQ SETTINGS (equalizer setting, only if USER
equalizer setting has been selected);
❒REGIONAL MODE (regional programmes);
❒CD DISPLAY (CD data display);
❒MP3 DISPLAY (MP3 CD data display);
❒CDC DISPLAY (CD Changer data display, if
installed); MP3 Info function (directory data info)
Press briefly button 8 (6-MP3
|) to display the name
of the current directory: the display will show the
name of the currently selected directory for about
5 seconds. Then the previously selected CD mode
will be displayed again.
If button 8 (6-MP3
|) is pressed again during
directory name displaying, the name of the MP3
track being played will be displayed twice for about
5 seconds. Then the previously selected CD mode
will be displayed again.
