2004 DODGE RAM 2500 DIESEL headlight bulb

Headlamp Delay Ð If Equipped
To aid in your exit, your vehicle, if equipped, can be
programmed by your dealer with a headlamp delay that
will leave the headlamps on for 0, 30, 60, or 90 seconds.
This delay is initiated when the ignition is turned OFF
while the headlamp switch is on, and then the headlamp
switch is cycled off. The headlamps will remain on for 60
seconds. Headlamp delay can be cancelled by either
turning the headlamp switch ON then OFF or by turning
the ignition ON.
Headlights, Parking Lights, Panel Lights
When the headlight switch is rotated to the first
position, the parking lights, taillights, side marker
lights, license plate light and instrument panel
lights are all turned on. Rotating the headlight switch to
the first position will also turn on the cab top clearance
lights, flare lights, and tailgate lights if the vehicle is
equipped with these lights. The headlights will turn ON
when the switch is rotated to the second position. The9LAMP OUT9indicator will be illuminated in the instru-
ment cluster if a defective bulb or wiring circuit is
detected for the headlamp system.
Your vehicle is equipped with plastic headlight lenses
that are lighter and less susceptible to stone breakage
than glass headlights.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

7. Seat Belt Reminder Light
When the ignition switch is first turned ON, this
light will turn on for 5 to 8 seconds as a bulb check.
During the bulb check, if the driver's seat belt is
unbuckled, a chime will sound. After the bulb check or
when driving, if the driver seat belt remains unbuckled,
the Seat Belt Warning Light will flash or remain on
continuously. Refer to9Enhanced Driver Seat Belt Re-
minder System (BeltAlertŸ)9in the Occupant Restraints
section for more information.
8. Speedometer
The speedometer shows the vehicle speed in miles per
hour and/or kilometers per hour.
9. Oil Pressure Gauge
The pointer should always indicate some oil pres-
sure when the engine is running. A continuous
high or low reading, under normal driving conditions,
may indicate a lubrication system malfunction. Immedi-
ate service should be obtained.NOTE:If the gauge pointer moves to either extreme of
the gauge, the ªCheck Gagesº indicator will illuminate
and a single chime will sound.
10. Cargo Lamp
The Cargo Lamp light will illuminate when the Cargo
Lamp is activated from the dimmer control switch,
located next to the headlight switch.
11. Door Ajar
The Door Ajar light will illuminate when any
door is opened. When the ignition is ON the
Door Ajar light will stay illuminated until the
open door is closed. When the ignition is OFF
the Door Ajar light will stay illuminated until the open
door is closed or the battery saver feature automatically
turns the light off.
UNDERSTANDING YOUR INSTRUMENT PANEL 145
4

mReplacement Light Bulbs.................367
mBulb Replacement......................367
NHeadlight (Halogen)/Front Park And Turn
Lights.............................367
NTail, Stop, Turn And Backup Lights.........371
NCenter High-Mounted Stoplight With Cargo
Light..............................373
NCab Top Clearance Lights Ð If Equipped....375
NTailgate ID Lights (Dual Rear Wheels).......376NSide Marker Lights (Dual Rear Wheels)......378
NFog Lights..........................378
mFluid Capacities........................379
mRecommended Fluids, Lubricants And Genuine
Parts................................380
NEngine.............................380
NChassis............................381
MAINTAINING YOUR VEHICLE 319
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Inside Bulb No.
Overhead Console Lights............... TS212-2
Dome Light............................7679
All of the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved.
LIGHT BULBS Ð Outside Bulb No.
Back-Up..............................3057
Center High Mounted Stop Lamp............. 912
Fog Lamp...........................9006LL
Headlamp (Halogen)...................9007QL
Park & Turn Signal...................3157NAK
Rear License Plate Lamp................... 168
Rear Cargo Light......................... 912
Tail & Stop............................3057
Cab Clearance Lights...................... 168
Dual Rear Wheel Sidemarker Light............ 168
Dual Rear Wheel Tailgate ID Lights (3)......... 168
BULB REPLACEMENT
Headlight (Halogen)/Front Park and Turn Lights
CAUTION!
This is a halogen bulb. Avoid touching the glass
with your fingers. Reduced bulb life will result.
1. Remove the expanding fastener from the headlight
welt.
MAINTAINING YOUR VEHICLE 367
7

3. Pull the housing out from the fender to allow room to
disconnect the electrical connectors.
4. Unlock and pull connector straight from the base of
the headlight halogen bulb.
370 MAINTAINING YOUR VEHICLE

5. Twist connector on turn signal/park light bulb1¤4turn
and remove connector and bulb from housing.
6. Remove housing from vehicle with headlight halogen
bulb in housing.
7. Twist collar on headlight halogen bulb
1¤4turn and
remove headlight bulb from the housing.
8. Replace headlight or turn signal bulb. Do not touch
the headlight halogen bulb.
9. Reverse procedure for installation of bulbs and hous-
ing.
10. Tighten the outboard fastener first.
Tail, Stop, Turn and Backup Lights
1. Remove the two (2) screws that pass through the bed
sheetmetal.
MAINTAINING YOUR VEHICLE 371
7

Jack Location........................... 298
Jack Operation.......................... 300
Jump Starting.......................... 310
Key, Replacement........................ 12
Key, Sentry............................. 11
Key-In Reminder......................... 11
Keyless Entry System...................... 22
Keys................................ 11,16
Lane Change and Turn Signals.............. 103
Lap Belts.............................. 42
Lap/Shoulder Belts....................... 34
LATCH (Lower Anchors and Tether for CHildren) . 59
Lights...............................70,99
Airbag............................55,144
Anti-Lock Warning..................146,242
Battery Saver......................... 100
Brake Warning........................ 147Bulb Replacement...................... 367
Cap Top Clearance..................... 375
Center Mounted Stop................... 373
Check Engine......................... 143
Courtesy/Reading..................... 113
Cruise.............................. 147
Daytime Running...................... 102
Dual Wheel Assembly Rear............... 376
Fog .............................102,378
Four-Wheel Drive Indicator............... 230
Hazard Warning Flasher................. 296
Headlights........................... 101
High Beam........................104,144
High Beam Indicator.................... 144
High Beam/Low Beam Select............. 104
Instrument Cluster..................... 143
Intensity Control....................... 100
Interior...........................99,113
Lights On Reminder.................... 102
418 INDEX
