2004 DODGE DAKOTA Owners Manual

NManual Compass Calibration..............80
NOutside Temperature....................81
mGarage Door Opener....................81
NProgramming Homelink.................82
NCanadian Programming/Gate Programming . . .84
NUsing Homelink.......................85
NErasing Homelink Buttons................85
NReprogramming a Single Homelink Button....85
NSecurity.............................85
mElectrical Power Outlets Ð If Equipped......86
NElectrical Outlet Use With Engine Off........87
mFloor Console Ð If Equipped..............88
NFloor Console Features..................88
mCenter Storage Compartment Ð If Equipped...89
mCup Holders..........................89
mTailgate..............................90
mSlide-In Campers.......................90
NCamper Applications....................90
NGeneral Information....................91
NCarbon Monoxide Warning Vehicles Equipped
With A Cap Or Slide-In Campers...........91
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

MIRRORS
Inside Day/Night Mirror
The mirror should be adjusted to center on the view
through the rear window. A two-point pivot system
allows for horizontal and vertical adjustment of the
mirror.Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of truck). The mirror should be adjusted
while set in the day position (toward windshield).
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Automatic Dimming MirrorÐ If Equipped
This mirror will automatically adjust for annoying head-
light glare from vehicles behind you. You can turn the
feature on or off by pressing the button at the base of the
mirror. A light in the button will indicate when the
dimming feature is activated.CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic with a slight
overlap of the view obtained on the inside mirror.
Exterior Mirrors Folding Feature
Folding exterior mirrors are hinged and may be moved
either forward or rearward to resist damage. The hinges
have three detent positions; full forward, full rearward,
and normal.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

Electric Remote-Control Mirrors
The controls for the power mirrors are located on the
driver's door trim panel.Set the top switch to the left or right for the left or right
mirror, and set it to the center off position to prevent
accidentally moving a mirror when you are finished
adjusting the mirror. To adjust a mirror, select left or right
with the top switch, and press one of the four arrows for
the direction you want the mirror to move.
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in the
right side mirror.
Heated Mirrors Ð If Equipped
Heated mirrors are automatically activated when you
depress the rear window defroster switch located on the
instrument panel. The light will illuminate to indicate
that the heating elements are ON. Turning OFF the
ignition will deactivate the heated mirrors.
SEATS
Seat Adjustment
The adjusting lever is at the front of the seat, near the
floor. Lift the lever and move the seat to the desired
position.
Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3

WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured. Adjust
any seat only while the vehicle is parked.
Reclining Seats
Both the bucket seats and the split-bench seats are
equipped with recliners. The reclining mechanism is
operated by a control located on the outboard side of the
seat. To recline, lean forward slightly before lifting the
lever, then push back to the desired angle and release the
lever. Lean forward and lift the lever to return the
seatback to its normal position.
WARNING!
Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt and
be seriously or even fatally injured. Use the recliner
only when the vehicle is parked.
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6 - Way Power Seat Adjuster Ð Driver's Side
Only
The 6-way power seat adjuster switch is on the outboard
side of the driver's seat. Use this switch to move the seat
up or down, forward or rearward, recline or tilt.
Lumbar Support Adjustment Ð Power Seats Only
Vehicles equipped with the power bucket seat or the
40/20/40 split bench power are equipped with an adjust-
able lumbar support on the driver's seat. Rotating the
lever on the left side of the driver's seatback increases or
decreases the lumbar support.
Seatback Releases Ð Bench Seat
The seatback is equipped with inertia latching mecha-
nisms that automatically lock and prevent the seatback
from folding forward during periods of high decelera-
tion, such as hard braking.
This type of latch mechanism eliminates the need to
actuate a release lever to fold the seat forward. In some
situations, such as when parked on a steep hill, the inertia
latch may lock and manual release of the lock will be
necessary.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
3

Seatback ReleasesÐBucket And Split Bench
Both seats have a position latch release. To release the
seatback if you are on the outside of the vehicle, lift up on
the recliner lever located on the outboard side of the seat.
From the rear seat, lift the lever located on the rear of the
seatback.
Club Cab Easy Entry System
To allow easier access to the rear seat, the front passenger
seat will move to its full forward position when the
seatback is folded down. To fold the seatback forward if
you are on the outside of the vehicle, lift up on therecliner lever located on the outboard side of the seat.
From the rear seat, pull the cloth pull-tab located on the
rear or the seat cushion rearward until the latch releases,
and then push the seat forward. The seat will lock in
place when the back is returned to an upright position
and will need to be reset. However, the seat may be slid
rearward before returning the seatback to the upright
position to minimize the amount of readjustment re-
quired.
NOTE:Power seats are available with the Club or Quad
Cab models only.
CAUTION!
When operating the folding front seat, use care in
repositioning seat to its normal position. This will
prevent shoulder belt harness from being caught
behind seat or tangled in the seatback latching
mechanism.
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
