SECTION 3
WIRING DIAGRAM FOR POWER SUPPLIES
CONTENTS
1. IGNITION SWITCH CIRCUIT3–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. 30 TER ”BAT+” POWER SUPPLY CIRCUIT(I.P FUSE BLOCK) 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. 15 TER ”IGN 1” POWER SUPPLY CIRCUIT(I.P FUSE BLOCK) 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4. 15A TER ”IGN2”, 15C TER ”ACC” POWER SUPPLY CIRCUIT(I.P FUSE BLOCK) 3–4. . . . . . . . . . . . . . . . . . . . . .
5. ENGINE FUSE BLOCK & RELAY CIRCUIT 3–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 975 of 2643
3–2WWIRING DIAGRAM FOR POWER SUPPLIES
1. IGNITION SWITCH CIRCUIT2. 30 TER ”BAT+” POWER SUPPLY CIRCUIT (I.P FUSE BLOCK)
Page 976 of 2643
WIRING DIAGRAM FOR POWER SUPPLIESW3–3
3. 15 TER ”IGN1” POWER SUPPLY CIRCUIT (I.P FUSE BLOCK)
Page 977 of 2643
3–4WWIRING DIAGRAM FOR POWER SUPPLIES
4. 15A TER ”IGN2”, 15C TER ”ACC” POWER SUPPLY CIRCUIT (I.P FUSE
BLOCK)
Page 978 of 2643
WIRING DIAGRAM FOR POWER SUPPLIESW3–5
5. ENGINE FUSE BLOCK & RELAY CIRCUIT
Page 979 of 2643
3–6WWIRING DIAGRAM FOR POWER SUPPLIES
Page 980 of 2643
WIRING DIAGRAM FOR POWER SUPPLIESW3–7
Page 981 of 2643
3–8WWIRING DIAGRAM FOR POWER SUPPLIES
