Page 211 of 516
Outlet Adjustment
Use the knob located in the center of the outlet, to
change the direction of the air ow.
Operation Tips
Clear away any ice, snow or leaves from the air
inlets on the hood that may block the ow of air
into your vehicle.
Use of non-GM approved hood de ectors may
adversely affect the performance of the system.
Keep the path under the front seats clear of objects
to help circulate the air inside your vehicle more
effectively.
Rear Climate Control System
(Without Entertainment System)
Your vehicle may have a rear climate control system
that allows the driver to adjust the fan speed or a
rear-seat passenger to set a separate temperature and
adjust the fan speed, for the rear seating area. This
system works with the main climate control system in
your vehicle.
This knob is located below
the main climate control
system on the instrument
panel switchbank. Use
this knob to adjust the fan
speed for the rear seat
passengers.
3-29
Page 213 of 516
9(Fan):Turn the fan knob on either rear fan control
to numeral 1, 2, or 3 to increase or decrease air ow
to the rear seating area. Turn the fan knob on either rear
fan control to 0 or OFF to turn off the fan.
Temperature Control:If the driver is adjusting the
temperature, increase or decrease the temperature for
the entire vehicle using the temperature controls located
on the main climate control panel. The air-conditioning
system must be on to direct cooled air to the rear of the
vehicle. If it is not on, the temperature in the rear of the
vehicle will remain at cabin temperature.
If a rear seat passenger is adjusting the temperature,
turn the right knob, located overhead on the control panel
behind the driver’s seat, clockwise or counterclockwise
to raise or lower the temperature in the rear seating
area only.Rear Air Outlets
To increase air ow through the rear oor outlets, place
the left bucket seat in the second row in the forward
position. For more information, seeRear Seat Operation
on page 1-6.
The outlet behind the left rear seat is the cold air return
outlet. Be sure to keep it free from obstructions.
Also, keep the area around the base of the center
instrument panel console, between and under the front
seats, free of objects that could also obstruct air ow
to the rear seating area.
For more information on how to use the main climate
control system, see “Climate Control System” listed
previously in this section. For information on ventilation,
see “Outlet Adjustment” under “Climate Control
System” listed previously in this section.
3-31
Page 215 of 516
9(Fan):If the driver is adjusting the fan speed, use
this control. Turn the fan knob on the rear fan control
located below the main climate control system on
the switchbank to numeral 1, 2, or 3 to increase or
decrease air ow to the rear seating area. Turn the fan
knob on the rear fan control to 0 to turn off the fan.
FAN:If a rear-seat passenger is adjusting the fan
speed, use this control. Press the FAN button on the
rear control panel. The display will show the current
setting. Press the left and right arrow buttons to cycle
through the available settings of OFF, LOW, MED,
and HIGH.
Temperature Control:If the driver is adjusting the
temperature, increase or decrease the temperature for
the entire vehicle using the temperature controls
located on the main climate control panel. The
air-conditioning system must be on to direct cooled air
to the rear of the vehicle. If it is not on, the temperature
in the rear of the vehicle will remain at cabin
temperature.
If a rear-seat passenger is adjusting the temperature,
press the TEMP button on the rear control panel.
Use the left arrow button to make the air cooler. Use
the right arrow button to make the air warmer.Rear Air Outlets
To increase air ow through the rear oor outlets, place
the left bucket seat in the second row in the forward
position. For more information, seeRear Seat Operation
on page 1-6.
The outlet behind the left rear seat is the cold air return
outlet. Be sure to keep it free from obstructions.
Also, keep the area around the base of the center
instrument panel console, between and under the front
seats, free of objects that could also obstruct air ow
to the rear seating area.
For more information on how to use the main climate
control system, see “Climate Control System” listed
previously in this section. For information on ventilation,
see “Outlet Adjustment” under “Climate Control
System” listed previously in this section.
3-33
