16. From the upright position, push down on the outer
area of the boot cover panel where the hinges and
hydraulic cylinders are located to separate it
from the roof tonneau. Then, continue to push the
boot cover panel down as far as it will go.17. Push down the roof tonneau cover. Be sure the
boot cover clears the rear roof panel.
18. Latch the tonneau panel. Pull the red cable with the
release tool until the cable is pulled tight and the
roof tonneau latch engages.Boot cover panel down, roof tonneau up
2-51

19. Repeat Step 18 on the other side of the vehicle.
20. You will know the latches are engaged if the
roof tonneau cannot be raised. If the roof tonneau
can be raised, repeat Step 18 on both sides of
the vehicle until the roof tonneau cannot be raised.
21. Once the roof tonneau is closed, adjust the cables
located behind the seats. Pull the cable with the red
band until both cables are the same length.
Repeat this step on the other side of the vehicle.
22. Check the roof tonneau to make sure it is secure
before driving.Vehicle Personalization
Memory Seat
Your vehicle may have a memory driver’s seat. The
controls are located on the outboard of the driver’s seat,
and are used to program and recall memory settings
for the driver’s seating positions.
2-52

Adjust the driver’s seat to the desired position. Press
the SET button, then press and hold button 1 (for
Driver 1) for three seconds. A double chime will sound
to let you know that the position has been stored.
A second seating position can be programmed by
repeating the procedure with a second driver and
pressing button 2 for three seconds. Each time button 1
or 2 is pressed and released while the vehicle is in
PARK (P), a single chime will sound, and the memory
position will be recalled.
If you use the unlock button on the remote keyless entry
transmitter to enter your vehicle, the preset driver’s
seat positions will be recalled if programmed to do so
through the Driver Information Center (DIC). The
numbers on the back of the transmitters, 1 or 2,
correspond to the numbers on the memory controls.The seat positions can also be recalled by placing the
key in the ignition if programmed to do so through
the Driver Information Center (DIC).
To stop recall movement of the memory feature at any
time, press one of the power seat controls or memory
buttons.
Further programming for automatic seat can be done
through the Driver Information Center (DIC). See
DIC Vehicle Personalization on page 3-55for more
information.
2-53

✍NOTES
2-54

Instrument Panel Overview...............................3-2
Hazard Warning Flashers................................3-3
Other Warning Devices...................................3-4
Horn.............................................................3-4
Tilt Wheel.....................................................3-5
Turn Signal/Multifunction Lever.........................3-5
Exterior Lamps.............................................3-12
Interior Lamps..............................................3-15
Center Console Switchbank............................3-17
Accessory Power Outlets...............................3-17
Ashtrays and Cigarette Lighter........................3-18
Climate Controls............................................3-19
Climate Control System.................................3-19
Outlet Adjustment.........................................3-22
Warning Lights, Gages, and Indicators............3-23
Instrument Panel Cluster................................3-24
Speedometer and Odometer...........................3-25
Trip Odometer..............................................3-25
Tachometer.................................................3-25
Safety Belt Reminder Light.............................3-26
Air Bag Readiness Light................................3-26
Air Bag Off Light..........................................3-28
Charging System Light..................................3-29
Brake System Warning Light..........................3-30
Anti-Lock Brake System Warning Light.............3-31Traction Control System (TCS) Warning Light . . .3-31
Engine Coolant Temperature Gage..................3-32
Malfunction Indicator Lamp.............................3-32
Oil Pressure Gage........................................3-36
Change Engine Oil Light................................3-37
Security Light...............................................3-37
Cruise Control Light......................................3-38
Reduced Engine Power Light.........................3-38
Highbeam On Light.......................................3-39
Check Gages Warning Light...........................3-39
Fuel Gage...................................................3-40
Auxiliary Gage Package.................................3-41
Driver Information Center (DIC).......................3-44
DIC Controls and Displays.............................3-44
DIC Warnings and Messages.........................3-48
DIC Vehicle Personalization............................3-55
Audio System(s).............................................3-61
Setting the Time...........................................3-61
Radio with CD..............................................3-62
Radio with Six-Disc CD.................................3-71
Theft-Deterrent Feature..................................3-85
Audio Steering Wheel Controls.......................3-86
Radio Reception...........................................3-87
Care of Your CDs.........................................3-87
Care of Your CD Player................................3-87
Integrated Windshield Antenna........................3-87
Section 3 Instrument Panel
3-1

Instrument Panel Overview
3-2

A. Climate Control Vents. SeeClimate Control System
on page 3-19.
B. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-24.
C. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-5.
D. Exterior and Interior Lamps Control. SeeExterior
Lamps on page 3-12andInterior Lamps on
page 3-15.
E. Driver Information Center (DIC) buttons. SeeDriver
Information Center (DIC) on page 3-44.
F. Audio Steering Wheel Controls. SeeAudio Steering
Wheel Controls on page 3-86.
G. Storage Tray. SeeInstrument Panel Storage Area
on page 2-30.
H. Audio System. SeeAudio System(s) on page 3-61.
I. Climate Control System. SeeClimate Control
System on page 3-19.
J. Transmission Shift Lever. SeeAutomatic
Transmission Operation on page 2-16.
K. Cupholder. SeeCupholder(s) on page 2-30.
L. Glovebox. SeeGlove Box on page 2-30.Hazard Warning Flashers
Your hazard warning ashers let you warn others. They
also let police know you have a problem. Your front
and rear turn signal lamps will ash on and off.
3-3

The hazard warning
asher button is located on
the top of the steering
column.
Your hazard warning ashers work no matter what
position your key is in, and even if the key isn’t in.
Press the button to make the front and rear turn signal
lamps ash on and off. Press the button again to
turn the ashers off.
When the hazard warning ashers are on, your turn
signals won’t work. The ashers will stop if you step on
the brake.Other Warning Devices
If you carry reective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind your
vehicle.
Horn
To sound the horn, press the horn symbol on the
steering wheel pad.
3-4
