2004 CHEVROLET SILVERADO light

Electrical System
Add-On Electrical Equipment
Notice:Don’t add anything electrical to your vehicle
unless you check with your dealer rst. Some
electrical equipment can damage your vehicle and
the damage wouldn’t be covered by your warranty.
Some add-on electrical equipment can keep other
components from working as they should.
Your vehicle has an air bag system. Before attempting
to add anything electrical to your vehicle, see
Servicing Your Air Bag-Equipped Vehicle on page 1-83.
Windshield Wiper Fuses
The windshield wiper motor is protected by an internal
circuit breaker and a fuse. If the motor overheats due to
heavy snow, etc., the wiper will stop until the motor
cools. If the overload is caused by some electrical
problem and not snow, etc., be sure to get it xed.
Power Windows and Other Power
Options
Circuit breakers protect the power windows and other
power accessories. When the current load is too heavy,
the circuit breaker opens and closes, protecting the
circuit until the problem is xed or goes away.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links. This greatly reduces the
chance of res caused by electrical problems.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical
size and rating.
If you ever have a problem on the road and don’t have
a spare fuse, you can borrow one that has the same
amperage. Just pick some feature of your vehicle
that you can get along without – like the radio or
cigarette lighter – and use its fuse, if it is the correct
amperage. Replace it as soon as you can.
5-123

Fuses Usage
4WSVent Solenoid
Canister/Quadrasteer
Module Power
RR HVAC Not Used
AUX PWRAuxiliary Power
Outlet — Console
IGN 1 Ignition Relay
PCM 1 Powertrain Control Module
ETC/ECMElectronic Throttle Control,
Electronic Brake Controller
IGN EInstrument Panel Cluster, Air
Conditioning Relay, Turn
Signal/Hazard Switch,
Starter Relay
RTD Ride Control
TRL B/U Backup Lamps Trailer Wiring
PCM BPowertrain Control Module,
Fuel Pump
F/PMP Fuel Pump (Relay)
B/U LPBack-up Lamps, Automatic
Transmission Shift Lock
Control System
RR DEFOG Rear Window DefoggerFuses Usage
HDLP-HI Headlamp High Beam Relay
PRIME Not Used
02B Oxygen Sensors
SIRSupplemental Inatable
Restraint System
FRT PARKFront Parking Lamps,
Sidemarker Lamps
DRLDaytime Running
Lamps (Relay)
SEO IGN Rear Defog Relay
TBC IGN1 Truck Body Controller Ignition
HI HDLP-LT High Beam Headlamp-Left
LH HID Not Used
DRL Daytime Running Lamps
IPC/DICInstrument Panel Cluster/
Driver Information Center
HVAC/ECAS Climate Control Controller
CIG LTR Cigarette Lighter
HI HDLP-RT High Beam Headlamp-Right
HDLP-LOW Headlamp Low Beam Relay
A/C COMP Air Conditioning Compressor
5-130

Maintenance Footnotes
†The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to
the completion of the vehicle’s useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the
maintenance be recorded.
#Lubricate the front suspension, ball joints, steering
linkage, transmission shift linkage and parking
brake cable guides. Ball joints should not be lubricated
unless their temperature is 10°F (-12°C) or higher,
or they could be damaged. Vehicles used under severe
commercial operating conditions require lubrication
on a regular basis every 3,000 miles (5 000 km).
(a)Visually inspect brake lines and hoses for proper
hook-up, binding, leaks, cracks, chang, etc. Inspect
disc brake pads for wear and rotors for surface
condition. Inspect other brake parts, including calipers,
parking brake, etc.
(b)Visually inspect front and rear suspension and
steering system for damaged, loose or missing parts,
signs of wear or lack of lubrication. Inspect power
steering lines and hoses for proper hook-up, binding,
leaks, cracks, chang, etc. Visually check constant
velocity joints, rubber boots and axle seals for leaks.(c)Visually inspect hoses and have them replaced if
they are cracked, swollen or deteriorated. Inspect all
pipes, ttings and clamps; replace with genuine GM parts
as needed. To help ensure proper operation, a pressure
test of the cooling system and pressure cap and cleaning
the outside of the radiator and air conditioning condenser
is recommended at least once a year.
(d)Visually inspect wiper blades for wear or cracking.
Replace blade inserts that appear worn or damaged
or that streak or miss areas of the windshield.
(e)Make sure the safety belt reminder light and all your
belts, buckles, latch plates, retractors and anchorages
are working properly. Look for any other loose or
damaged safety belt system parts. If you see anything
that might keep a safety belt system from doing its
job, have it repaired. Have any torn or frayed safety belts
replaced. Also look for any opened or broken air bag
coverings, and have them repaired or replaced. (The air
bag system does not need regular maintenance.)
(f)Lubricate all key lock cylinders, body door hinges,
hood latch assembly, secondary latch, pivots, spring
anchor, release pawl, tailgate hinges, tailgatelinkage,
tailgate handle pivot points, latch bolt, fuel door
hinge, locks and folding seat hardware. More frequent
lubrication may be required when exposed to a corrosive
environment. Applying silicone grease on weatherstrips
with a clean cloth will make them last longer, seal
better and not stick or squeak.
6-8

A
Accessory Power Outlets.................................3-19
Adding a Snow Plow or Similar Equipment.........4-63
Adding Washer Fluid.......................................5-48
Additional Program Information........................... 7-9
Additives, Fuel................................................. 5-7
Add-On Electrical Equipment...........................5-123
Add-On Equipment..........................................4-62
Adjusting the Speakers
(Balance/Fade)..................3-75, 3-79, 3-90, 3-104
After Off-Road Driving.....................................4-35
Air Bag
Off Light.....................................................3-37
Passenger Status Indicator...........................3-40
Readiness Light..........................................3-36
Air Bag Systems.............................................1-67
Adding Equipment to Your Air Bag-Equipped
Vehicle...................................................1-83
Air Bag Off Switch.......................................1-73
How Does an Air Bag Restrain?....................1-71
Passenger Sensing System...........................1-78
Servicing Your Air Bag-Equipped Vehicle.........1-83
What Makes an Air Bag Inate?....................1-71
What Will You See After an Air Bag Inates?......1-72
When Should an Air Bag Inate?...................1-70
Where Are the Air Bags?..............................1-68
Air Cleaner/Filter, Engine.................................5-25
Air Conditioning..............................................3-30
Airbag Sensing and Diagnostic Module (SDM)...... 7-9All-Wheel Drive...............................................5-58
All-Wheel Drive (AWD) System.........................2-48
AM .............................................................3-128
AM-FM Radio.................................................3-73
Antenna, Fixed Mast......................................3-130
Antenna, XM™ Satellite Radio
Antenna System........................................3-130
Anti-lock Brake System..................................... 4-6
Anti-Lock Brake, System Warning Light..............3-44
Appearance Care..........................................5-114
Care of Safety Belts...................................5-117
Chemical Paint Spotting..............................5-120
Cleaning the Inside of Your Vehicle..............5-114
Cleaning the Outside of Your Vehicle............5-117
Finish Damage..........................................5-120
Sheet Metal Damage..................................5-120
Underbody Maintenance.............................5-120
Vehicle Care/Appearance Materials...............5-121
Weatherstrips............................................5-117
Approaching a Hill..........................................4-28
Ashtrays........................................................3-20
Audio Output................................................3-116
Audio System(s).............................................3-72
AM-FM Radio.............................................3-73
Audio Steering Wheel Controls....................3-127
Care of Your Cassette Tape Player...............3-129
Care of Your CD and DVD Player................3-130
Care of Your CDs and DVDs.......................3-130
Chime Level Adjustment.............................3-130
Fixed Mast Antenna...................................3-130
1

Audio System(s) (cont.)
Radio with Cassette and CD.........................3-86
Radio with CD............................................3-76
Radio with Six-Disc CD..............................3-100
Rear Seat Audio (RSA)...............................3-125
Setting the Time for Radios with Radio Data
Systems (RDS)........................................3-73
Setting the Time for Radios without Radio
Data Systems (RDS)................................3-72
Theft-Deterrent Feature...............................3-127
Understanding Radio Reception...................3-128
XM™ Satellite Radio Antenna System...........3-130
Automatic Dimming Mirror Operation..........2-56, 2-58
Automatic Headlamp System............................3-14
Automatic Transfer Case..................................2-40
Automatic Transmission...................2-24, 2-49, 2-51
Fluid..................................................5-27, 5-30
Operation...................................................2-27
Auxiliary Battery............................................4-100
Auxiliary Roof Mounted Lamp Switch.................3-17
B
Backing Up....................................................4-92
Battery..........................................................5-52
BATTERY NOT CHARGING.............................3-64
Battery Replacement......................................... 2-6
Battery Run-Down Protection............................3-19
Battery Warning Light......................................3-42Before Leaving on a Long Trip.........................4-42
Before You Drive...........................................3-114
Before You Go Off-Roading..............................4-23
Brake
Parking......................................................2-48
System Warning Light..................................3-43
Brake Adjustment............................................5-51
Brake Fluid....................................................5-49
Brake Pedal Travel.........................................5-51
Brake Wear...................................................5-51
Brakes..........................................................5-49
Braking........................................................... 4-6
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-22
BUCKLE PASSENGER....................................3-65
BUCKLE SEATBELT.......................................3-65
Bulb Replacement...........................................5-63
Center High-Mounted Stoplamp (CHMSL) and
Cargo Lamp............................................5-68
Front Turn Signal, Sidemarker and Daytime
Running Lamps........................................5-65
Halogen Bulbs............................................5-63
Headlamps.................................................5-63
Pickup Box Identication and Fender
Marker Lamps.........................................5-69
Replacement Bulbs......................................5-72
Roof Marker Lamps.....................................5-66
Taillamps....................................................5-70
Buying New Tires...........................................5-86
2

C
California Fuel.................................................. 5-6
Canada – Customer Assistance.......................... 7-5
Canadian Owners................................................ ii
Canadian Roadside Assistance........................... 7-7
Capacities and Specications..........................5-132
Car Washes for QUADRASTEER™
Equipped Vehicles.......................................4-17
Carbon Monoxide...................2-15, 2-53, 4-46, 4-70
Care of
Safety Belts..............................................5-117
Your Cassette Tape Player..........................3-129
Your CD and DVD Player...........................3-130
Your CDs and DVDs..................................3-130
Cargo Lamp...................................................3-17
CARGO LAMP ON.........................................3-65
Cassette Tape Messages.................................3-97
CD Adapter Kits.............................................3-97
CD Messages...............................3-86, 3-99, 3-113
Center Console Storage Area...........................2-68
Center High-Mounted Stoplamp (CHMSL) and
Cargo Lamp...............................................5-68
Center Instrument Panel Fuse Block................5-126
Center Passenger Position, Safety Belts.............1-24
Chains, Tires..................................................5-91
CHANGE ENGINE OIL....................................3-66
Check Engine Light.........................................3-48
CHECK OIL LEVEL.........................................3-65CHECK WASHER FLUID.................................3-65
Checking Brake Fluid......................................5-50
Checking Coolant............................................5-36
Checking Engine Oil........................................5-20
Checking Things Under the Hood......................5-12
Chemical Paint Spotting.................................5-120
Child Restraints
Child Restraint Systems...............................1-38
Infants and Young Children...........................1-34
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-47
Older Children.............................................1-32
Securing a Child Restraint Designed for the
LATCH System................................1-48, 1-49
Securing a Child Restraint in a Center Rear
Seat Position...........................................1-56
Securing a Child Restraint in a Rear Outside
Seat Position...........................................1-53
Securing a Child Restraint in the Center Front
Seat Position...........................................1-58
Securing a Child Restraint in the Right Front
Seat Position (Crew Cab)..........................1-58
Securing a Child Restraint in the Right
Front Seat Position (Regular and
Extended Cab).........................................1-61
Top Strap...................................................1-42
Top Strap Anchor Location............................1-43
Where to Put the Restraint...........................1-41
3

Chime Level Adjustment.................................3-130
Cigarette Lighter.............................................3-20
Cleaning
Inside of Your Vehicle.................................5-114
Outside of Your Vehicle..............................5-117
Underbody Maintenance.............................5-120
Weatherstrips............................................5-117
Cleaning Aluminum or Chrome-Plated Wheels.....5-119
Cleaning Exterior Lamps/Lenses......................5-118
Cleaning Fabric/Carpet...................................5-114
Cleaning Glass Surfaces................................5-116
Cleaning Interior Plastic Components...............5-116
Cleaning Leather...........................................5-116
Cleaning the Mirror.................................2-58, 2-60
Cleaning the Top of the Instrument Panel.........5-116
Cleaning the Video Screen.............................3-125
Cleaning the Windshield and Wiper Blades.......5-119
Cleaning Tires..............................................5-119
Cleaning Vinyl..............................................5-116
Climate Control System...................................3-20
Dual..........................................................3-22
Dual Automatic............................................3-25
Clutch, Hydraulic.............................................5-34
Compass Calibration...............................2-57, 2-59
Compass Operation.........................................2-59
Compass Variance..................................2-56, 2-59
Content Theft-Deterrent....................................2-20Control of a Vehicle.......................................... 4-5
Coolant
Engine Temperature Gage............................3-46
Heater, Engine............................................2-26
Surge Tank Pressure Cap.............................5-38
Cooling System..............................................5-41
Crew Cab......................................................1-56
Cruise Control................................................3-10
Cruise Control Light........................................3-51
Cupholder(s)..................................................2-67
Current and Past Model Order Forms................7-12
Customer Assistance Information
Courtesy Transportation.................................. 7-7
Customer Assistance for Text Telephone (TTY)
Users....................................................... 7-4
Customer Assistance Offices........................... 7-4
Customer Satisfaction Procedure..................... 7-2
GM Mobility Program for Persons
with Disabilities.......................................... 7-5
Reporting Safety Defects to General Motors.......7-11
Reporting Safety Defects to the Canadian
Government............................................7-11
Reporting Safety Defects to the United States
Government............................................7-10
Roadside Assistance Program......................... 7-6
Service Publications Ordering Information........7-11
4

E
Easy Exit Seat...............................................2-72
Electrical System
Add-On Equipment.....................................5-123
Fuses and Circuit Breakers.........................5-123
Power Windows and Other Power Options.......5-123
Windshield Wiper Fuses.............................5-123
Electronic Transfer Case..................................2-44
Emissions Inspection and Maintenance
Programs...................................................3-50
Engine
Air Cleaner/Filter.........................................5-25
Battery.......................................................5-52
Check and Service Engine Soon Light............3-48
Coolant......................................................5-35
Coolant Heater............................................2-26
Coolant Temperature Gage...........................3-46
Drive Belt Routing.......................................6-18
Engine Compartment Overview......................5-14
Exhaust.....................................................2-53
Fan Noise..................................................5-46
Oil .............................................................5-20
Overheating................................................5-38
Starting......................................................2-24
ENGINE COOLANT HOT.................................3-66
Engine Hour Meter Display...............................3-35
Engine Oil Additives........................................5-23
ENGINE OVERHEATED..................................3-66Entry Lighting.................................................3-18
Environmental Concerns..................................4-25
Event Data Recorders (EDR)............................. 7-9
Exit Lighting...................................................3-18
Express Down Windows..................................2-18
Extended Cab........................................1-56, 2-14
Extended Cab and Crew Cab...........................1-53
Extender, Safety Belt.......................................1-31
Exterior Lamps...............................................3-13
F
Fifth Wheel and Gooseneck Trailering................4-89
Filter
Engine Air Cleaner......................................5-25
Finding a Program Type (PTY) Station
(RDS and XM™).......................3-79, 3-90, 3-104
Finding a Station..................3-74, 3-77, 3-88, 3-102
Finish Care..................................................5-118
Finish Damage.............................................5-120
Five-Speed (VORTEC™ 4300 V6 and
4800 V8 Engines)........................................2-32
Five-Speed (VORTEC™ 6000 V8 Engine)...........2-31
Fixed Mast Antenna.......................................3-130
Flash-to-Pass................................................... 3-9
Flat Tire........................................................5-92
Flat Tire, Changing.........................................5-93
6
