Fuses Usage
DIS,
INJECTORDirect Ignition System, Injector
ABS, ENG
FUSEAntilock Brake System, Engine Fuse
AIRBAG Air Bag
HVAC
BLOWERHVAC Blower
BLANK Not Used
BLANK Not Used
BLANK Not Used
BLANK Not Used
BLANK Not Used
BLANK Not Used
CLOCK, AUDIO Clock, AudioEngine Compartment Fuse Block
The engine compartment fuse block is located on the
driver’s side of the vehicle, near the battery. SeeEngine
Compartment Overview on page 5-14for more
information on location. To access the fuses, pull out the
top and bottom flaps to release the cover. To reinstall the
cover, push the cover until it is secure.
5-87
Fuses Usage
H/L HI RH Head Lamp High Right Side
BLANK Not Used
H/L HI LH Head Lamp High Left Side
BLANK Not Used
H/L LOW RH Head Lamp Low Right Side
ILL RHParking Lamp Right Side,
Illumination Circuit
H/L LOW LH Head Lamp Low Left Side
ILL LHParking Lamp Left Side, License
Plate Lamp
ROOM LAMP Room Lamp
BLANK Not Used
DEFOG Defogger
SUN ROOF Sunroof
ILL LAMP Illumination RelayFuses Usage
HORN Horn
HEAD LAMP Headlamp
FUEL PUMP Fuel Pump
A/C COMP Air Conditioning Compressor
FRT FOG Front Fog Lamp
BLOWER Blower
ABS Antilock Brake System
IP F/BOX Instrument Panel Fuse Box
RAD’ FAN Radiator Fan
IGN 2 Ignition 2
IGN 1 Ignition 1
POWER
WINDOWPower Windows
FUSE SPARE Spare Fuse
5-89
Relays Usage
BLANK Not Used
RAD FAN LOW
RELAYRadiator Fan Low Relay
HEAD LAMP
HIGH RELAYHead Lamp High Relay
HEAD LAMP
LOW RELAYHead Lamp Low Relay
PWR WINDOW
RELAYPower Window Relay
FOG LAMP
RELAYFog Lamp Relay
MAIN
RELAY/FAN
CONTROL
RELAYMain Relay/Fan Control RelayRelays Usage
FUEL PUMP
RELAYFuel Pump Relay
A/C COMP
RELAYAir Conditioning Relay
(OPTION)
MAIN RELAYMain Relay (Option)
RAD FAN HI
RELAYRadiator Fan High Relay
ILLUMINATION
RELAYIllumination Relay
BLANK Not Used
5-90
