Discuss your needs with your trailer
sales or rental agency, and f ollow the
guidelines in the rest of this section.
Also make sure that all equipment is
properly installed and that it meets
f ederal, state, province, and local
regulations. Towing can require a variety of
equipment, depending on the size of
your trailer, how it will be used, and
how much load you are towing.
The best way to confirm that car and
trailer weights are within limits is to
have them checked at a public scale.
Using a suitable scale or a special
tongue load gauge, check the tongue
load the f irst time you set up a
towing combination (a f ully-loaded
car and trailer), then recheck the
tongue load whenever the conditions
change.
Any hitch used on your car must be
properly bolted to the underbody.
Always use saf ety chains. Make sure
they are secured to both the trailer
and hitch, and that they cross under
the tongue so they can catch the
trailer if it becomes unhitched.
Leave enough slack to allow thetrailer to turn corners easily, but do
not let the chains drag on the ground.
Acura recommends that any trailer
having a total weight of 1,000 lbs
(450 kg) or more be equipped with
its own electric or surge-type brakes.
If you choose electric brakes, be
sure they are electronically actuated.
Do not attempt to tap into your car’s
hydraulic system. No matter how
successf ul it may seem, any attempt
to attach trailer brakes to your car’s
hydraulic system will lower braking
ef f ectiveness and create a potential
hazard.
Seeyourtrailerdealerformore
inf ormation on installing electric
brakes.
CONT INUED
Towing a Trailer
Driving
Hitches
Saf et y Chains Trailer Brakes
T owing Equipment and
A ccessories
Checking L oads
223

All states and Canadian provinces
require some type of trailer lights.
Check requirements f or the areas
where you plan to tow.
You can get an optional trailer
lighting connector f or your car f rom
your Acura dealer.
If you use a converter, you can get
the connector and pins that mate
with the connector in your car f rom
your Acura dealer.Since lighting and wiring vary in
trailer type and brand, you should
also have a qualif ied mechanic install
a suitable connector between the car
and the trailer.
Always consult your Acura dealer
bef ore connecting the trailer lights
to your car’s lighting system.
Applicable
Light
Taillight
Brake Light
Back-up
Light
Right Turn
Signal
Left Turn
Signal
GroundWiring
Color
Red/Black
White/Black
Green/Black
Green/
Yellow
Green/Blue
Black
Ref er to the f ollowing table f or the
wiring color code.
Wiring Color Code f or Lighting
T railer L ights
Towing a Trailer
Driving224

Many states and Canadian provinces
require special outside mirrors when
towing a trailer. Even if they don’t,
you should install special mirrors if
you cannot clearly see behind you, or
if the trailer creates a blind spot.
Askyourtrailersalesorrental
agency if any other items are
recommended or required f or your
towing situation.When preparing to tow, and bef ore
driving away, be sure to check the
f ollowing:
All weights and loads are within
limits (see pages and ).
Thehitch,safetychains,andany
other attachments are secure.
Allitemsonandinthetrailerare
properly secured and cannot shif t
while you drive. The car has been properly
serviced, and the tires, brakes,
suspension, and cooling system
are in good operating condition.
The lights and brakes on your car
and the trailer are working
properly. Your car tires and spare are
properly inf lated (see page ),
and the trailer tires and spare are
inflated as recommended by the
trailer maker.
221 222 274
Additional Trailer EquipmentPre-T ow Checklist
Towing a Trailer
Driving225

The added weight, length, and
height of a trailer will af f ect your car’s
handling and perf ormance, so
driving with a trailer requires some
special driving skills and techniques.
Foryoursafetyandthesafetyof
others,taketimetopracticedriving
maneuvers bef ore heading f or the
open road, and f ollow the guidelines
discussed below.Drive slower than normal in all
driving situations, and obey posted
speed limits f or cars with trailers. If
you have an automatic transmission,
use D position when towing a trailer
on level roads. D is the proper shif t
lever position to use when towing a
trailer in hilly terrain. (See ‘‘
’’inthenextpagefor
additional gear information.)
When towing a trailer in the
Sequential SportShif t mode, select
Fourth, Third, Second, or First gear;
depending on the vehicle speed and
road condition. Do not use Fif th gear. If the automatic transmission f luid
temperature increases and exceeds
the specif ied limit, the transmission
will also automatically downshif t to
the first gear even with the
Sequential Sportshif t mode. This
prevents the automatic transmission
f rom overheating. In this case, the
gear position ‘‘1’’ in the instrument
panel between tachometer and
speedometer blinks about f or f ive
seconds, then it stays on.
3
Driving Saf ely With a T railer
Towing a Trailer
Driving
T owing Speeds and Gears
Driving
on Hills
226

Maketurnsmoreslowlyandwider
than normal. The trailer tracks a
smaller arc than your car, and it can
hit or run over something the car
misses. Allow more time and
distance f or braking. Do not brake or
turn suddenly as this could cause the
trailer to jackknif e or turn over.
When climbing hills, closely watch
your temperature gauge. If it nears
the red (Hot) mark, turn the air
conditioning of f , reduce speed and, if
necessary, pull to the side of the
road to let the engine cool.When driving down hills, reduce
your speed and shif t down to 2nd
gear. Do not ‘‘ride’’ the brakes, and
remember it will take longer to slow
downandstopwhentowingatrailer. If you must stop when f acing uphill,
use the f oot brake or parking brake.
Do not try to hold the car in place by
pressing on the accelerator, as this
can cause the automatic
transmission to overheat.
If the automatic transmission shif ts
f requently within 3rd, 4th, and 5th
gears while going up a hill, shif t to
D. Crosswinds and air turbulence
caused by passing trucks can disrupt
your steering and cause trailer
swaying. When being passed by a
large car, keep a constant speed and
steer straight ahead. Do not try to
make quick steering or braking
corrections.Always drive slowly and have
someone guide you when backing up.
Grip the of the steering
wheel; then turn the wheel to the lef t
to get the trailer to move to the lef t,
andturnthewheelrighttomovethe
trailer to the right.
Follow all normal precautions when
parking, including f irmly setting the
parking brake and putting the
transmission in Park (automatic) or
in 1st or Reverse (manual). Also,
place wheel chocks at each of the
trailer’s tires.
3
bottom
Towing a Trailer
Driving
Making T urns and Braking
Driving on Hills Handling Crosswinds and Buf f et ingBacking Up
Parking
227

µÌU.S. Cars:
Trailer towing, driving with a roof
rack, or driving in mountainous
conditions.
Driving on muddy, dusty, or
deiced roads.
Follow the
Maintenance Schedule f or Severe
Conditions. NOTE: If you only
drive under a ‘‘severe’’ condition, you
should f ollow the Maintenance
Schedule f or Normal Conditions. Your authorized Acura dealer knows
your car best and can provide
competent, ef f icient service.
However, service at a dealer is not
mandatory to keep your warranties
in effect. Maintenance may be done
by any qualif ied service f acility or
person who is skilled in this type of
automotive service. Keep all the
receipts as proof of completion, and
have the person who does the work
f ill out the Maintenance Record.
Check your warranty booklet f or
more inf ormation.
According to state and federal
regulations, f ailure to perf orm
maintenance on the items marked
with will not void your emissions
warranties. However, Acura
recommends that all maintenance
services be perf ormed at the
recommended time or mileage
period to ensure long-term reliability.
We recommend the use of Acura
parts and f luids whenever you have
maintenance done. These are
manuf actured to the same high-
quality standards as the original
components, so you can be conf ident
of their perf ormance and durability.
OCCASIONALLY
Maintenance Schedule
Maint enance
Maintenance, replacement, or
repair of emissions control
devices and systems may be done
by any automotive repair
establishment or individual using
parts that are ‘‘certif ied’’ to EPA
standards.
Canadian Owners
233

Check the battery condition by
looking at the test indicator window
on the battery. The label on the
battery explains the test indicator’s
colors.
Check the condition of your car’s
battery monthly. You should check
the color of the test indicator window,
and f or corrosion on the terminals.
Check the battery terminals for
corrosion (a white or yellowish
powder). To remove it, cover the
terminals with a solution of baking
soda and water. It will bubble up and
turn brown. When this stops, wash it
of f with plain water. Dry of f the
battery with a cloth or paper towel.
Coat the terminals with grease to
help prevent f uture corrosion.
Battery posts,
terminals, and related accessories
contain lead and lead compounds.
CONT INUED
Battery
Maint enance
WARNING:
Wash hands af ter handling.
265
TEST INDICATOR WINDOW

Check the condition of the wiper
blades at least every six months.
Look f or signs of cracking in the
rubber, or areas that are getting
hard. Replace the blades if you f ind
these signs, or if they leave streaks
and unwiped areas when used.Disconnect the blade assembly
fromthewiperarmbypushingin
the lock tab. Hold the lock tab in
while you push the blade assembly
toward the base of the arm.
Raise the wiper arm of f the
windshield.
To replace the blade:
Raise the driver’s side f irst, then
the passenger’s side. 2.
1.
CONT INUED
Wiper Blades
Maint enance267
WIPER ARMS
LOCK TAB
Do not open the hood when the wiper
arms are raised, or you will damage the
hood and the arms.
