2003 VOLVO XC90 radio

2003 VOLVO XC90
Remote controls
Your vehicle is equipped with a remote control transmitter. This transmi\
tter uses a radio signal to allow
"keyless" entry into the passenger compartment or the tailgate. You will\
be supplied with two coded key
ring transmitters, which will enable you to lock/unlock all doors and th\
e tailgate from a distance of 10-
15 feet (3- 5 meters).
On vehicles equipped with an alarm, the alarm will also be activated/dea\
ctivated by this system.
The vehicle can also be locked/unlocked with the key.

Buttons in remote control:
1-Lock, 2-Unlock, 3-Unlock tailgate,
4-"Panic" function,*, 5-Approach lighting
As an extra security precaution in certain situations (valet parking, e\
tc.), Volvo recommends that the
transmitter not be included when the keys are given to anyone. The servi\
ce key can be used instead. If
one of the transmitters is misplaced, contact the nearest authorized Vol\
vo retailer for assistance.
Using the remote control
l Press the LOCK button once to lock all doors and tailgate.
l Press the UNLOCK button once to unlock the driver's door and fuel filler\
door. Wait for at least 1
second and press this button again (within 10 seconds) to unlock all d\
oors and the tailgate.
l To unlock the tailgate (without unlocking the doors), press the Unlock\
tailgate button twice within 3
seconds.
NOTE:
l Airbag deployment will automatically unlock the doors.
l The keys may also be used to lock and unlock the doors, and to activate \
and deactivate the alarm
system.
l To avoid leaving your keys in the vehicle, make a habit of always lockin\
g the vehicle with the remote
control.
file:///K|/ownersdocs/2003/2003_XC90/03xc90_05.htm (4 of 11)12/30/2006\
4:18:56 PM

2003 VOLVO XC90
2 0 0 3
VOLVO XC90
Audio

pg. 159 Audio
Audio system160
Audio system controls161
Audio functions164
Radio functions168
Menu settings and selections174
CD player175
CD changer (option)177
CD player179
HomeLink® Universal Transceiver180
pg. 160 Audio
Audio system
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (1 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
Steering wheel keypad (option)
The four buttons on the steering wheel keypad can be used to control the\
audio system. The steering
wheel keypad can be used to adjust volume, shift between preset stations\
and change CD tracks.
l Press the or buttons briefly to search for a radio station, or to go to the next/pre\
vious
track on a CD
l Press and hold down these buttons to search within a track.
Display
The display (1) shows the currently selected function, menu selections\
, etc. Clean the display with a dry,
soft, lint-free cloth. Do not use cleaning agents.
Accessing and using menus
In menu mode, you can change settings and program new functions in the a\
udio system. The various
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (3 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
menu alternatives are shown in the display.
Press the menu button (2) to enter menu mode. Use the menus as follows\
:
l Use the menu keys (3) to navigate up or down in the menus. Dots in the\
display indicated that there
are more menu selections from which to choose.
l One long press on EXIT/CLEAR exits menu mode.
l A short press on the EXIT/CLEAR enables you to cancel, undo, or answer n\
o to a menu selection, or
to go back in the menu structure.
l Pressing ENTER confirms a menu selection, or takes you to the next subme\
nu.
pg. 162 Audio
Audio system controls (contd)
Rear headphone connectors and controls (option)
The door panels behind the second row of seats can be equipped with head\
phone connectors for
passengers in the second and optional third row of seats. Several people\
can listen to different sound
sources, such as CDs or the radio at the same time without disturbing ea\
ch other. Two sets of
headphones can be plugged into each connector.
l Use the SEL button (1) to step between the sound sources.
l Press the arrow keys (2) briefly to change CD tracks or switch between\
preset stations.
l Hold down the arrow keys to fast forward/reverse, or search for the prev\
ious/next strong radio station.
l Hold down the SEL button to turn off the sound.
For the best sound reproduction, we recommend headphones with impedance \
between 16-32 ohm. The
sensitivity of these should be equal to or greater than 102 dB. The head\
phone connections are intended
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (4 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
for 3.5 mm contacts and are located under the lower edge of the socket.
All headphones are automatically turned off when the ignition is switche\
d off. They must be manually
restarted when the ignition is switched on again.
Headphones - limitations
l The headphones will only work when the ignition key is in position I or \
higher.
l If a set of headphones is connected to the same source that is being sen\
t through the speakers, the
headphone controls cannot be used to change track or station. This is to\
prevent the driver from being
distracted by an unexpected change in music.
l If the driver selects the same sound source as someone listening to this\
source through headphones,
the driver takes control of the sound source.
l Only one disc in the optional CD changer, and one track on the CD can be\
played at a time.
l Headphone users can choose from among the preset radio stations (AM, FM\
1, FM2) previously set by
the driver.
l If FM is played in the speakers, AM is not available and vice versa.
pg. 163 Audio
Remote control (option)
1. Memory - stores radio stations that have been found by a search
To store a station: - Press the memory button (1). The preset station number will flash 4\
times in the
display
- While the preset number is flashing, use the + or - buttons (5) to s\
elect a position at which to store the
station
- Press button 1 again to store the station
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (5 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
2. Volume
3. Forward/back - fast forward or back
4. Source - step between sound sources
5. Preset/disc - selects among CD's (in the optional CD changer) or pr\
eset radio stations
6. Auto store - searches for and stores the strongest radio stations
7. Not in use
8. Not in use
9. Power - off/on
Point the remote control toward the IR port on the radio panel (see the\
illustration on
page 160).
NOTE: If the remote control does not function properly, check the batteries (\
AAA or R03).
pg. 164 Audio
Audio functions
On/Off button
To activate the system:
1. Turn the ignition key to position I.
2. Press the POWER button (1) to switch the audio system on or off.
NOTE: If you switch off the ignition while the audio system is on, the system \
will be on when the
ignition is switched on again.
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (6 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
the resonance of a concert hall. Dolby Surround Pro Logic II (DPL2) wo\
rks in CD and FM mode. 3-
channel stereo (3-CH) is recommended for AM radio broadcasts. DPL2 is \
only available on the highest
level audio system -Premium Sound. Use the following instructions to sel\
ect PRO LOGIC II, 3-
CHANNEL, or to turn these functions off.
1. Select AUDIO SETTINGS in the menu.
2. Press ENTER.
3. Select SURROUND MODE
4. Press ENTER.
5. Select PRO LOGIC II, 3-CHANNEL, or OFF.
The symbol
PL II is shown in the display. 3-CH is shown when 3-channel stereo is s\
elected.
Dolby noise reduction is manufactured under license from Dolby Laborator\
ies Licensing Corporation.
"Dolby", "Pro Logic" and the double-D symbol
are trademarks of Dolby Laboratories Licensing
Corporation. The Dolby Pro Logic Surround System is manufactured under l\
icence from Dolby
Laboratories Licensing Corporation.
pg. 167 Audio
Bass speaker - SUBWOOFER (option)
The subwoofer helps the system provide fuller sound and deeper bass.
1. Select AUDIO SETTINGS in the menu and press ENTER.
2. Select SUBWOOFER and press ENTER. See
page 165 for information on setting the subwoofer level.
Equalizer FR
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (9 of 17)12/30/200\
6 4:19:06 PM

2003 VOLVO XC90
EQ - FRONT This function is used to fine-tune the sound from the front speakers.
1. Select AUDIO SETTINGS in the menu and press ENTER.
2. Select Equalizer FR and press ENTER.
3. Use the menu selection buttons to set the level or use the SELECTOR c\
ontrol.
4. Press ENTER to select the next frequency. You can select five frequen\
cies.
5. Press ENTER until you come to the menu mode to save the changes you h\
ave made.
Equalizer RR
EQ - REAR This function is used to fine-tune the sound from the rear speakers.
1. Select AUDIO SETTINGS in the menu and press ENTER.
2. Select EQ- REAR and press ENTER.
3. Use the menu selection buttons to set the level or use the SELECTOR c\
ontrol.
4. Press ENTER to select the next frequency. You can select five frequen\
cies.
5. Press ENTER until you come to the menu mode to save the changes you h\
ave made.
pg. 168 Audio
Radio functions
Station search
1. Choose radio mode AM/FM1/FM2 using the SELECTOR control (1) or the \
AM/FM button (2).
2. Press briefly on
or to search for the next strong station. The radio will search for the ne\
xt
file:///K|/ownersdocs/2003/2003_XC90/03xc90_11a.htm (10 of 17)12/30/20\
06 4:19:06 PM
