2003 SUBARU IMPREZA WRX Owners Manual

Keys and doors
2-14
Security system (if equipped)
The security system helps to protect your vehicle
and valuables from theft. The horn sounds and the
parking lights flash if someone attempts to break
into your vehicle. The starter motor is also inter-
rupted to prevent starting the vehicle without a key.
The system can be armed and disarmed with the
remote transmitter.The system does not operate when the key is in-
serted into the ignition switch. System operation
The security system will give the following alarm in-
dications when triggered: The parking lights will flash and the horn will
sound intermittently. In addition, the starter motor willnot operate. The alarm automatically resets after 30 seconds;
however, the alarm will reactivate if the vehicle is
tampered with again. The alarm will continue for sixtimes if any sensor continues to be activated.
The alarm is triggered by: Opening a door, the rear gate or trunk lid (vehicle
equipped with trunk light only).
Application of physical shock to the vehicle (e.g.
breaking glass or forced entry). Note that there are
two alarm levels for shock: warning and alarm. In
warning mode, the alarm detects lower level vibra-
tions and triggers 2 warning chirps on the horn and
two flashes on the lights as a deterrent to would be
vandals. In alarm mode, higher levels of shock are
detected and the system will go into full alarm. Ignition switch being turned on while in armed
state. NOTE
With the valet mode selected, the security sys- tem does not operate and the parking lights do not flash when the remote transmitter is used forlocking and unlocking. The security system indi-cator light in the combination meter flashestwice per second to show that the valet mode is
selected. For details, refer to “Valet mode ” in this
section.

Keys and doors
2-15
– CONTINUED –
Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close all doors (and the rear gate on the wagon).
1) Press to Arm the system.
2) Press to Disarm the system.
Security system-indicator light
6. Briefly press the “LOCK/ARM” button (for less
than two seconds). All doors (and the rear gate on
the wagon) will lock, the horn will sound one time,the parking lights will flash one time and the indica-
tor light starts flashing slowly (approximately once
every two seconds).
If any of the doors (or the rear gate) is not fully
closed, the horn sounds three times, the parking
lights flash three times to alert you that the doors (or
the rear gate) are not properly closed. When you
close the door, the system will automatically arm and doors will automatically lock.

Keys and doors
2-16
To arm the system using power door locking switches
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close the doors (and the rear gate on the wagon) but leave only the driver ’s door or the front passen-
ger’ s door open.
6. Push the front side ( “LOCK” side) of the power
door locking switch to set the door locks.
7. Close the door. The horn will sound one time, the parking lights will flash one time and the indicator
light will start flashing slowly (approximately once
every two seconds) to inform you that the system
has armed.
NOTE The system can be armed even if the engine hood and/or the windows are opened. Always
make sure that they are fully closed before arm- ing the system. Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The
driver’ s door will unlock, the horn will sound two
times, the parking lights will flash two times and the
indicator light will go off.
To unlock all other doors (and the rear gate on the
wagon), briefly press the “UNLOCK/DISARM” button
a second time.
Emergency disarming
If you cannot disarm the system using the transmit-
ter (i.e. the transmitter is lost, broken or the transmit-
ter battery is too weak), you can disarm the system
without using the transmitter.

Keys and doors
2-17
– CONTINUED –
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .
To deactivate it, press the “LOCK/ARM” button or
“UNLOCK/DISARM” button.
The parking lights will also flash when the alarm is activated.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds.
Valet mode
When you choose the valet mode, the security sys-
tem does not operate. In valet mode, the remotetransmitter is used only for locking and unlocking
the doors (and rear gate on the wagon) and panic
activation. The parking lights do not flash when re-
mote transmitter is used for locking and unlocking.
To enter the valet mode, open the driver ’s door and keep the
“UNLOCK/DISARM” button depressed for
more than two seconds . The security system sta-
tus indicator light will continue to flash two times per second indicating that the system is in the valetmode.
To exit valet mode, open the driver ’s door and keep
the “UNLOCK/DISARM” button pressed for more
than two seconds. The indicator will stop flashing.
Passive arming
When passive arming mode has been programmed
by the dealer, arming of the system is automatically
accomplished without using the remote transmitter. Note that in this mode, DOORS MUST BE MANUAL-
LY LOCKED.

Keys and doors
2-18
To enter the passive mode
1. Remove the side sill cover on the driver ’s side.
1)Open the driver ’s door.
2)Remove the two clips fastening the front portion
of the cover with a screwdriver.
3)Remove the side sill cover by pulling it up.
1) Connector for SRS airbag system (yellow)
2) White (1P)
2. Connect the white (1 pole) connector.
3. Turn the ignition switch from the “LOCK” to the
“ON” position.
4. Install the side sill cover.
To place the system in active arming mode (remote
required for activation), disconnect the white con-
nector.

Keys and doors
2-19
– CONTINUED –
WARNING
Do not disconnect or tamper with any yellow connector and/or any harness covered withyellow insulation and/or tape.Doing so could result in accidental inflation of the SRS airbag or could make the SRS airbag
system inoperative, which may result in seri-
ous injury.
Arming the system
1. Turn the ignition switch to the “ON” position.
1) ON 2) LOCK
2. Turn the ignition switch from “ON” to “LOCK”
position and remove the key from the ignition switch.

Keys and doors
2-20
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with theinside door lock levers.
5. Close the doors. The system will automatically
arm after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming
will take place immediately regardless of whether ornot the passive mode has been selected.
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
above or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing.

Keys and doors
2-21
– CONTINUED –
The indicator light provides the following indications. Flashing one time: Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
NOTE The battery must be reconnected before the indi- cator light will flash.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position. Child safety locks
1) Lock 2) Unlock
Each rear door has a child safety lock that prevents
the doors from being opened even if the inside door
handle is pulled.
When the child safety lock lever is in the lock posi-
tion, the door cannot be opened from inside regard- less of the position of the inner door handle lock
lever. The door can only be opened from the out-side.
