2003 SUBARU FORESTER ENGINE OIL

6
Safety precautions when driving Seatbelt and SRS airbag
All persons in the vehicle should fasten their
seatbelts BEFORE the vehicle starts to move.
Otherwise, the possibility of serious injury be-
comes greater in the event of a sudden stop or
accident. To obtain maximum protection in the event of
an accident, the driver and all passengers in the
vehicle should always wear seatbelts when the
vehicle is moving. The SRS (Supplemental Re-
straint System) airbag does not do away with
the need to fasten seatbelts. In combination
with the seatbelts, it offers the best combined
protection in case of a serious accident.
Not wearing a seatbelt increases the chance of
severe injury or death in a crash even when the
car has the SRS airbag. The SRS airbags deploy with considerable
speed and force. Occupants who are out of
proper position when the SRS airbag deploys
could suffer very serious injuries. Because the
SRS airbag needs enough space for deploy-
Outside mirror defogger
Rear window defogger
Air recirculation
Engine oil Washer
Mark Name

21
–
CONTINUED –
Warning and indicator light
Mark Name Page
Seatbelt warning light 3-9
SRS airbag system warning light 3-10
CHECK ENGINE warning
light/Malfunction indicatorlamp 3-10
Charge warning light 3-11
Oil pressure warning light 3-11
AT OIL temperature warning
light (if equipped) 3-12
or ABS warning light 3-12
or Brake system warning light 3-13
Door open warning light 3-14
Front-wheel drive warning
light (if equipped) 3-15
Low fuel warning light 3-14
Turn signal indicator lights 3-15
High beam indicator light 3-15
Security system indicator
light (if equipped) 2-14
Cruise control indicator light
(if equipped) 3-15
Mark Name Page

3-1
3
Instruments and controls
Ignition switch ............................................. 3-2 LOCK ................................................................ 3-2
ACC .................................................................. 3-3
ON ..................................................................... 3-3
START .............................................................. 3-3
Key reminder chime ........................................ 3-3
Key interlock release (AT vehicles only) ...... 3-4
Hazard warning flasher ............................... 3-5
Meters and gauges ...................................... 3-5 Speedometer ................................................... 3-5
Odometer/Trip meter ...................................... 3-5
Tachometer ...................................................... 3-6
Fuel gauge ....................................................... 3-7
Temperature gauge ......................................... 3-8
Ambient temperature gauge .......................... 3-9
Warning and indicator lights ...................... 3-9 Seatbelt warning light and chime .................. 3-9
SRS airbag system warning light .................. 3-10
CHECK ENGINE warning light/Malfunction
indicator lamp ................................................. 3-10
Charge warning light ...................................... 3-11
Oil pressure warning light .............................. 3-11
AT OIL TEMPerature warning light
(for AT vehicles) .............................................. 3-12
ABS warning light ........................................... 3-12
Brake system warning light ........................... 3-13
Door open warning lights ............................... 3-14
Low fuel warning light .................................... 3-14
Front-wheel drive warning light
(for AT vehicles) .............................................. 3-15
Shift position indicator (AT vehicles) ........... 3-15 Turn signal indicator lights ............................ 3-15
High beam indicator light ............................... 3-15
Cruise control indicator light ......................... 3-15
Clock ............................................................. 3-16
Light control switch ..................................... 3-17 Headlights ....................................................... 3-17
High/low beam change (dimmer) .................. 3-18
Headlight flasher ............................................. 3-18
Daytime running light system ....................... 3-19
Turn signal lever .......................................... 3-19
Illumination brightness control .................. 3-20
Parking light switch ..................................... 3-21
Fog light switch (if equipped) ..................... 3-21
Wiper and washer ........................................ 3-22 Windshield wiper and washer switches ....... 3-23
Rear window wiper and washer switch ........ 3-25
Windshield wiper deicer (if equipped) ....... 3-26
Rear window defogger switch .................... 3-27
Mirrors ........................................................... 3-29 Inside mirror .................................................... 3-29
Outside mirrors ............................................... 3-31
Tilt steering wheel ........................................ 3-33
Horn ............................................................... 3-34

3-9
Instruments and controls
–CONTINUED –
Ambient temperature gauge
The ambient temperature gauge shows the ambient
temperature in a range from –22 °Fto122 °F(–30 °Cto
50 °C).
The gauge can give a false reading under any of the
following conditions: When there is too much sun.
During idling; while running at low speeds in a traffic
jam; when the engine is restarted immediately follow-
ing a shutdown. When the actual ambient temperature falls outside
the specified indicator range.Warning and indicator lights
Several of the warning and indicator lights come on
momentarily and then go out when the ignition switch
is initially turned to the “ON” position. This permits
checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to
the “ON” position. The following lights come on:
Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light/Malfunction indica-
tor lamp
Charge warning light
Oil pressure warning light
AT OIL temperature warning light (AT vehicles)
ABS warning light
Brake system warning light
If any lights fail to come on, it indicates a burned-out
bulb or a malfunction of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” position,
the seatbelt warning light will come on and the remind-
er chime will sound for about six seconds to remind the
HS3047BA

3-11
Instruments and controls
–CONTINUED –
NOTE
This light also comes on when the fuel filler cap is
not tightened until it clicks.
If you have recently refueled your vehicle, the cause of
the CHECK ENGINE warning light/malfunction indica-
tor lamp coming on could be a loose or missing fuel fill-
er cap. Remove the cap and retighten it until it clicks.
Make sure nothing is interfering with the sealing of the
cap. Tightening the cap will not make the CHECK EN-
GINE warning light turn off immediately. It may take
several driving trips. If the light does not go out, take
your vehicle to your authorized SUBARU dealer im-
mediately. If the light is blinking:
If the light is blinking while driving, an engine misfire
condition has been detected which may damage the
emission control system.
To prevent serious damage to the emission control
system, you should do the following: Reduce vehicle speed.
Avoid hard acceleration.
Avoid steep uphill grades.
Reduce the amount of cargo, if possible.
Stop towing a trailer as soon as possible.
The CHECK ENGINE warning light may stop blinking and come on steadily after several driving trips. You
should have your vehicle checked by an authorized
SUBARU dealer immediately.
Charge warning light
If this light comes on when the engine is run-
ning, it may indicate that the charging system is not
working properly.
If the light comes on while driving or does not go out
after the engine starts, stop the engine at the first safe
opportunity and check the alternator belt. If the belt is
loose, broken or if the belt is in good condition but the
light remains on, contact your nearest SUBARU deal-
er immediately. Oil pressure warning light
If this light comes on when the engine is run-
ning, it may indicate that the engine oil pressure is low
and the lubricating system is not working properly.
If the light comes on while driving or does not go out
after the engine starts, stop the engine at the first safe
opportunity and check the engine oil level. If the oil lev-
el is low, add oil immediately. If the engine oil is at the
proper level but the light remains on, contact your
nearest SUBARU dealer immediately.

3-12
Instruments and controls
Do not operate the engine with the oil pressure
warning light on. This may cause serious en-
gine damage.
AT OIL TEMPerature warning
light (for AT vehicles)
If this light comes on when the engine is running, it
may indicate that the automatic transmission fluid tem-
perature is too hot.
If the light comes on while driving, it is unnecessary to
stop the vehicle, but avoid driving up steep grades or
in stop and go traffic. Automatic transmission control system warn-
ing
If the light flashes after the engine starts, it may indi-
cate that the automatic transmission control system is
not working properly. Contact your nearest SUBARU
dealer for service immediately. ABS warning light
The ABS warning light comes on when the ignition switch is turned to the “ON” position and goes out after
about two seconds.
This is an indication that the ABS system is working
properly.
If the warning light behaves as follows, the ABS
system may not work properly.
When the warning light is on, the ABS function
shuts down; however, the conventional brake
system continues to operate normally.
The warning light does not come on when the
ignition switch is turned to the “ON” position. The warning light comes on when the ignition
switch is turned to the “ON” position, but it
does not go out even when the vehicle speed
exceeds approximately 8 mph (12 km/h). The warning light comes on during driving.
If these occur, have the ABS system repaired at
the first available opportunity by your SUBARU
dealer.
With a vehicle equipped with an EBD system, the ABS
warning light comes on together with the brake system
warning light if the EBD system becomes faulty. For
(U.S.) (Canada)

4-1
4
Climate control
Ventilator ...................................................... 4-2 Air flow selection ............................................ 4-2
Center and side ventilators ............................ 4-3
Manual climate control system ................... 4-4 Control panel ................................................... 4-4
Heater operation ............................................. 4-6
Air conditioner operation (if equipped) ........ 4-9
Automatic climate control system
(if equipped) ................................................. 4-10 Temperature sensors ..................................... 4-15
Operating tips for heater and air
conditioner ................................................... 4-16 Cleaning ventilation grille .............................. 4-16
Efficient cooling after parking in direct
sunlight ............................................................ 4-17
Lubrication oil circulation in the refrigerant
circuit ............................................................... 4-17
Checking air conditioning system before
summer season .............................................. 4-17
Cooling and dehumidifying in high humidity
and low temperature weather conditions ..... 4-17
Air conditioner compressor shut-off when
engine is heavily loaded ................................ 4-17
Refrigerant for your climate control system 4-17
Air filtration system (if equipped) ............... 4-18 Replacing an air filter ..................................... 4-18

4-17
Climate control
– CONTINUED –
Efficient cooling after parking in direct sunlight
After parking in direct sunlight, drive with the windows
open for a few minutes to allow outside air to circulate
into the heated interior. This results in quicker cooling
by the air conditioner. Keep the windows closed during
the operation of the air conditioner for maximum cool-
ing efficiency. Lubrication oil circulation in the refrig-
erant circuit
Operate the air conditioner compressor at a low en-
gine speed (at idle or low driving speeds) a few min-
utes each month during the off-season to circulate its
oil. Checking air conditioning system be-
fore summer season
Check the air conditioner unit for refrigerant leaks,
hose conditions, and proper operation each spring.
This check is best performed by your SUBARU dealer.
Cooling and dehumidifying in high hu-
midity and low temperature weather
conditions
Under certain weather conditions (high relative humid-
ity, low temperatures, etc.) a small amount of water
vapor emission from the air outlets may be noticed.
This condition is normal and does not indicate any
problem with the air conditioning system. Air conditioner compressor shut-off
when engine is heavily loaded
To improve acceleration and gas mileage, the air con-
ditioner compressor is designed to temporarily shut off
during air conditioner operation whenever the acceler-
ator is fully depressed such as during rapid accerela-
tion or when driving on a steep upgrade. Refrigerant for your climate control
system
Your air conditioner uses ozone friendly refrigerant
HFC134a. Therefore, the method of adding, changing
or checking the refrigerant is different from the method
for CFC12 (freon). Consult your SUBARU dealer for
service. Repairs needed as a result of using the wrong
refrigerant are not covered under warranty.
