2003 SUBARU BAJA display

Instruments and controls3-29
–
CONTINUED –
By pressing and releasing the left button, the automatic dimming
function is toggled on or off. When the automatic dimming function is
on, the auto dimming indicator light (green) located to the right of the
button will illuminate. By pressing and releasing the right button, the compass display is
toggled on or off. When the compass is on, an illuminated compass
reading will appear in the lower part of the mirror.
Even with the mirror in anti-glare mode, the mirror surface turns bright
if the transmission is shifted into reverse. This is to ensure good rear-
ward visibility during reversing. n Photosensors
HB6020BA
The mirror has a photosensor attached on both the front and back
sides. If the glare from the headlights of vehicles behind you strikes
the mirror, these sensors detect it and make the reflection surface of
the mirror dimmer to help prevent you from being blinded. For this
reason, use care not to cover the sensors with stickers, or other simi-
lar items. Periodically wipe the sensors clean using a piece of dry soft
cotton cloth or an applicator. nCompass calibration
1. For optimum calibration, switch off all nonessential electrical ac-
cessories (rear window defogger, heater/air conditioning system,
spotlight, etc.) and ensure all doors are shut.
2. Drive to an open, level area away from large metallic objects or

3-30
structures and make certain the ignition switch is in the “ON” position.
3. Press and hold the left button for 3 seconds then release, and the compass will enter the calibration mode. “CAL” and direction will be
displayed.
4. Drive slowly in a circle until “CAL” disappears from the display
(about two or three circles). The compass is now calibrated.
5. Further calibration may be necessary should outside influences
cause the mirror to read inaccurately. You will know that this has oc-
curred if your compass begins to read in only limited directions.
Should you encounter this situation, return to step one of the above
procedure and recalibrate the mirror. n Compass zone adjustment
1. The zone setting is factory preset to Zone 8. Refer to the “Com-
pass calibration zone ” map at the end of this manual to verify that the
compass zone setting is correct for your geographical location.
2. Press and hold the right button for 3 seconds then release, and the
word “ZONE” will briefly appear and then the zone number will be dis-
played.
3. Press the right hand button repeatedly to cycle the display through
all possible zone settings. Stop cycling when the correct zone settingfor your location is displayed.
4. Releasing the button for 3 seconds will exit the zone setting mode.
Outside mirrors Convex mirror (Passenger side)
WARNING
Objects look smaller in a convex mirror and farther away than
when viewed in a flat mirror. Do not use the convex mirror tojudge the distance of vehicles behind you when changing lanes.
Use the inside mirror (or glance backwards) to determine theactual size and distance of objects that you view in convex mir-
ror.

Audio5-5
–
CONTINUED –
Choose desired volume level for each mode by turning the volume
control dial. The control function returns to volume control mode after
about 5 seconds.
To change control modes: Each brief press of the “AUDIO” button
5 changes control modes in the following sequence starting from vol-
ume control mode. (When the radio is first turned on, the control mode
is in the volume control.)
Volume Bass Treble Balance Fader
(VOL) (BAS) (TRE) (BAL) (FAD)
The “AUDIO” button 5 is used for selecting the following control
modes:
Display
Control mode
HB5036BA
Turn counterclockwiseTurn clockwise
BASBass controlFor less bassFor more bass
TRETreble controlFor less trebleFor more treble
FA DFader controlTo increase rear speaker
volume and decrease front
speaker volumeTo increase front speaker
volume and decrease rear
speaker volume
BALBalance controlTo increase left speaker
volume and decrease right
speaker volumeTo increase right speakervolume and decrease left
speaker volume
VOLVolume controlFor less volumeFor more volume
Waveband selection
n FM/AM selection
Push the “BAND” button 2 to select FM1, FM2 or AM reception. The

5-6
display indicates which one is currently selected. Stereo indicator
The stereo indicator “ST” will come on when an FM stereo broadcast
is received. Tuning (TUNE)
n Manual tuning (TUNE)
Press the tuning button 3 marked “ ” to increase the tuning frequen-
cy and press the tuning button marked “ ” to decrease it.
Each time the button is pressed, the frequency interval can be
changed between 10 kHz in the AM mode and 0.2 MHz in the FMmode.
Constant pressure on the button causes a continuous change in the
frequency. n Automatic tuning (SCAN)
Press the “SCAN” button
6 to change the radio to the SCAN mode. In
this mode, the radio scans through the radio band until a station is
found. The radio will stop at the station for five seconds while display-
ing the frequency, after which scanning will continue until the entire
band has been scanned from the low end to the high end.
Press the “SCAN” button again to cancel the SCAN mode and to stop
on any displayed frequency.
When the “SCAN” button is pressed for automatic tuning, stations are
scanned in the direction of low frequencies to high frequencies only.
Automatic tuning may not function properly if the station reception is
weakened by distance from the station or proximity to tall buildingsand hills. Selecting preset stations
Presetting a station with a “preset button ”
4 allows you to select that
station in a single operation. Up to six AM, FM1 and FM2 stations
each may be preset. How to preset stations
1. Press the “BAND” button 2 to select FM1, FM2 or AM reception.
2. Press the “SCAN” button or tune the radio manually until the

Audio5-7
–
CONTINUED –
desired station frequency is displayed.
3. Press one of the preset buttons for more than 2 seconds to store
the frequency. At this time, there will momentarily be no sound from
the radio. If the button is pressed for less than 2 seconds, the preced-
ing selection will remain in memory. NOTE If the connection between the radio and battery is broken for any
reason such as vehicle maintenance or radio removal, all stationsstored in the preset buttons are cleared. If this occurs, it is neces-sary to reset the preset buttons.
Compact disc player operation
HB5067CB
7 Disc slot
8 CD button
9 Eject button
Q Fast forward and track upbutton W
Fast reverse and track downbutton
E Random button
R Repeat button
T Scan button
Y PWR (power) switch
To playback a compact disc
n When CD is not in the player
Hold a disc with a finger in the center hole while gripping the edge of

5-10
NOTE Avoid driving the vehicle with a CD sticking out, because
vibration might make it fall out. To protect the disc, the disc is automatically loaded if it is left
in the ejected position for more than approximately 15 seconds(Auto Reload). In this case, the disc is not played.
CD changer control (If optional in dash CD changer is connected) An optional CD changer can be connected to this audio unit. See your
SUBARU dealer for more information. For procedures for loading and un-
loading CDs, refer to “In-dash 6 CD auto changer ” in this chapter.
HB5067DB
U CD button
I Track selection buttons
O RAND (Random) button P
RPT (Repeat) button
A SCAN button
To start playback
Press the “CD” button U. The “CD” indicator will come on and the
disc number will appear on the display and the CD changer will start playback.

5-12
To cancel the random mode, press the button again. Then the
“RAND” indicator goes out, and normal playback mode is restored.
Scan (a convenient way to become familiar with a disc)
1. Press the “SCAN” button
A.
– The display shows “SCAN” and the track number being
scanned.– You hear the first 10 seconds of each track.
– The operation is automatically cleared after playing all pro-
grams. Then, normal playback starts.
2. Press the “SCAN” button again when you hear a track you like.
– Normal playback resumes.
To stop playback
To stop playback and switch over to the radio mode, press the
“BAND” button.

Maintenance and service11-11
–
CONTINUED –
12. Reinstall the cover under the oil filter.
13. Pour engine oil through the filler neck.
Oil capacity (Guideline): 4.2 US qt (4.0 liters, 3.5 Imp qt)
The oil quantity indicated above is only a guideline. The necessary quantity of oil depends on the quantity of oil that has been drained.
The quantity of drained oil differs slightly depending on the tempera-
ture of the oil and the time the oil is left flowing out. After refilling the
engine with oil, therefore, you must use the dipstick to confirm that the
level is correct.
14. Start the engine and make sure that no oil leaks appear aroundthe filter ’s rubber seal and drain plug.
15. Run the engine until it reaches the normal operating temperature.
Then stop the engine and wait a few minutes to allow the oil drain
back. Check the oil level again and if necessary, add more engine oil. Recommended grade and viscosity CAUTION
Use only engine oil with the recommended grade and viscosity.
Oil grade: ILSAC GF-3, which can be identified with the new API certification mark (Starburst mark)
or API classification SL with the words “ENERGY CON-
SERVING” (if you cannot obtain the oil with SL grade,
you may use SJ grade “ENERGY CONSERVING ” oil).
These recommended oil grades can be identified by looking for either
or both of the following marks displayed on the oil container.
