3. Fold down the switchback door by releasing the lock knob. Then you can have a flat and larger cargo space.
4. Place the long object on the cargo bed through the switchback dooropening.
Be sure all items are secured in place. NOTE When opening the switchback door in snow, accumulated snow
in the cargo bed may enter the passenger compartment which could result in dampness in the passenger compartment. Prior to opening
of the switchback door, brush off the snow completely. Close the switchback door whenever you leave the vehicle to pre-
vent unauthorized entry.
WARNING
The switchback door should be kept completely shut when the
vehicle is idling in an enclosed or partially enclosed area to avoidthe possibility of exhaust gas entering the passenger compart-ment. Engine exhaust gas contains carbon monoxide, a colorlessand odorless gas which is extremely dangerous, or even lethal if
inhaled. To ensure that exhaust gas cannot penetrate the switch-
back door, make certain that there are no obstructions betweenthe door and the vehicle body that prevent the door from fully
closing or that crimp the weather strip around the door.

3
Instruments and controls Ignition switch3-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key reminder chime 3-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 3-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key interlock release (AT vehicles only) 3-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard warning flasher 3-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Meters and gauges 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer/Trip meter 3-7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 3-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature indicator (if equipped) 3-8 . . . . . . . . . . . . . . . . . . . . . . .
Fuel gauge 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature gauge 3-9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning and indicator lights 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbag system warning light 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHECK ENGINE warning light/Malfunction indicator lamp 3-11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charge warning light 3-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil pressure warning light 3-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
AT OIL TEMPerature warning light (for AT vehicles) 3-13 . . . . . . . . . . . . . .
ABS warning light 3-13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system warning light 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door ajar warning lights 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switchback door indicator light 3-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low fuel warning light 3-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front-wheel drive warning light (for AT vehicles) 3-15 . . . . . . . . . . . . . . . . .
Security system status indicator light (if equipped) 3-16 . . . . . . . . . . . . . .
Shift position indicator (for AT vehicles) 3-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn signal indicator lights 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High beam indicator light 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cargo lamp indicator light 3-16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light control switch 3-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime running light system 3-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn signal lever 3-19
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination brightness control 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking light switch 3-21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch (if equipped) 3-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper and washer 3-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 3-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruments and controls3-3
–
CONTINUED –
Ignition switch
WARNING
Never turn the ignition switch to “LOCK” while the vehicle is be-
ing driven or towed because that will lock the steering wheel, pre- venting steering control. And when the engine is turned off, it
takes a much greater effort than usual to steer.
The ignition switch has four positions: LOCK, ACC, ON and START.
HB4000CA
LOCK
The key can only be inserted or removed in this position. The ignition
switch will lock the steering wheel when you remove the key.
If turning the key is difficult, turn the steering wheel slightly to the right
and left as you turn the key.

3-4
nAutomatic transmission vehicles
HB2032CA
HB4016BA
The key can be turned from “ACC” to “LOCK” only when the selector
lever is in the “P” position.
n Manual transmission vehicles
OM-H0144
The key can be turned from “ACC” to “LOCK” only when the key is
pushed in while turning it. ACC
In this position the electrical accessories (radio, cigarette lighter socket, etc.) can be used. ON
This is the normal operating position after the engine is started.

Instruments and controls3-5
–
CONTINUED –
START CAUTION
Do not turn the ignition switch to the “START” position while the
engine is running.
The engine is started in this position. The starter cranks the engine to
start it. When the key is released (after the engine has started), the
key automatically returns to the “ON” position.
Key reminder chime
The reminder chime sounds when the driver ’s door opens and the key is
in the “LOCK” or “ACC” positions. The chime stops when the key is re-
moved from the ignition switch.
Ignition switch light
For easy access to the ignition switch in the dark, the ignition switch lightcomes on when driver ’s door is opened. The light remains on for 10 se-
conds and goes out after driver ’s door is closed or if the key is turned to
the “ON” position.
Key interlock release (AT vehicles only)
If the key can not be turned to the “LOCK” position even when the selec-
tor lever is in the “P” position:
HB3011BA

3-8
To change the mode indication, briefly push the knob.
Each press of the knob changes the function alternately.A trip meter B trip meter
To set the trip meter to zero, select either the A trip or B trip meter and
push the knob and keep it pushed for more than 1 second.
NOTE If the connection between the combination meter and battery is bro-
ken for any reason such as vehicle maintenance or fuse replace-ment, the data recorded on the trip meter will be lost. Tachometer
CAUTION
Do not operate the engine with the pointer of the tachometer in
the red zone. In this range, fuel injection will be cut by the enginecontrol module to protect the engine from overrevving. Theengine will resume running normally after the engine speed isreduced below the red zone.
The tachometer shows the engine speed in thousands of revolutions perminute. Outside temperature indicator (if equipped)
The outside temperature indicator shows the outside temperature in a
range from –22°F to 122 °F ( –30 °C to 50 °C).
The indicator can give a false reading under any of the following condi-tions: When there is too much sun.
During idling; while running at low speeds in a traffic jam; when the
engine is restarted immediately following a shutdown. When the actual outside temperature falls outside the specified indi-
cator range.

Instruments and controls3-9
–
CONTINUED –
Fuel gauge
The fuel gauge shows the approximate amount of fuel remaining in the tank.
The gauge does not return to “E” even though the ignition switch is in the
“ACC” or “LOCK” position.
The gauge may move slightly during braking, turning or acceleration dueto fuel level movement in the tank.
Temperature gauge
CAUTION
If the pointer exceeds the normal operating range, safely stop the
vehicle as soon as possible.
See “ In case of emergency ” in chapter 9.
HB2012BB
The temperature gauge shows engine coolant temperature when the
ignition switch is in the “ON” position.
The coolant temperature will vary in accordance with the outside temper-
ature and driving conditions.
We recommend that you drive moderately until the pointer of the temper-
ature gauge reaches near the middle of the range. Engine operation is
optimum with the engine coolant at this temperature range and high rev-
ving operation when the engine is not warmed up enough should be

3-10
avoided.
Warning and indicator lights
Several of the warning and indicator lights come on momentarily and
then go out when the ignition switch is initially turned to the “ON” posi-
tion. This permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the “ON” position.
The following lights come on:
Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light / Malfunction indicator lamp
Charge warning light
Oil pressure warning light
AT OIL temperature warning light (AT vehicles)
ABS warning light
Brake system warning light
If any lights fail to come on, it indicates a burned-out bulb or a malfunc-
tion of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” position, the seatbelt
warning light will come on and the reminder chime will sound for about
six seconds to remind the driver to fasten the seatbelt.
The seatbelt warning light remains on for about six seconds and turns off
automatically after six seconds.
The seatbelt reminder chime will turn off when the driver ’s side seatbelt is
buckled or it will turn off automatically after six seconds. SRS airbag system warning light AIRBAG
When the ignition switch is turned to the “ON” position, the SRS airbag
system warning light will come on for about six seconds and go out. This
shows the SRS frontal airbag and seatbelt pretensioners are in normaloperation.
