2003 SUBARU BAJA clock

In case of emergency9-7
–
CONTINUED –
HB9054BA
2. Open the tailgate and remove the rubber cap from the cargo bed. Pull up the “RELEASE” portion of the cap when removing it.
3. Locate the hex-headed hoist shaft end inside the hole.
HB9055BA
4. Turn the hoist shaft end counterclockwise with the wheel nut
wrench until the temporary spare tire is on the ground with enough
cable slack to allow you to pull it out from under the vehicle.
CAUTION
Do not put your fingers into the center hole of the temporaryspare tire while you pulling it out, because they might be pinched
in between the wheel and the retainer.

9-8
HB9056AA
5. Tilt the retainer at the end of the cable and pull it through the cen-
ter of the temporary spare tire.
6. After the temporary spare tire is removed from the cable, the cable
must be wound up completely by turning the hoist nut shaft clockwise
until you hear a clicking sound. Also visually inspect the cable to
make certain that there is no longer any slack present.WARNING
When using the spare tire hoist:
After the temporary spare tire is removed from the cable, wind
the cable up completely until the retainer at end of the cable sitsagainst the underside of the vehicle. Driving with the cable notretracted fully could result in damage to the adjacent under floorparts and lead to a serious accident. The spare tire holder is designed to carry only the smaller tem-
porary spare tire. Never store a full size tire (flat or otherwise) in
the spare tire holder. Doing so can result in damage to adjacentunder floor parts and can lead to a serious accident.
CAUTION
When using the spare tire hoist:Do not use air tools or power tools to turn the spare tire hoist
shaft end. If you do, it could result in severe mechanical damageto the spare tire hoist.

In case of emergency9-9
–
CONTINUED –
Re-storage of spare tire
1. Turn the spare tire hoist shaft end counterclockwise with the wheel
nut wrench to loosen the cable sufficiently enough to allow the cable
end retainer go through center hole of the temporary spare tire.
2. Insert the retainer through the center hole of the temporary tire
(with the outside of the tire facing up).
3. Turn the hoist shaft end clockwise with the wheel nut wrench towind the cable up completely until you hear a few clicking sounds.
Confirm that the temporary spare tire holding cable has been wound
up completely by shaking the temporary tire.
CAUTION
If the temporary spare tire is not stored securely, it could damage
adjacent areas of the vehicle and make an abnormal noise.
4. Put the rubber cap on the hoist shaft end hole.
5. Place the wheel nut wrench back into the tool bag and store thejack and tool bag in their storage locations.
Temporary spare tire Using the temporary spare tire
WARNING
Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not designed to sustain the towing load.
Use of the temporary spare tire when towing can result in failureof the spare tire and/or less stability of the vehicle and may leadto an accident.
CAUTION
Never use any temporary spare tire other than the original. Usingother sizes may result in severe mechanical damage to the drivetrain of your vehicle.

9-12
HGS038BA
4. Put wheel blocks at the front and rear of the tire diagonally opposite
the flat tire.
5. Take out the spare tire, jack, and wheel nut wrench. Refer to the sections “Spare tire ” and “Jack and tools ” in this chapter for
their location, instructions and precautions.
After the spare tire is removed from the spare tire holder, the cable must
be wound up completely by turning the hoist nut shaft clockwise until
you hear a clicking sound. Also visually inspect the cable to make cer-
tain that there is no longer any slack present.
Removing the flat tire and installing the spare tire
HS9008BA
1. Loosen the wheel nuts using the wheel nut wrench but do not re- move the nuts.

In case of emergency9-15
–
CONTINUED –
8. Turn the jack handle counterclockwise to lower the vehicle.
HB9078BB
9. Use the wheel nut wrench to securely tighten the wheel nuts to the
specified torque, following the tightening order in the illustration.
The torque for tightening the nuts is 66 to 81 ft-lb (90 to 110 N-m, 9 to
11 kg-m). This torque is equivalent to applying about 88 to 110 lbs
(40 to 50 kg) at the top of the wheel nut wrench provided to your ve-
hicle. Never use your foot on the wheel nut wrench or a pipe exten-
sion on the wrench because you may exceed the specified torque.
Have the wheel nut torque checked at the nearest automotive service
facility. Storage of the flat tire CAUTION
Secure the flat tire in the cargo bed (with the outer side of the
wheel facing up) by using the designated tire holding rod and
retainer. If the flat tire is not properly secured, it may fall out andcreate a dangerous road hazard that could lead to a serious acci-dent. Do not store the flat tire under the floor. Doing so could dam-
age the underside of the vehicle.
1. Take the tire holding rod and retainer out of the tool bag.

In case of emergency9-21
–
CONTINUED –
Engine overheating
WARNING
Never attempt to remove the radiator cap until the engine has been shut off and has fully cooled down. When the engine is hot,the coolant is under pressure. Removing the cap while the engineis still hot could release a spray of boiling hot coolant, which
could burn you very seriously.
If the engine overheats, pull off the road safely and stop the vehicle in asafe place. If steam is coming from the engine compartment
Turn the engine off and get everyone away from the vehicle until itcools down. If no steam is coming from the engine compartment
1. Keep the engine running at idling speed.
2. Open the hood to ventilate the engine compartment.
Confirm that the cooling fan is turning. If the fan is not turning, im-
mediately turn the engine off and contact your authorized dealer for
repair.
3. After the engine coolant temperature has dropped, turn off the en-gine.
If the temperature gauge stays at the overheated zone, turn the en-
gine off.
4. After the engine has fully cooled down, check the coolant level in
the reserve tank.If the coolant level is below the “MIN” mark, add coolant up to the
“MAX” mark.
5. If there is no coolant in the reserve tank, add coolant to the reserve
tank. Then remove the radiator cap and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator, first wrap a thick
cloth around the radiator cap, then turn the cap counterclockwise
slowly without pressing down until it stops. Release the pressure from

In case of emergency9-27
–
CONTINUED –
Moonroof — if the moonroof cannot be closed
If the moonroof cannot be closed with the moonroof switch, you can
close the moonroof manually.
1. Take out the moonroof wrench and screwdriver from the tool bag.
HB9007BB
HB9006BA
2. Remove the map light lens by prying the edge of the lens with a regu-
lar screwdriver, then remove the switch body retaining screws and take
off the moonroof switch.
HB9008BA
3. Insert the wrench in the end of the motor shaft.
To lower the moonroof, turn the wrench clockwise.
To close the moonroof, turn the wrench counterclockwise.
Have your vehicle checked by an authorized SUBARU dealer.

10-4
wax to restore the original luster. Frequent polishing with a compound or
an incorrect polishing technique will result in removing the paint layer
and exposing the undercoat. When in doubt, it is always best to contactyour SUBARU dealer or an auto paint specialist. Cleaning aluminum wheels
Promptly wipe the aluminum wheels clean of any kind of grime or
agent. If dirt is left on too long, it may be difficult to clean off. Do not use soap containing grit to clean the wheels. Be sure to use a
neutral cleaning agent, and later rinse thoroughly with water. Do not
clean the wheels with a stiff brush or expose them to a high-speed wash-ing device. Clean the vehicle (including the aluminum wheels) with water as soon
as possible when it has been splashed with sea water, exposed to sea
breezes, or driven on roads treated with salt or other agents. Cleaning fog light lens
HBA017BB
1. Stop the vehicle in a safe place.
2. Stop the engine and turn off the fog lights.
3. Check that the fog lights are not hot. Then, grasp the protector and
turn it approximately 10 ° counter-clockwise.
4. Pull the protector off the fog light.
5. Wash the lens with water.
6. Apply the protector to the lens at an angle of approximately 10 ° from
