26-05-2003
YOUR 206 IN DETAIL
84
SUMMARY TABLE FOR FITTING CHILD SEATS (saloon and 206 SW) In accordance with the European regulation (Directive 2000/3), the table below indicates the options for the installation of child restraints, depending on the weight group and the seat in the vehicle:
U : universal category
U F : universal category, forward-facing.
X : no child restraint.According to destination:
L1 : BRITAX Babysure E11 0344117 Universal (birth to 13 kg).
L2 : ROMER Prince E1 03301058 Universal (9 to 18 kg).
L3 : ROMER Vario E1 03301120 Universal (15 to 25 kg).
L4 : RECARO Start E1 03301108 Universal (15 to 36 kg).
L5 : KLIPPAN Optima E17 030007 Universal (15 to 36 kg).
L6 : KIDDY Isofix Rearwards facing (c)
E1 03301123 and Universal (birth to 13 kg).
L7 : KIDDY Isofix Forwards facing (c)
E2 030011 Universal (9 to 18 kg).
(a) Group 0: from birth to 10 kg.
(b) The rules for transporting children in the front passenger seat are specific to each country. Consult the current legisla- tion in your country.
(c) See section "Seats - Isofix mountings" for use of the KIDDY child seat on the vehicle's Isofix mountings, or failing this with the seat belt. Statutory weight group
Seat Group 0(a)
at 0+ Group 1 Group 2 Group 3
< 13 kg 9 - 18 kg 15 - 25 kg 22 - 36 kg
Front passenger (b)
UU UU
Fixed seat, Height adjustable seat L1, L6 L2, L7 L3, L4, L5 L4, L5
Rear passenger UU UU
Side seat L1, L6 L2, L7 L3, L4, L5 L4, L5
Rear passenger X U F U F U F
Centre seat L2 L3, L4, L5 L4, L5
Three-point seat belt
Rear passenger X U F U F U F
Centre seat L2 L3
Two-point seat belt
26-05-2003
YOUR 206 IN DETAIL85
Statutory weight group
Seat Group 0(a)
at 0+ Group 1 Group 2 Group 3
< 13 kg 9 - 18 kg 15 - 25 kg 22 - 36 kg
Front passenger (b)
UU UU
Rear passenger L1, L6 L2, L7 L3, L4, L5 L4, L5
Side seat
SUMMARY TABLE FOR FITTING CHILD SEATS (206 RC*) In accordance with the European regulation (Directive 2000/3), the table below indicates the options for the installation of child restraints, depending on the weight group and the seat in the vehicle:
U : universal category According to destination:
L1 : BRITAX Babysure E11 0344117 Universal (birth to 13 kg).
L2 : ROMER Prince E1 03301058 Universal (9 to 18 kg).
L3 : ROMER Vario E1 03301120 Universal (15 to 25 kg).
L4 : RECARO Start E1 03301108 Universal (15 to 36 kg).
L5 : KLIPPAN Optima E17 030007 Universal (15 to 36 kg).
L6 : KIDDY Isofix Rearwards facing (c)
E1 03301123 and Universal (birth to 13 kg).
L7 : KIDDY Isofix Forwards facing (c)
E2 030011 Universal (9 to 18 kg).
(a) Group 0: from birth to 10 kg.
(b) The rules for transporting children in the front passenger seat are specific to each country. Consult the current legisla- tion in your country.
(c) See section "Seats - Isofix mountings" for use of the KIDDY child seat on the vehicle's Isofix mountings, or failing this with the seat belt.
* During the year, according to destination.
