2003 NISSAN MAXIMA jump start

6 In case of emergencyFlat tire ...................................................................... 6-2
Changing a flat tire ............................................... 6-2
Jump starting............................................................. 6-6
Push starting ............................................................. 6-8If your vehicle overheats ........................................... 6-9
Towing your vehicle ................................................ 6-10
Towing recommended by NISSAN .................... 6-10
Vehicle recovery (Freeing a stuck vehicle) ........ 6-11
Z
02.7.12/A33-D/V5.0
X

Stowing the damaged tire and toolsSecurely store the spare tire and jacking
equipment in the vehicle.
WARNING
IAlways make sure that the spare tire
and jacking equipment are properly
secured after use. Such items can
become dangerous projectiles in an
accident or sudden stop.
IThe T-type spare tire and small sizespare tire are designed for emer-
gency use. See ªWheels and tiresº in
the ª8. Maintenance and do-it-
yourselfº section.To start your engine with a booster battery, the
instructions and precautions below must be
followed.
WARNING
IIf done incorrectly, jump starting can
lead to a battery explosion, resulting
in severe injury or death. It could also
damage your vehicle.
IExplosive hydrogen gas is always
present in the vicinity of the battery.
Keep all sparks and flames away from
the battery.
IDo not allow battery fluid to come
into contact with eyes, skin, cloth or
painted surfaces. Battery fluid is a
corrosive sulphuric acid solution
which can cause severe burns. If the
fluid should come into contact with
anything, immediately flush the con-
tacted area with water.
IKeep battery out of the reach of
children.
SCE0040
JUMP STARTING
6-6
In case of emergency
Z
02.7.12/A33-D/V5.0
X

IThe booster battery must be rated at
12 volts. Use of an improperly rated
battery can damage your vehicle.
IWhenever working on or near a bat-
tery, always wear suitable eye protec-
tors (for example, goggles or indus-
trial safety spectacles) and remove
rings, metal bands, or any other jew-
elry. Do not lean over the battery
when jump starting.
IDo not attempt to jump start a frozen
battery. It could explode and cause
serious injury.
IYour vehicle has an automatic engine
cooling fan. It could come on at any
time. Keep hands and other objects
away from it.
WARNING
Always follow the instructions below.
Failure to do so could result in damage
to the charging system and cause per-
sonal injury.
1. If the booster battery is in another vehicle,
position the two vehicles to bring their bat-
teries into close proximity to each other.
Do not allow the two vehicles to touch.
2. Apply parking brake. Move the shift lever tothe N (Neutral) position (On automatic
transmission models, move the selector
lever to the P (Park) position). Switch off all
unnecessary electrical systems (light,
heater, air conditioner, etc.).
3. Remove vent caps on the battery (if so
equipped). Cover the battery with an old
cloth to reduce explosion hazard.
4. Connect jumper cables in the sequence as
illustrated.
SCE0392
In case of emergency
6-7
Z
02.7.12/A33-D/V5.0
X

tery which can generate heat, reduce
battery life, and in some cases lead to
an explosion.
IWhen working on or near a battery,
always wear suitable eye protection
and remove all jewelry.
IBattery posts, terminals and related
accessories contain lead and lead
compounds. Wash hands after han-
dling.
IKeep the battery out of the reach of
children.
Check the fluid level in each cell. It should be
between the MAX and MIN lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening.Do not overfill.
Vehicles operated in high temperatures or
under severe conditions require frequent
checks of the battery fluid level.
1. Remove the cell plugs.
2. Add distilled water up to the MAX level.
3. Tighten cell plugs.
JUMP STARTINGIf jump starting is necessary, see ªJump start-
ingº in the ª6. In case of emergencyº section. If
the engine does not start by jump starting, the
battery may have to be replaced. Contact your
NISSAN dealer.
DI0137M
8-16
Maintenance and do-it-yourself
Z
02.7.12/A33-D/V5.0
X

Gas cap .......................................................... 3-12
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ....................................... 8-2
Glove box........................................................ 2-27
Glove box lock ................................................ 2-27
H
Hazard warning flasher switch........................ 2-22
Head restraints ................................................. 1-6
Headlights
Bulb replacement ...................................... 8-27
Headlight switch ........................................ 2-19
Xenon headlights....................................... 2-19
Heated seats................................................... 2-23
Heated steering wheel (if so equipped).......... 2-24
Heater
Engine coolant heater ............................... 5-21
Heater and air conditioner controls ............. 4-3
Heater operation.......................................... 4-3
Heater operation, Semiautomatic air
conditioner ........................................................ 4-4
HomeLink
Universal Transceiver .................. 2-37
Hood, release ................................................. 3-10
Horn ................................................................ 2-22
How to stop alarm, Vehicle security ............... 2-15I
Ignition switch ................................................... 5-4
Automatic transmission models ........... 5-4, 5-8
Key positions ............................................... 5-6
Manual transmission models ............. 5-5, 5-11
Immobilizer system ......................................... 2-15
Indicator lights................................................. 2-12
Inspection/maintenance (I/M) test................... 9-21
Instrument panel ............................................... 2-2
Interior light ..................................................... 2-34
Interior light replacement ................................ 8-28
Interior trunk lid release .................................. 3-12
ISOFIX child restraint ..................................... 1-34
J
Jump starting .................................................... 6-6
K
Keyless entry .................................................... 3-4
Keys .................................................................. 3-2
L
Label, Air conditioner specification label ........ 9-12
Label, Emission control information label ....... 9-11
Label, F.M.V.S.S. certification label................ 9-11
Labels
Air bag warning labels............................... 1-18
Engine serial number ................................ 9-11Vehicle identification number (VIN)........... 9-10
LATCH system................................................ 1-34
License plate, Installing front license plate..... 9-13
Light
Air bag warning light ................................. 1-18
Bulb replacement ...................................... 8-26
Fog light switch ......................................... 2-21
Headlight switch ........................................ 2-19
Headlights Bulb replacement .................... 8-27
Interior light................................................ 2-34
Personal light............................................. 2-35
Replacement ............................................. 8-26
Trunk light.................................................. 2-36
Vanity mirror light ...................................... 2-36
Warning/indicator lights and audible
reminders ........................................... 2-9, 2-12
Xenon headlights....................................... 2-19
Lights, Exterior and interior light
replacement .................................................... 8-28
Loading information (See vehicle loading
information) ..................................................... 9-14
Lock
Door locks ................................................... 3-2
Glove box lock........................................... 2-27
Power door lock .......................................... 3-2
Trunk lid lock opener lever........................ 3-10
Low fuel warning light ..................................... 2-11
M
Maintenance
Battery ....................................................... 8-15
General maintenance .................................. 8-2
Inside the vehicle ........................................ 8-3
Z
02.7.12/A33-D/V5.0
X
10-3

Seat belts .................................................. 1-20
Three-point type with retractor .................. 1-23
Seat(s)
Heated seats ............................................. 2-23
Seats ........................................................... 1-2
Security system, vehicle security system ....... 2-14
Security systems (Nissan Vehicle Immobilizer
System), Engine start ..................................... 2-15
Security systems (See vehicle security
system) ........................................................... 2-14
Servicing air conditioner .......................... 4-3, 4-12
Shift lock release ............................................ 5-10
Shifting
Automatic transmission ........................ 5-4, 5-8
Manual transmission .......................... 5-5, 5-11
Shoulder belt height adjustment, For front
seats ............................................................... 1-26
Side air bag system (See supplemental side air
bag system) .................................................... 1-15
Spark plugs ..................................................... 8-17
Speedometer .................................................... 2-4
Starting
Before starting the engine ........................... 5-7
Jump starting ............................................... 6-6
Precautions when starting and driving ........ 5-2
Push starting ............................................... 6-8
Starting the engine ...................................... 5-7
Steering
Power steering fluid................................... 8-14
Power steering system .............................. 5-17
Tilting steering wheel ................................ 3-14
Storage ........................................................... 2-26
Sunglasses holder .......................................... 2-26
Sun shade....................................................... 2-31Sun visors ....................................................... 3-15
Sunroof ........................................................... 2-31
Supplemental air bag warning labels ............. 1-18
Supplemental air bag warning light ....... 1-18, 2-11
Supplemental front air bag system ................. 1-13
Supplemental restraint system ......................... 1-8
Precautions on supplemental restraint
system ......................................................... 1-8
Supplemental side air bag system ................. 1-15
Switch
Fog light switch ......................................... 2-21
Hazard warning flasher switch .................. 2-22
Headlight switch ........................................ 2-19
Ignition switch .............................................. 5-4
Ignition switch automatic transmission
models.................................................. 5-4, 5-8
Ignition switch manual transmission
models................................................ 5-5, 5-11
Power door lock switch ............................... 3-4
Rear window and outside mirror defogger
switch......................................................... 2-17
Traction control system cancel switch ...... 2-24
Turn signal switch ..................................... 2-21
T
Tachometer ....................................................... 2-4
Temperature gauge, Engine coolant temperature
gauge ................................................................ 2-5
Theft (Nissan Vehicle Immobilizer System),
Engine start..................................................... 2-15
Three way catalyst ............................................ 5-3
Tilting steering wheel ...................................... 3-14Tire
Flat tire ........................................................ 6-2
Uniform tire quality grading ....................... 9-19
Tires
Spare tire ................................................... 8-37
Tire chains ................................................. 8-34
Tire placard ............................................... 9-12
Tire pressure ............................................. 8-33
Tire rotation ............................................... 8-35
Types of tires............................................. 8-33
wheel/tire size.............................................. 9-9
Wheels and tires ....................................... 8-33
Top tether strap child restraints ...................... 1-35
Towing
Tow truck towing ....................................... 6-10
Towing a trailer.......................................... 9-15
Towing load/specification chart ................. 9-15
Towing safety ............................................ 9-17
Traction control system .................................. 5-19
Traction control system (TCS) cancel
switch .............................................................. 2-24
Trailer towing .................................................. 9-15
Transceiver, HomeLink
Universal
Transceiver ..................................................... 2-37
Transmitter ........................................................ 3-4
Transmission
Automatic transmission fluid (ATF) ........... 8-12
Driving with automatic transmission .... 5-4, 5-8
Driving with manual transmission ...... 5-5, 5-11
Transmission selector lever lock
release ....................................................... 5-10
Traveling or registering your vehicle in another
country ............................................................ 9-10
Trip computer.................................................. 2-32
Z
02.7.12/A33-D/V5.0
X
10-5
