2003 MERCEDES-BENZ SL-Class CD player

1
Where to find itIntroduction

Where to find itThis Operator's Manual is designed to pro-
vide support information for you, the
COMAND operator. Each chapter has its
own guide color to provide fast access to
information.At a glance
Here you will find an overview of
all COMAND control elements and system
components. If you are operating
COMAND for the first time or if you have
rented or borrowed the vehicle, this is the
chapter you should read first.
Audio
Here you will find all the information on
how to use the radio, CD player, CD chan-
ger and adjust the audio system settings.Telephone*
Here you can learn in detail about the
many functions of the telephone, SMS,
how to initiate an emergency call and use
service numbers.Navigation
Here you will find detailed information re-
garding the following topics:
Destination input

Route selection and calculation

Route guidance including detour

Working with the destination memory
Info Services* and System settings
This chapter provides information on how
to:
Request and display info services such
as news, weather, stocks and sports

the COMAND system set-up.
Directories
The glossary explains the most important
technical terms.
The table of contents and index directory
will help you quickly locate the information
you need.

11 At a glance
Multifunction display

Multifunction display
The starter switch is in position 1 or 2. Re-
fer to vehicle operating instructions.
You can operate the following systems
with steering wheel buttons 5 and 6:

Radio

CD (CD changer and CD drive)

Auxiliary audio source, e.g. tape player
(page 200)

Telephone
For more detailed information, refer to
“Multifunction display” in the chapters dis-
cussing the radio, CD and telephone ope-
ration.
Function
1
Left display in speedometer
2
Right display in tachometer
Operating the control system
3
Adjusting the volume
I lowers the volume
J raises the volume
4
Making a call
K Accept incoming call or
starts dialing
L End a call or end Tele Aid
5
Switching from system to system
E next system
H previous system
6
Switching in the system
F next display
G previous displayFunction

200 Info Services/System settingsAuxiliary audio source

Auxiliary audio sourceThe auxiliary audio source (e.g. tape recor-
der) will be installed in the glove compart-
ment of your vehicle and connected to the
socket available for this purpose. You will
require a separate connecting cable for
this.COMAND will play back voice outputs du-
ring route guidance even if the auxiliary au-
dio source has been switched on.
It is possible to use the telephone while the
auxiliary audio source is in operation.
1Adjusting sound settings (
page 63)
ConnectingiMercedes-Benz recommends that any
auxiliary audio unit is installed and con-
nected by an authorized Mercedes-
Benz Center.
iRefer to the seperate operating instruc-
tions for information on how to operate
the auxiliary audio source (e.g. tape
player).
Switching auxiliary audio source on
P82.85-7724-31
1

201 Info Services/System settings
Auxiliary audio source

Turn the right-hand rotary/push-
button v to highlight “AUX” in the
main system settings menu and press
to confirm.
The “AUX” menu will appear. The auxi-
liary audio source will switch on if it has
been connected to the COMAND cont-
rol unit.
Adjusting the volume (
page 14).Adjusting the volume level of an auxilia-
ry audio source

Adjust volume of vehicle radio to a
comfortable listening level.

Connect adapter cable to, for example,
a portable tape player and to vehicle
(socket in glove box).

Press ( button on COMAND unit.

Activate the “AUX” menu as described.

Press “Play” button on the portable
tape player.

Adjust the volume on the portable tape
player so that the audio system output
is at or near the same comfortable level
previously set in radio mode.

Volume can now be adjusted using
either COMAND or volume controls on
multifunction steering wheel.Muting auxiliary audio source

Press Ö.
Symbol R will appear.
Canceling mute function

Press Ö again.
Symbol R will disappear.
iThe sound adjustments for the auxiliary
audio source are independent of those
selected for the COMAND audio sour-
ces.
iOnly the volume setting of the tape play-
er can be controlled using the
COMAND system.

203 Glossary
Audio source
This includes the systems radio and CD
(CD drive in the control unit and CD
changer) as well as an auxiliary audio
source, e.g. tape player.
COMAND
(Co
ckpit Man
agement and D
ata Sys-
tem)
Information and operating center for
vehicle sound and communications
systems, including the radio and CD
player, as well as for other optional
equipment (CD changer, telephone*,
etc.).
Emergency call
This function places a call to a local
9-1-1 provider. It does not initiate a
->TELE AID call. Please note that the
9-1-1 emergency call system is a public
service. Using it without due cause is a
criminal offense.GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special re-
ceivers. Employs CD digital maps for
navigation.
Heading-up
The map is displayed facing driving di-
rection pointing up during route
guidance.
Info Services*
With this function you can request in-
formation on news, weather, stocks,
sports and reminders. Info Services is
an additional optional feature to basic
Tele Aid service. Tele Aid can be initial-
ly activated by completing a subscriber
agreement and placing an acquain-
tance call. Mix
Display representation during route
guidance. The symbol display is activa-
ted automatically from the map display
before making a turn. After you have
made the turn, the map will appear
again.
Multifunction display
Two displays in the combination instru-
ment that show important information
about the COMAND systems radio, CD,
telephone* and navigation. The dis-
plays can be called up using the control
buttons on the multifunction steering
wheel.
Navigation CD
Contains all the destination addresses
(town, road, intersection, house num-
ber, special destinations) and the digi-
tal map material for a country or a
region for destination entry, route cal-
culation and route guidance.
