2003 MERCEDES-BENZ E-CLASS check engine

Contents
Adjusting air distribution .............. 177
Adjusting air volume .................... 177
Defrosting .................................... 178
Air recirculation mode.................. 178
Charcoal filter .............................. 180
Rear window defroster ................. 180
Air conditioner ............................. 181
Residual heat and ventilation ....... 182
Rear air conditioning .................... 182
Power windows.................................. 184
Opening and closing the windows 184
Synchronizing power windows ..... 186
Sliding/pop-up roof* ......................... 187
Opening and closing the slid-
ing/pop-up roof* ......................... 187
Synchronizing the
sliding/pop-up roof ...................... 189
Panorama sliding/pop-up roof*......... 190
Panorama sliding/pop-up roof* ... 190
Solar panel* ................................. 193
Driving systems ................................. 194
Cruise control .............................. 194
Distronic* .................................... 197
AIRMATIC DC (Dual Control)* ...... 209
PARKTRONIC system* ................. 212
Loading.............................................. 216Roof rack ...................................... 216
Ski sack* ...................................... 216
Split rear bench seat*................... 219
Folding front passenger seat* ...... 222
Expanding the cargo area* ........... 223
Loading instructions ..................... 224
Cargo tie-down rings ..................... 225
Useful features ................................... 226
Interior storage spaces ................. 226
Ashtrays........................................ 231
Cigarette lighter ............................ 232
12-V socket* ................................ 232
Heated steering wheel* ................ 233
Telephone* ................................... 233
Tele Aid* ....................................... 234
Garage door opener ...................... 243
Operation.......................................... 247
The first 1000 miles (1500km) ........... 248
Driving instructions ............................ 249
Drive sensibly – save fuel.............. 249
Drinking and driving ...................... 249
Pedals ........................................... 249
Power assistance .......................... 250
Brakes........................................... 250Driving off ..................................... 252
Parking ......................................... 252
Tires.............................................. 252
Aquaplaning .................................. 253
Tire traction .................................. 253
Tire speed rating ........................... 254
Winter driving instructions ............ 254
Standing water ............................. 255
Passenger compartment............... 255
Traveling abroad ........................... 255
Control and operation of radio
transmitter.................................... 256
Catalytic converter ....................... 256
Emission control ........................... 257
Coolant temperature .................... 258
At the gas station ............................... 259
Check regularly and before
a long trip ..................................... 260
Engine compartment .......................... 261
Hood ............................................. 261
Engine oil ...................................... 262
Transmission fluid level ................ 264
Coolant level ................................. 264
Battery .......................................... 266
Windshield washer system and
headlamp cleaning system* ......... 267
ProCarManuals.com

48 Getting startedDrivingSingle wipe
Press switch briefly in the direction of
arrow1.
The windshield wipers wipe one time
without washer fluid.
Wiping with windshield washer fluid

Push switch in the direction of arrow1
past the resistance point.
The windshield wiper operates with
washer fluid.
Information on filling up the washer reser-
voir can be found in the "Operation" sec-
tion (page 267).
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an au-
thorized Mercedes-Benz Center as
soon as possible.
!If leaves, snow, etc. block the wind-
shield wipers, switch off the wipers.

For safety reasons, withdraw key
from starter switch. Remove block-
age.


Turn the windshield wipers on
again.
If windshield wipers fail to function at
all in switch positionI,


Set the combination switch to the
next highest wiper speed.


Have the windshield wipers
checked at the nearest authorized
Mercedes-Benz Center.
ProCarManuals.com

49 Getting started
Driving
The coolant temperature is over 248°F
(120°C)
The coolant is too hot and is no longer
cooling the engine.
Stop the vehicle as soon as possible
and turn off the engine. Allow engine
and coolant to cool.

Check the coolant level and add cool-
ant if necessary (
page 264).In case of accident
If the vehicle is leaking gasoline:

Do not start the engine under any cir-
cumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Center.If no damage can be determined on the


major assemblies


fuel system


engine mount

Start the engine in the usual manner.
ProCarManuals.com

91 Controls in detail
Locking and unlocking
system, the vehicle cannot be locked
or the engine started via the KEY-
LESS-GO system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the key), the mes-
sage
Key not recognized!
will appear
in the multifunction display.
Find the key or change its present loca-
tion immediately (e.g. place it on the
front passenger seat or insert it in shirt
pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the card behind
when exiting and locking the vehicle,
the message
Key recognized in vehi-
cle!
will appear in the multifunction
display.Factory setting
Global unlocking

Grasp the door handle.
The vehicle will lock again automatically
within approximately 40 seconds if neither
door nor trunk is opened.Global locking

Press lock button at door handle
(page 53) or trunk lid (
page 92).
iThe vehicle could be inadvertently un-
locked if the SmartKey with KEY-
LESS-GO is within 3 ft. (1 m) of the
vehicle and

the door handle is splashed with
water, or


you attempt to clean the door
handle.
!If you cannot lock or unlock the vehicle
with the SmartKey with KEYLESS-GO,
then either the batteries of the key are
discharged or the key is malfunction-
ing.

Check the batteries of the Smart-
Key with KEYLESS-GO (
page 88)
and replace them if necessary
(
page 328).


Use the mechanical key to unlock
the driver’s door (
page 327) and
trunk lid (
page 328) as required.
Lock the vehicle using the mechan-
ical key (
page 328).
If your SmartKey with KEYLESS-GO is
malfunctioning, contact your autho-
rized Mercedes-Benz Center.
ProCarManuals.com

114 Controls in detailLightingDaytime running lamp mode
Turn exterior lamp switch to
positionM orU.
When the engine is running, the low beam
headlamps are automatically switched on.
In low ambient light conditions the parking
lamps will also switch on.
Canada only
When you shift from a driving position to
positionN orP, the low beam switches off
(with a three-minute delay).
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam head-
lamps.
USA only
The high beam headlamps can also be ac-
tivated when driving with the daytime run-
ning lamp mode activated and exterior
lamp switch in positionM.To activate the daytime running lamp
mode, see "Setting daytime running lamp
mode" (
page 139).
Locator lighting and night security illu-
mination
Locator lighting and night security illumi-
nation are described in the control system
section under "Setting locator lighting"
(
page 139) and "Setting night security il-
lumination" (
page 140).
Switching on front fog lamps

Check that the low beam headlamps
are switched on.

Pull out exterior lamp switch to first
stop.
The green indicator lamp‡ in the
lamp switch lights up.Switching on rear fog lamp

Check that the low beam headlamps
are switched on.

Pull out e xt eri or la m p swi tc h to s ec ond
stop.
The yellow indicator lamp† in the
lamp switch lights up.
iSee notes on the exterior lamp switch
(page 112).
iFog lamps will operate with the parking
lamps and/or the low beam headlamps
on. Fog lamps should only be used in
conjunction with low beam headlamps.
Consult your State or Province Motor
Vehicle Regulations regarding allow-
able lamp operation.
ProCarManuals.com

119 Controls in detail
Instrument cluster
Coolant temperature displayDuring severe operating conditions and
stop-and-go city traffic, the coolant tem-
perature may rise close to 248°F (120°C).
The engine should not be operated with
the coolant temperature above 248°F
(120°C). Doing so may cause serious en-
gine damage which is not covered by the
Mercedes-Benz Limited Warranty.
Trip odometer
Check to see that the trip odometer
and main odometer (
page 121) ap-
pear in the multifunction display.

Press and hold the reset knob on the in-
strument cluster (
page 22) until the
trip odometer is reset.
Warning!
G


Driving when your engine is badly over-
heated can cause some fluids which
may have leaked into the engine com-
partment to catch fire. You could be se-
riously burned.


Steam from an overheated engine can
cause serious burns and can occur just
by opening the engine hood. Stay away
f r o m t h e e n g i n e i f y o u s e e o r h e a r s t e a m
coming from it.
Turn off the engine, get out of the vehicle
and do not stand near the vehicle until it
cools down.iExcessive coolant temperatures trigger
a warning in the multifunction display.
ProCarManuals.com

125 Controls in detail
Control system
Menus, submenus and functions
Menu 1
Menu 2
Menu 3
Menu 4
Menu 5
Menu 6
Menu 7
Menu 8
Commands/submenusStandard dis-
play
AUDIO
NAVI*
Distronic*
Malfunction
memory
Settings
Trip computer
Telephone
Digital speed-
ometer
Select radio
station
Activate
route guid-
ance
Call up set-
tings
Call up malfunc-
tion messages
Reset to factory
settings
Fuel consumption
statistics after
start
Load phone
book
Call up FSS
PLUS
Operate CD
player*
Instrument clus-
ter submenu
Fuel consumption
statistics since
the last reset
Search for
name in
phone book
Check tire pres-
sure*
Operate cas-
sette player
Time/Date sub-
menu
Call up range
Check engine oil
level
Lighting sub-
menuVehicle sub-
menuConvenience
submenuDynamic driving
seat* submenu
ProCarManuals.com

126 Controls in detailControl system
Standard display menu
You can select the functions in the stan-
dard display menu with buttonk
orj.
The following functions are available:
Display digital speedometer
Press buttonj twice.
The current vehicle speed is shown in
the multifunction display.
AUDIO menu
The functions in the
Audio
menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO OFF
is shown in the
display.
The following functions are available:
iThe headings used in the menus table
are designed to facilitate navigation
within the system and are not neces-
sarily identical to those shown in the
control system displays.
The first function displayed in each
menu will automatically show you
which part of the system you are in.
Function
Page
Call up digital speedometer
see
below
Call up FSS PLUS
275
Check tire pressure*
270
Check engine oil level
262
Function
Page
Select radio station
127
Operate CD player*
127
Operate cassette player
128
ProCarManuals.com
