Page 325 of 399
325 Practical hints
Where will I find ...?
Minispare wheel
In the case of a flat tire, you may tempo-
rarily use the Minispare* wheel when ob-
serving the following restrictions:
Do not exceed a vehicle speed of
50 mph (80km/h).
Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.
Do not operate vehicle with more than
one spare wheel mounted.More information can be found in the
"Technical data" section (
page 362).
Luggage box
Remove luggage box
1Fastening clip
2Luggage box
Turn fastening clips1 to the left up-
wards from fastening bolts.
Lift luggage box in the area of the fas-
tening bolts and remove it from trunk.Install luggage box
Insert luggage box into trunk so that
fastening clips are in line with fastening
bolts.
Push front edge of luggage box in direc-
tion of arrow under cover of trunk sill.
Press fastening clips onto fastening
bolts until they lock into place.
Warning!
G
The dimensions of the Minispare* wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare*
wheel mounted.
The spare wheel should only be used tempo-
rarily, and replaced with a regular road
wheel as quick as possible.
ProCarManuals.com
Page 328 of 399
328 Practical hintsUnlocking/locking in an emergencyUnlocking the trunk
The trunk can no longer be locked with the
key.
Lock and unlock the trunk with the me-
chanical key as follows:Trunk lid lock1Unlocking
2Locking
Insert the mechanical key in the trunk
lid lock.
Turn the key to the left in position1
and hold it in this position.
Pull on the trunk lid handle and lift the
trunk lid.
Locking the vehicle
If you are unable to lock the vehicle with
the SmartKey, lock it with the mechanical
key as follows:
Close the passenger doors and the
trunk.
Press the central locking switch in the
cockpit (
page 100).
Check to see whether the locking
knobs on the passenger doors are still
visible. If necessary, push them down
manually.
Lock the driver’s door with the me-
chanical key (
page 327).
Check if the trunk is locked. If neces-
sary lock the trunk with the mechanical
key (
page 98).
Changing batteries
If the batteries in the SmartKey are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an autho-
rized Mercedes-Benz Center.
Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
ProCarManuals.com
Page 333 of 399
333 Practical hints
Replacing bulbs
Rear lamps Notes on bulb replacement
Use only 12-volt bulbs of the same type
and with the specified watt rating.
Switch lights off before changing a bulb
to prevent short circuits.
Always use a clean lint-free cloth when
handling bulbs.
Y o u r h a n d s s h o u l d b e d r y a n d f r e e o f o i l
and grease.
If the newly installed bulb does not light
up, visit an authorized Mercedes-Benz
Center.
Have the LEDs and bulbs for the follow-
ing lamps replaced by an authorized
Mercedes-Benz Center:
Additional turn signal lamps in the
exterior rear view mirrors
High mounted brake lamp
Bi-Xenon lamps
Front fog lamps
Lamp
Type
7
High mounted brake
lamp
LED
8
Tail, parking and
standing lamp
HiP
9
License plate lamps
C 5 W
Warning!
G
Keep bulbs out of reach of children.
Bulbs and bulb sockets can be very hot. Al-
low the lamp to cool down before changing
a bulb.
Halogen lamps contain pressurized gas. A
bulb can explode if you:
touch or move it when hot
drop the bulb
scratch the bulb
Wear eye and hand protection.
Because of high voltage in Bi-Xenon lamps,
it is dangerous to replace the bulb or repair
the lamp and its components. We recom-
mend that you have such work done by a
qualified technician.
ProCarManuals.com
Page 334 of 399
334 Practical hintsReplacing bulbsReplacing bulbs for front lamps
1Bulb socket for turn signal lamp
2High beam bulb
3Bulb socket for parking and standing
lamp
High beam bulb (Halogen headlamps
only)
Switch off the lights.
Open the hood (
page 261).
Press the clamp and remove headlamp
cover.
Pull electrical connector off.
Turn the locking mechanism counter-
clockwise and take out the high beam
bulb2.
Insert the new high beam bulb so that
the base is in the recess of the holder.
Turn the locking mechanism clockwise.
Plug the connector onto the high beam
bulb.
Align headlamp cover and click into
place.
High beam bulb (Bi-Xenon* headlamps
only)
Switch off the lights.
Open the hood (
page 261).
Press the clamp and remove headlamp
cover.
Pull electrical connector off.
Turn the locking mechanism counter-
clockwise and take out the high beam
bulb2.
Insert the new high beam bulb so that
the base is in the recess of the holder.
Turn the locking mechanism clockwise.
Plug the connector onto the high beam
bulb.
Align headlamp cover and click into
place.
Warning!
G
Because of high voltage in Bi-Xenon lamps,
it is dangerous to replace the bulb or repair
the lamp and its components. We recom-
mend that you have such work done by a
qualified technician.
ProCarManuals.com
Page 336 of 399
336 Practical hintsReplacing bulbsReplacing bulbs for rear lamps
Tail lamp assemblies
The tail lamps are equipped with HiP bulbs.License plate lamp
1Screw
Switch off the lights.
Loosen both screws1 and remove
lamp.
Replace the tubular lamp and reinstall
lamp.
Retighten the screws.
!To prevent scratches, we recommend
that you have the sidemarker bulb re-
placed by an authorized Mer-
cedes-Benz Center.Warning!
G
The bulbs in the tail lamps cannot be re-
placed individually. The tail lamp bulbs are
under pressure and could explode during an
attempt to replace them.
If the tail lamps are malfunctioning, have
them exchanged at an authorized Mer-
cedes-Benz Center.
ProCarManuals.com
Page 337 of 399
337 Practical hints
Replacing wiper blades
Replacing wiper blades
Replacing wiper blades
Removal
Turn key in starter switch to position1.
Turn combination switch to wiper
settingII (
page 47).
With wiper arm in the vertical position
(see above), turn key in starter switch
to position0.
Fold the wiper arm forward.You should hear it snap into place.
Turn the wiper blade at a right angle to
wiper arm.
Slide the wiper blade sideways out of
the retainer.Installation
Slide wiper blade onto wiper arm until
it locks in place.
Rotate wiper blade into position paral-
lel to wiper arm.
Fold wiper arm back so that blade rests
on windshield.
!To avoid damage to the hood, the wiper
arms should only be folded forward
when in the vertical position.Warning!
G
For safety reasons, remove key from starter
switch before replacing a wiper blade, other-
wise the motor could suddenly turn on and
cause injury.
!Never open the hood when the wiper
arm is folded forward.
Do not allow the wiper arms to contact
the windshield glass without a wiper
blade inserted.
For your convenience, we recommend
that you have this work carried out by
an authorized Mercedes-Benz Center.
ProCarManuals.com
Page 338 of 399
338 Practical hintsFlat tire
Flat tirePreparing the vehicle
Park the vehicle as far as possible from
moving traffic on a hard surface.
Turn on the hazard warning flashers.
Engage the steering wheel lock in the
straight-ahead position and set the
parking brake.
Move the selector lever toP.
Have any passenger exit the vehicle at
a safe distance from the roadway.
Mounting the spare wheel
Preparing the vehicle
Prepare the vehicle as described under
"Preparing the vehicle" on this page.
Take the spare wheel out of the trunk
(page 324).
Lifting the vehicle
Prevent the vehicle from rolling away
by blocking wheels with wheel chocks
(not included) or other sizable objects.
When changing wheel on a level surface:
Place one chock in front of and one be-
hind the wheel that is diagonally oppo-
site to the wheel being changed.When changing wheel on a hill:
Place chocks on the downhill side
blocking both wheels of the other axle.
Take the two-piece wheel wrench and
the jack out of the trunk (
page 326).
Assemble wheel wrench.
Warning!
G
The jack is designed exclusively for jacking
up the vehicle at the jack take-up brackets
built into either side of the vehicle. To help
avoid personal injury, use the jack only to lift
the vehicle during a wheel change. Never
get beneath the vehicle while it is supported
by the jack. Keep hands and feet away from
the area under the lifted vehicle. Always
firmly set parking brake and block wheels
before raising vehicle with jack.
Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
ProCarManuals.com
Page 340 of 399
340 Practical hintsFlat tire
Removing the wheel
1Alignment bolt
Unscrew the upper-most wheel bolt
and remove.
Replace this wheel bolt with alignment
bolt1 supplied in the tool kit.
Remove the remaining bolts.
Remove the wheel.Mounting the Minispare wheel
Clean contact surfaces of wheel and
wheel hub.
Guide the spare wheel onto the align-
ment bolt and push it on.
Insert wheel bolts and tighten them
slightly.
Warning!
G
Position the jack only on the jack take-up
brackets designed for this purpose.
If the jack is not properly positioned, the ve-
hicle may slip off of the jack.Warning!
G
The jack is intended only for lifting the vehi-
cle briefly for wheel changes. It is not suited
for performing maintenance work under the
vehicle. Never lie down under the raised ve-
hicle. Do not start the engine when the vehi-
cle is raised.
!Do not place wheel bolts in sand or dirt.
This could result in damage to the bolt
and wheel hub threads.
!To avoid paint damage, place wheel flat
against hub and hold it there while in-
stalling first wheel bolt.
