2003 MERCEDES-BENZ E-CLASS trunk release

98 Controls in detailLocking and unlockingIllumination of the emergency release but-
ton:

The button will blink for 30 minutes af-
ter opening the trunk.


The button will blink for 60 minutes af-
ter closing the trunk.
Separately locking the trunk
The lock is located next to the recessed
handle.
1Unlocked
2Locked

Close the trunk lid (
page 96).

Pull the mechanical key out of the
SmartKey (
page 329).

Insert the mechanical key in the trunk
lid lock.

Turn the key completely to the right to
position2.
The trunk remains locked even when the
vehicle is centrally unlocked.
!The emergency release button does
not open the trunk lid if the vehicle bat-
tery is discharged or disconnected.iIf the emergency release button is
pressed and the vehicle was centrally
locked, the exterior lamps will flash and
the alarm will sound.
To cancel the alarm, insert the key in
the starter switch or press buttonŒ
or ‹ on the key.
iTo deny any unauthorized person ac-
cess to the trunk, lock it separately
with the mechanical key. Leave only
the SmartKey without its mechanical
key inside the vehicle.
iYou can only cancel the separate trunk
locking mode by means of the mechan-
ical key.
ProCarManuals.com

220 Controls in detailLoadingFolding the backrest forward
1Release handle
Pull release handle1.
The seat cushion automatically springs
upward slightly.1Seat cushion
2Seat backrest

Grip the back of seat cushion1 and
fold forward.

Push the rear seat head restraints all
the way in.

Pull the handle in the trunk.
The seat backrest is released and the
head restraints fold back.

Fold the seat backrest forward.
ProCarManuals.com

226 Controls in detailUseful features
Useful featuresInterior storage spaces Parcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Glove box
1Glove box lid release
2Compartment for mobile phone/glass-
es
Opening the glove box

Push lid release1.
The glove box lid opens downward.
Closing the glove box

Push lid up to close.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when stowing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs. Do not place anything on the shelf
below the rear window.
Luggage nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net.
The parcel net cannot protect transported
goods in the event of an accident.
ProCarManuals.com

310 Practical hintsWhat to do if …F
Key recognized
in vehicle!
A KEYLESS-GO* key left in the vehi-
cle was recognized while locking the
vehicle from the outside.

Take the key out of the vehicle.
Key
Visit workshop!
The KEYLESS-GO* system is mal-
functioning.

Visit an authorized Mercedes-Benz Center
as soon as possible.
Key
do not forget key
This display appears (for a maximum
of 60 seconds) if the driver’s door is
opened with the engine shut off and
no key in the starter switch.
This message is only a reminder.

Insert key in the starter switch.
_
Entry position
Do not drive!
Seat, mirrors and steering wheel
have not yet moved to their preset
driving positions.

Wait until the seat, mirrors and steering
wheel have moved to their driving positions.
The message disappears.
Except Canada:;Canada only:!
Release park. brake!
You are driving with the parking
brake set.

Release the parking brake (
page 45).
<
Visit workshop!
The seat belt system is malfunction-
ing.

Visit an authorized Mercedes-Benz Center
as soon as possible.
Ê
Trunk open!
This message will appear whenever
the trunk lid is open.

Close the trunk lid.
Display
Possible cause
Suggested solution
ProCarManuals.com

397 Index
Dialing a number from the phone
book 149
Ending a call 149
Loading phone book* 149
Messages in display 309
Operating 147
Redialing 149
Temperature
Display mode 134
Sensor 27
Setting interior temperature 165,
176
Setting units in display 134
Tie-down rings (trunk) 225
Tightening torque 342, 379
Time
Setting hours 137
Setting minutes 137, 138
Tire inflation pressure
Setting units 136
Tire speed rating 379
Tires 373
Tools 326
Tow-away alarm 82
Arming 82
Disarming 82Disarming for transport 82
Towing eye bolt (vehicle tool kit)
Installing 350
Towing the vehicle 348
Tracking services
For stolen vehicle 242
Traction 155, 379
Trip computer 145
Trip odometer
Resetting 119
Trunk
Closing the lid 96
Lamp 117
Lock button, KEYLESS-GO* 92
Message in display 310
Opening 88, 96
Opening from inside vehicle 94
Separately locking 98
Tie-down rings 225
Trunk lid emergency release 97
Unlocking with KEYLESS-GO* 92
Trunk lid
Closing 96
Turn signals 46
Additional in mirrors 332
Front bulbs 332Turning off
Engine 51
U
Units
Setting speedometer units 134
Setting temperature units 134
Setting tire inflation pressure
units 136
Unlocking 30, 86, 327
Centrally from inside 100
Driver’s door in an emergency 327
Fuel filler flap 259
Global 87
Global with KEYLESS-GO* 91
Selective settings 87
Trunk lid with KEYLESS-GO* 92
Vehicle in an emergency 241
With KEYLESS-GO* 32
With the SmartKey 30
Upgrade signals
Tele Aid* 240
Uphill driving
Cruise control 195
Upshifting 152
Useful features 226
Ashtrays 231
