108 Controls in detailSeatsSeat ventilation*
The seat ventilation switch is located on
the center console. The blue indicator
lamps in the switch show which ventilation
level you have selected.
1Seat ventilation
Make sure that the ignition has been
switched on.
All lamps in the instrument cluster light
up.Switching seat ventilation on
Press button1 repeatedly until the de-
sired ventilation level is set.
Switching seat ventilation off
Press button1 repeatedly until all indi-
cator lamps go out.
Level3
3 indicator lamps lit
2
2 indicator lamps lit
1
1 indicator lamp lit
off
No indicator lamps lit
!The seat ventilation may switch off if
the battery voltage is too low.
iIf seat ventilation is activated through
the summer opening function, seat
ventilation is automatically set to the
highest level.
