Page 8 of 384
ContentsFuses ................................................. 322
Fuse boxes in passenger
compartment................................ 322
Fuse boxes in engine
compartment................................ 324
Emergency engine shut-down ...... 324Technical data.................................. 325
Spare parts service ............................ 326
Warranty coverage ............................. 327
Loss of Service and Warranty
Information Booklet...................... 327
Identification labels............................ 328
Layout of poly-V-belt drive ................. 329
CL 500 ......................................... 329
CL 55 AMG ................................... 329
CL 600 ......................................... 329Engine................................................ 330
Rims and Tires ................................... 331
Same size tires ............................. 332
Mixed size tires ............................ 333
Spare wheel ................................. 333
Electrical system ............................... 334
Main Dimensions ............................... 335
Weights.............................................. 336
Fuels, coolants, lubricants etc. .......... 337
Capacities .................................... 337
Engine oils.................................... 339
Engine oil additives ...................... 339
Air conditioning refrigerant .......... 339
Brake fluid .................................... 340
Premium unleaded gasoline ......... 340
Fuel requirements ........................ 340
Gasoline additives ........................ 341
Coolants....................................... 342
Windshield and headlamp
washer system ............................. 344Consumer information ....................... 345
Uniform tire quality grading ......... 345
Technical terms............................... 347Index................................................. 353
Page 14 of 384
14 IntroductionWhere to find it
Where to find itThis Operator’s Manual is designed to pro-
vide comprehensive support information
for you, the vehicle operator. Each section
has its own reference color so you can find
information quickly.At a glance
Here you will find an overview of all the
controls that can be operated from the
driver’s seat.Getting started
Here you will find all the information you
need for your first drive. You should read
this section first if this is your first
Mercedes-Benz vehicle or if you are rent-
ing or borrowing this vehicle.Safety and Security
H e r e y o u w i l l f i n d d e s c r i p t i o n s o f t h e s a f e t y
features of your vehicle.
Controls in detail
Here you will find detailed information
about the equipment installed in your vehi-
cle. This section expands on the “Getting
started” section and also describes techni-
cal innovations. If you are already familiar
with the basic functions of your vehicle,
this section will be of particular interest to
you.Operation
Here you will find all the information you
need for the proper operation of your vehi-
cle.Practical hints
This section provides fast assistance for
dealing with problems you may encounter.
Technical data
All important technical data for your vehi-
cle can be found in this section.Indexes
The glossary provides explanations of the
most important technical terms.
The table of contents and the index are de-
signed to help you find information quickly
and easily.
The following publications are part of your
vehicle documentation:
this Operator’s Manual
the Service Booklet
Separate operating instructions will be
provided as required depending on the
equipment options installed in your vehi-
cle.
Page 16 of 384
16 IntroductionOperating safety
Operating safety
Proper use of the vehicle
Proper use of the vehicle requires that you
are familiar with the following information
and rules:
The safety precautions in this manual
The “Technical data” section in this
manual
Traffic rules and regulations
Motor vehicle laws and safety stan-
dards
Warning!
G
Work improperly carried out on electronic
components and associated software could
cause them to malfunction or cease func-
tioning completely. Because the vehicle’s
electronic components are interconnected,
any modification made may produce an un-
desired effect on other systems.
Electronic system malfunctions could seri-
ously impair the operating safety of your ve-
hicle.
Make sure that any repairs or modifications
to electronic components are carried out by
an authorized Mercedes-Benz Center.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function while the
engine is running. You should therefore nev-
er turn off the engine while driving.
Page 236 of 384
236OperationAt the gas station
Check regularly and before a long trip
1Windshield washer and headlamp
cleaning system
More information on refilling the reser-
voir (
page 244).
2Brake fluid
More information on brake fluid can be
found in the “Technical data” section
on (
page 340).
3Coolant level
More information on coolant
(
page 242).Engine oil level
More information on engine oil
(
page 238).
Vehicle lighting
Check function and cleanliness.More infor-
mation on replacing light bulbs can be
found in the “Practical hints” section on
(page 302).
Tire inflation pressure
More information on tire inflate pressure
(page 247).
Opening hood (
page 237).
Exterior lamp switch (
page 108).
iLeaving the engine running and the fuel
cap open can cause the
?
lamp to
illuminate.
More information can be found in the
“Practical hints” section (
page 268).
Page 240 of 384
240OperationEngine compartmentIf there is excessive engine oil with the en-
gine at normal operating temperature, the
following message will appear:ENGINE OIL LEVEL
REDUCE OIL LEVEL
Have excess oil siphoned.
See “Practical hints” (
page 281) if the
engine oil level indicator lights up in the
display while the engine is running.
More information on engine oil can be
found in the “Technical data”
(
page 339).Checking the engine oil level with the
oil dipstick (CL 500, CL 55 AMG only)
The engine oil level can be checked by ei-
ther oil dipstick1 or via the multifunction
display in the instrument cluster
(
page 239). The amount of engine oil
needed is shown more precisely on the op-
erating system display.
1Oil dipstick
Open the hood (
page 237).
Pull out oil dipstick1 (
page 241).
Wipe oil dipstick1 clean.
Fully insert oil dipstick1 into the dip-
stick guide tube, and remove after ap-
proximately three seconds to obtain an
accurate reading.
1Oil dipstick
iIf you want to stop the checking proce-
dure, press the
k
or
j
button on
the multifunction steering wheel.
Page 241 of 384
241 Operation
Engine compartment
The oil level is acceptable when it leaves a
line between the upper and lower marks of
oil dipstick 1.
For adding oil see (
page 241).
See “Practical hints” (page 281) if the
engine oil level indicator lights up in the
display while the engine is running.
More information on engine oil can be
found in the “Technical data”
(
page 339).Adding engine oil
CL 500, CL 55 AMG1Filler neck capCL 6001Filler neck cap
Unscrew the filler neck cap 1 from filler
neck.
Add engine oil as required. Be careful
not to overfill with oil.
Be careful not to spill any oil when adding.
Avoid environmental damage caused by oil
entering the ground or water.
Screw the filler neck cap 1 back on the
filler neck.
More information on engine oil can be
found in the “Technical data”
(
page 339).
iFill quantity between upper and lower
oil dipstick marking level is approxi-
mately 2.1 US qt (2.0 l).
!Excessive oil must be siphoned or
drained off. It could cause damage to
the engine and catalytic converter not
covered by the Mercedes-Benz Limited
Warranty.
Page 243 of 384
243 Operation
Engine compartment
The coolant expansion tank is located on
the passenger side of the engine compart-
ment.
1Coolant expansion tank
Using a rag, turn the cap slowly approx-
imately one half turn to the left to re-
lease any excess pressure.
Continue turning the cap to the left and
remove it.The coolant level is correct if the level
for cold coolant: reaches the black top
part of the reservoir
for warm coolant: is approx. 0.6 in
(1.5 cm) higher
Add coolant as required.
Replace and tighten cap.
More information on coolant can be found
in the “Technical data” section
(
page 342).
Battery
Your vehicle’s battery is located in the
trunk under the right hand wheel well cov-
er panel (
page 313).
The battery should always be sufficiently
charged in order to achieve its rated ser-
vice life. Refer to Service Booklet for bat-
tery maintenance intervals.
If you use your vehicle mostly for short dis-
tance trips, you will need to have the bat-
tery charge checked more frequently.
When replacing the battery, always use
batteries approved by Mercedes-Benz.
If you do not intend to operate your vehicle
for an extended period of time, consult an
authorized Mercedes-Benz Center about
steps you need to observe.
Page 245 of 384
245 Operation
Engine compartment
The windshield washer system on this ve-
hicle is heated, so a fluid mixture produced
for temperatures of approximately 14°F
(–10°C) should be sufficient.
1Washer fluid reservoir
More information can be found in the
“Technical data” section (
page 344).
Warning!
G
Washer solvent / antifreeze is highly flam-
mable. Do not spill washer
solvent / antifreeze on hot engine parts, be-
cause it may ignite. You could be seriously
burned.!Only use washer fluid which is suitable
for plastic lenses. Improper washer flu-
id can damage the plastic lenses of the
headlamps.
