2003 MERCEDES-BENZ C CLASS COUPE air condition

ContentsControls in detail ............................... 81
Locking and unlocking ......................... 82 SmartKey ........................................ 82
Opening the doors from the inside . 85
Opening the trunk lid ...................... 85
Closing the trunk lid ....................... 86
Trunk lid emergency release .......... 86
Automatic central locking .............. 87
Locking and unlocking from
the inside ....................................... 87
Seats .................................................... 89 Easy-entry/exit feature* ................ 89
Head restraints............................... 90
Heated seats* ................................ 91
Memory function* ................................ 93 Storing positions into memory ....... 94
Recalling positions from memory ... 94
Storing exterior rear view mirror
parking position ............................. 95
Lighting ................................................ 96 Exterior lamp switch ....................... 96
Combination switch ........................ 99
Hazard warning flasher ................... 99
Interior lighting ............................. 100 Instrument cluster ............................. 102
Instrument cluster illumination .... 102
Coolant temperature gauge ......... 102
Trip odometer .............................. 103
Tachometer .................................. 103
Outside temperature indicator ..... 104
Control system .................................. 105 Multifunction display .................... 105
Multifunction steering wheel ........ 106
Menus .......................................... 108
Standard display menu ................ 110
AUDIO menu ................................ 110
NAV menu .................................... 112
Malfunction memory menu .......... 112
Settings menu .............................. 114
Trip computer menu ..................... 125
TEL menu* ................................... 126
Manual transmission ......................... 130 Shifting into reverse ..................... 131
Automatic transmission* ................... 132 One-touch gearshifting ................. 133
Gear ranges .................................. 134
Gear selector lever position ......... 135
Program mode selector switch ..... 136
Accelerator position ..................... 137 Emergency operation
(Limp Home Mode) ...................... 137
Good visibility .................................... 138 Rear view mirror ........................... 138
Headlamp cleaning system* ........ 140
Sun visors .................................... 141
Climate control .................................. 142 Setting the temperature ............... 145
Adjusting air distribution and
volume ......................................... 145
Defrosting .................................... 146
Air recirculation mode .................. 146
Rear window defroster ................. 147
Air conditioning ............................ 148
Ventilated storage compartment . 148
Rear passenger compartment
adjustable air vents ...................... 149
Deactivating the climate control
system ......................................... 149
Automatic climate control*
(Canada only) .................................... 150 Setting the temperature ............... 152
Adjusting air distribution .............. 153
Adjusting air volume .................... 153
Maximum cooling MAXCOOL ....... 154
Defrosting .................................... 154

Contents
Air recirculation mode .................. 154
Charcoal filter .............................. 156
Rear window defroster ................. 156
Air conditioning ............................ 157
Residual heat and ventilation* ..... 158
Rear passenger compartment
adjustable air vents ...................... 158
Audio system ..................................... 159 Audio and telephone, operation ... 159
Operating safety ........................... 159
Operating and display elements ... 160
Button and soft key operation ...... 162
Operation ..................................... 162
Radio mode .................................. 165
Cassette mode ............................. 168
CD changer* operating mode ...... 172
Telephone* operation .................. 176
Power windows .................................. 182 Opening and closing the windows 182
Synchronizing power windows ..... 184
Panorama sliding/pop-up roof* ......... 185 Opening and closing the
sunshades for the panorama
sliding/pop-up roof ...................... 185
Opening and closing the panorama
sliding/pop-up roof ...................... 186 Synchronizing the panorama
sliding / pop-up roof ..................... 188
Driving systems ................................. 189 Cruise control .............................. 189
Loading .............................................. 192 Roof rack* ................................... 192
Luggage cover ............................. 192
Split folding rear bench seat ......... 192
Loading instructions .................... 194
Useful features .................................. 195 Interior storage spaces ................ 195
Ashtrays ....................................... 198
Cigarette lighter ........................... 199
Telephone* ................................... 200
Tele Aid* ...................................... 201
Garage door opener ...................... 209
Operation ......................................... 213
The first 1000 miles (1500km) .......... 214
Driving instructions ........................... 215 Drive sensibly – save fuel ............. 215
Drinking and driving ..................... 215
Pedals .......................................... 215
Power assistance .......................... 216
Brakes........................................... 216 Driving off .....................................217
Parking .........................................217
Tires ..............................................218
Hydroplaning ................................ 219
Tire traction ..................................219
Tire speed rating ...........................219
Winter driving instructions ............220
Standing water .............................221
Passenger compartment ...............221
Driving abroad ..............................221
Control and operation of radio
transmitter ....................................222
Catalytic converter .......................222
Emission control ...........................223
Coolant temperature ....................223
At the gas station ...............................224 Check regularly and before a
long trip ........................................225
Engine compartment .......................... 226 Hood .............................................226
Engine oil ......................................227
Transmission fluid level ................229
Coolant level .................................229
Battery ..........................................231
Windshield washer system and
headlamp cleaning system ...........232

Contents
Technical data................................. 305
Spare parts service ............................ 306
Warranty coverage ............................. 307 Loss of Service and Warranty
Information Booklet ..................... 307
Identification labels ........................... 308 Certification label ......................... 308
Vehicle Identification Number
(VIN) ............................................. 308
Identification labels and numbers 308
Layout of poly-V-belt drive ................. 309 C 230 Kompressor ....................... 309
C 320 ........................................... 309
Engine ................................................ 310
Rims and Tires ................................... 311 Same size tires ............................. 311
Mixed size tires ............................ 312
Spare wheel ................................. 313 Electrical system ................................ 314
Main Dimensions ................................ 315
Weights .............................................. 316
Fuels, coolants, lubricants etc. .......... 317
Capacities ..................................... 317
Engine oils .................................... 319
Engine oil additives ....................... 319
Air conditioning refrigerant .......... 319
Brake fluid .................................... 319
Premium unleaded gasoline ......... 320
Fuel requirements ........................ 320
Gasoline additives ........................ 321
Coolants ...................................... 321
Windshield and headlamp
washer system ............................. 324
Consumer information ....................... 325 Uniform tire quality grading ......... 325
Technical terms ...............................327Index .................................................333

11
Introduction
Operator’s Manual
Important notice for California
retail buyers and lessees of Mercedes-Benz automobiles
Under California law you may be entitled to
a replacement of your vehicle or a refund
of the purchase price or lease price, if
Mercedes-Benz USA, LLC and / or its au-
thorized repair or service facilities fail to fix
one or more substantial defects or mal-
functions in the vehicle that are covered by
its express warranty after a reasonable
number of repair attempts. During the pe-
riod of 18 months from original delivery of
the vehicle or the accumulation of
18 000 miles (approx. 29 000 km) on the
odometer of the vehicle, whichever occurs
first, a reasonable number of repair at-
tempts is presumed for a retail buyer or
lessee if one or more of the following oc-
curs:
(1) the same substantial defect or mal-
function results in a condition that is
likely to cause death or serious bodily
injury if the vehicle is driven, that de-
fect or malfunction has been subject to
repair two or more times, and you have
directly notified Mercedes-Benz USA,
LLC in writing of the need for its repair,
(2) the same substantial defect or mal- function of a less serious nature than
category (1) has been subject to repair
four or more times and you have direct-
ly notified us in writing of the need for
its repair, or (3) the vehicle is out of service by reason
of repair of the same or different sub-
stantial defects or malfunctions for a
cumulative total of more than
30 calender days. Written notification
should be sent to us, not a dealer, at
Mercedes-Benz USA, LLC, Customer
Assistance Center, One Mercedes
Drive, Montvale, NJ 07645-0350.

144 Controls in detailClimate controlThe climate control is operational whenev-
er the engine is running. You can operate
the climate control system in either the au-
tomatic or manual mode. The system cools
or heats the interior depending on the se-
lected interior temperature and the cur-
rent outside temperature.
Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.The air conditioning will not engage (no
cooling) if the
AC
OFF
mode is selected
(
page 148)Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
iIf the vehicle interior is hot, ventilate
the interior before driving off.
Keep the air intake grille in front of the
windshield free of snow and debris.

146 Controls in detailClimate controlDefrosting
Activating
Press button
P
(page 143).
The indicator lamp on the button
comes on
or

Switch off air recirculation, if selected.
Press button
O
(page 143).
The indicator lamp on the button goes
out.

Close center air vents.

Open left and right side air vents and
adjust side air vents upwards. Deactivating

Press button
P
(page 143).
The indicator lamp on the button goes
out. Defrosting is turned off.
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside. This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment. Activating

Press button
O
(page 143).
The indicator lamp on the button
comes on.
iThese settings should only be selected
for a short time.
Warning!
G
When the outside temperature is below
41°F (5°C), only switch to air recirculation
mode for short periods to prevent window
fogging.
iIf you keep button
O
pressed the
side windows and panorama slid-
ing/pop-up roof will be closed.
The air recirculation mode is activated
automatically at high outside tempera-
tures.
If you have turned off the air condition-
ing (
page 148) or the outside
temperature is below 41°F (5°C), the
air recirculation mode will not switch
on automatically.

147
Controls in detail
Climate control
Deactivating
Press button
O
(page 143)
The indicator lamp on the button goes
out.
The air recirculation mode is deactivated
automatically:


after five minutes if the outside temper-
ature is below approximately 41°F
(5 °C)


after five minutes if the air conditioning
is turned off


after 30 minutes if the outside temper-
ature is above approximately 41°F
(5 °C) At outside temperatures above 79°F
(26 °C) the system will not automatically
switch back to outside air. A quantity of
outside air is added after approximately
30 minutes.
Rear window defroster
The rear window defroster uses a large
amount of power. To keep the battery
drain to a minimum, switch off the defrost-
er as soon as the rear window is clear. The
defroster is automatically deactivated af-
ter approximately 6 to 17 minutes of oper-
ation depending on the outside
temperature.
Activating
Press button
F
(page 143).
The indicator lamp on the button lights
up. Deactivating

Press button
F
(page 143) again.
The indicator lamp on the button goes
out.
iIf you keep button
O
pressed the
side windows and panorama slid-
ing/pop-up roof will be returned to
their previous position.
Warning!
G
Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.!If the rear window defroster switches
off too soon and the indicator lamp
starts blinking, this means that too
many electrical consumers are operat-
ing simultaneously and there is insuffi-
cient voltage in the battery. The system
responds automatically by deactivating
the rear window defroster.
As soon as the battery has sufficient
voltage, the rear window defroster au-
tomatically turns itself back on.

148 Controls in detailClimate controlAir conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator.
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.
Press buttonAC
OFF
(page 143).
The indicator lamp on the
button AC
OFF
lights up. Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.

Press
AC
OFF
again (
page 143).
The indicator lamp on the
button AC
OFF
goes out.
The air conditioning system uses the refrig-
erant R134a. This refrigerant is free of
CFCs which are harmful to the ozone layer.
Ventilated storage compartment
The front center console storage compart-
ment has its own air vent that allows for
cooling ventilation when the climate con-
trol system is activated.
1 Lever
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.
!If the air conditioning cannot be turned
on again, this indicates that the air con-
ditioning system is losing refrigerant.
The compressor has turned itself off.
Have the air conditioning system
checked at the nearest authorized
Mercedes-Benz Center.
iYou should keep this air vent closed
when outside temperatures are low.
