CHANGING ENGINE COOLANT O Major cooling system repairs should be
performed by your INFINITI retailer. The
service procedures can be found in the
appropriate INFINITI Service Manual. O Improper servicing can result in reduced
heater performance and engine overheat-
ing.
WARNING O To avoid being scalded, never change
the coolant when the engine is hot.
O Never remove the radiator cap when
the engine is hot. Serious burns
could be caused by high pressure
fluid escaping from the radiator.
O Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.
O Keep coolant out of reach of children
and pets.
1. Open radiator drain plug at the bottom of
radiator, and remove radiator filler cap.
O Be careful not to allow coolant to con-
tact drive belts.
O Waste coolant must be disposed of
properly. Check your local regulations.
2. Close the radiator drain plug securely after
the coolant is drained. 3. Fill the radiator slowly with the proper mix-
ture of anti-freeze solution and demineral-
ized water/distilled water. Fill the reservoir
tank up to the MAX level. Then install the
radiator filler cap.
4. Start the engine and warm it up until it
reaches normal operating temperature.
Then race the engine 2 or 3 times under no
load. Watch the engine coolant tempera-
ture gauge for signs of overheating.
5. Stop the engine. After it completely cools
down, refill the radiator up to the filler
opening. Fill the reservoir tank up to the
MAX level. Check the drain plug for any
sign of leakage.
6. Recheck the coolant level after the vehicle
has been driven for a day.SDI0114
8-6 Do-it-yourself
Z 02.7.29/V35-D/V5.0
X

If maintenance is required, see your INFINITI
retailer for servicing.
The filter element should not be cleaned and
reused. Replace it according to the mainte-
nance intervals. See ªPeriodic maintenance
schedulesº in the ª9. Maintenanceº section for
maintenance intervals. When replacing the
filter, wipe the inside of the air cleaner housing
and the cover with a damp cloth.
WARNINGO Operating the engine with the air
cleaner removed can cause you or
others to be burned. The air cleaner
not only cleans the air, it stops flame
if the engine backfires. If it is not
there, and the engine backfires, you
could be burned. Do not drive with
the air cleaner removed and be care-
ful when working on the engine with
the air cleaner removed.
O Never pour fuel into the throttle body
or attempt to start the engine with the
air cleaner removed. Doing so could
result in serious injury. CAUTION O After wiper blade replacement, return
the wiper arm to its original position.
Otherwise it may be damaged when
the engine hood is opened.
O Make sure the wiper blade contacts
the glass, otherwise the arm may be
damaged from wind pressure.
O Worn windshield wiper blades can
damage the windshield and impair
driver vision.
CLEANING If your windshield is not clear after using the
windshield washer or if a wiper blade chatters
when running, wax or other material may be on
the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your
windshield is clean if beads do not form when
rinsing with clear water.
Clean the blade by wiping it with a cloth
soaked in a washer solution or a mild deter- gent. Then rinse the blade with clear water. If
your windshield is still not clear after cleaning
the blades and using the wiper, replace the
blades.
AIR CLEANER WINDSHIELD WIPER BLADES
8-16 Do-it-yourself
Z 02.7.29/V35-D/V5.0
X

WARNINGSee your INFINITI retailer and have it
checked if the brake pedal height does
not return to normal.
Brake pad wear indicators The disc brake pads on your vehicle have
audible wear indicators. When a brake pad
requires replacement, it will make a high
pitched scraping or screeching sound when
the vehicle is in motion whether or not the
brake pedal is depressed. Have the brakes
checked as soon as possible if the wear indi-
cator sound is heard.
Under some driving or climate conditions, oc-
casional brake squeak, squeal or other noise
may be heard. Occasional brake noise during
light to moderate stops is normal and does not
affect the function or performance of the brake
system.
Proper brake inspection intervals should
be followed. For additional information, see
ªPeriodic maintenance schedulesº in the ª9.
Maintenanceº section for maintenance inter-
vals. High performance sports brake pad occasion-
ally makes squeak, squeal or other braking
noise because of its very high friction coeffi-
cient.
These occasional brake noise is normal, but if
it continues, see your INFINITI retailer.
BRAKE BOOSTER Check the brake booster function as follows:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster. If the brakes do not operate properly, see your
INFINITI retailer.
Do-it-yourself
8-19
Z 02.7.29/V35-D/V5.0
X

condition; check for improper tongue load,
overload, worn suspension or other pos-
sible causes of either condition.
O Always secure items in the trailer to prevent
load shifts while driving.
O Be certain your rear view mirrors conform to
all federal, state or local regulations. If not,
install any mirrors required for towing be-
fore driving the vehicle.
Trailer towing tips In order to gain skill and an understanding of
the vehicle's behavior, you should practice
turning, stopping and backing up in an area
which is free from traffic. Steering stability, and
braking performance will be somewhat differ-
ent than under normal driving conditions.
O Always secure items in the trailer to prevent
load shift while driving.
O Avoid abrupt starts, acceleration or stops.
O Avoid sharp turns or lane changes.
O Always drive your vehicle at a moderate
speed.
O Always block the wheels on both vehicle
and trailer when parking. Parking on a
slope is not recommended; however, if you
must do so, and if your vehicle is equipped with automatic transmission, first apply the
parking brake and block the wheels, and
then move the transmission selector lever
into the P (Park) position. If you move the
selector lever to the P (Park) position be-
fore blocking the wheels and applying the
parking brake, the transmission may be
damaged.
O When going down a hill, shift into a lower
gear and use the engine braking effect.
When ascending on a long grade, down-
shift the transmission to a lower gear and
reduce speed to reduce chances of engine
overloading and/or overheating.
O If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
opening the windows, switching the fan
control to high and setting the temperature
control to the HOT position.
O Trailer towing consumes more fuel than
normal circumstances.
O Avoid towing a trailer for the first 500 miles
(800 km).
O Have your vehicle serviced more often than
at intervals specified in the recommended
maintenance schedule. O When making a turn, your trailer wheels will
be closer to the inside of the turn than your
vehicle wheels. To compensate for this,
make a larger than normal turning radius
during the turn.
O Crosswinds and rough roads will adversely
affect vehicle/trailer handling, possibly
causing vehicle sway. When being passed
by larger vehicles, be prepared for possible
changes in crosswinds that could affect
vehicle handling. If swaying does occur,
firmly grip the steering wheel, steer straight
ahead, and immediately (but gradually) re-
duce vehicle speed. This combination will
help stabilize the vehicle. Never increase
speed.
O Be careful when passing other vehicles.
Passing while towing a trailer requires con-
siderably more distance than normal pass-
ing. Remember the length of the trailer
must also pass the other vehicle before you
can safely change lanes.
O To maintain engine braking efficiency and
electrical charging performance, do not use
sixth gear (manual transmission) or fifth
position (automatic transmission).
O Avoid holding the brake pedal down too
long or too frequently such as on long
down-hill sections of road. This could cause
10-18 Technical and consumer information
Z 02.7.29/V35-D/V5.0
X

If you believe that your vehicle has a defect
which could cause a crash or could cause
injury or death, you should immediately
inform the National Highway Traffic Safety
Administration
(NHTSA) in addition to no-
tifying INFINITI.
If
NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However,
NHTSA cannot be-
come involved in individual problems be-
tween you, your retailer, or INFINITI.
To contact
NHTSA , you may call the Auto
Safety Hotline toll-free at 1-888-327-4236.
You may also write to:
NHTSA , U.S. De-
partment of Transportation, Washington,
D.C. 20590. You can also obtain other
information about motor vehicle safety from
the Hotline. You may notify INFINITI by contacting our
Consumer Affairs Department, toll-free, at
1-800-662-6200.
In Hawaii call (808) 836-0888. Due to legal requirements in some states/
areas, your vehicle may be required to be in
what is called the ªready conditionº for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the ªready conditionº
when it is driven through certain driving pat-
terns. Usually, the ªready conditionº can be
obtained by ordinary usage of the vehicle.
If a powertrain system component is repaired
or the battery is disconnected, the vehicle may
be reset to a not ªready conditionº. Before
taking the I/M test, drive the vehicle through
the following pattern to set the vehicle to the
ready condition. If you cannot or do not want to
perform the driving pattern, an INFINITI re-
tailer can conduct it for you.
WARNING Always drive the vehicle in a safe and
prudent manner according to traffic con-
ditions, and obey all traffic laws.
1. Start the engine. Allow the engine to idle
until the engine coolant temperature gauge
needle points between the C and H (normal
operating temperature). 2. Accelerate the vehicle to 55 MPH (88
km/h), then quickly release the accelerator
pedal completely and keep it released for at
least 6 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed
of 53 to 60 MPH (86 to 96 km/h) for at least
5 minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 3 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 min-
utes.
8. Stop the vehicle. Place the automatic trans-
mission selector lever in the ªPº or ªNº
position or the manual transmission shift
lever in the ªNº position.
9. Turn the engine off.
10.Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the en-
gine until step 7 is completed.REPORTING SAFETY DEFECTS
(US only) READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)
Technical and consumer information
10-21
Z 02.7.29/V35-D/V5.0
X

Fuel
Capacities and recommended fuel/lubricants/
fluids .......................................................... 10-2
filler cap ..................................................... 3-14
filler lid ....................................................... 3-14
Fuel economy ............................................ 5-17
Fuel octane rating ..................................... 10-3
Fuel recommendation................................ 10-3
Gauge .......................................................... 2-5
Fuses .............................................................. 8-20
Fusible links .................................................... 8-20
G
Garage door opener, HomeLink Universal
Transceiver ..................................................... 2-37
Gas cap .......................................................... 3-14
Gauge ............................................................... 2-3
Engine coolant temperature gauge ............. 2-5
Fuel gauge .................................................. 2-5
Odometer..................................................... 2-4
Speedometer ............................................... 2-4
Tachometer ................................................. 2-4
General maintenance ....................................... 9-2
Glasses case .................................................. 2-26
Glove box........................................................ 2-27
Glove box lock ................................................ 2-27
H
Hazard warning flasher switch........................ 2-20
Head restraints ................................................. 1-9 Headlights
Bulb replacement ...................................... 8-25
Headlight switch ........................................ 2-17
Xenon headlights ..................................... 2-17
Heated seats................................................... 2-21
Heater
Engine coolant heater ............................... 5-24
Heater and air conditioner (automatic) ....... 4-3
HomeLink Universal Transceiver .................. 2-37
Hood, release ................................................. 3-10
Horn ................................................................ 2-21
How to stop alarm, Vehicle security ............... 2-14
I
Ignition switch ................................................... 5-4
Automatic transmission models ........... 5-4, 5-8
Key positions ............................................... 5-6
Manual transmission models ............. 5-5, 5-12
Immobilizer system ......................................... 2-14
In-cabin microfilter ............................................ 4-5
Indicator lights................................................. 2-11
Infiniti Vehicle Immobilizer System, Engine
start ................................................................... 5-6
Inside Automatic anti-glare mirror................... 3-17
Inspection/maintenance (I/M) test................. 10-21
Installing front bumper cover ........................ 10-12
Instrument panel ............................................... 2-2
Instrument pocket ........................................... 2-25
Interior light ..................................................... 2-35
Interior light replacement ................................ 8-26
Interior trunk lid release .................................. 3-12
ISOFIX child restraint ..................................... 1-40 J
Jump starting .................................................... 6-7
K
Keyless entry (See remote keyless entry
system) ............................................................. 3-5
Keys .................................................................. 3-2
L
Label, Air conditioner specification label ...... 10-12
Label, Emission control information label ..... 10-11
Label, F.M.V.S.S. certification label.............. 10-10
Labels
Air bag warning labels............................... 1-23
Engine serial number .............................. 10-10
Vehicle identification number (VIN)........... 10-9
LATCH system................................................ 1-40
License plate, Installing front license plate... 10-13
Light
Air bag warning light ................................. 1-23
Bulb replacement ...................................... 8-23
Flashing signal .......................................... 2-19
Fog light switch ......................................... 2-20
Headlight switch ........................................ 2-17
Headlights Bulb replacement .................... 8-25
Interior light................................................ 2-35
Map light .................................................... 2-35
Rear personal light .................................... 2-36
Replacement ............................................. 8-23
Trunk light.................................................. 2-37
11-3
Z 02.7.29/V35-D/V5.0
X
