DRIVING YOUR HYUNDAI DRIVING YOUR HYUNDAIDRIVING YOUR HYUNDAI DRIVING YOUR HYUNDAI
DRIVING YOUR HYUNDAI
2- 11 accordance with the maintenance schedule in
Section 5. Before winter, have your coolant test-
ed to assure that its freezing point is sufficient for
the temperatures anticipated during the winter.
C160D01A-AAT
Check Battery and Cables Check Battery and CablesCheck Battery and Cables Check Battery and Cables
Check Battery and CablesWinter puts additional burdens on the battery
system. Visually inspect the battery and cables
as described in Section 6. The level of charge in
your battery can be checked by your Hyundai
dealer or a service station.
C160E01A-AATChange to "Winter Weight" Oil if Change to "Winter Weight" Oil ifChange to "Winter Weight" Oil if Change to "Winter Weight" Oil if
Change to "Winter Weight" Oil if
Necessary NecessaryNecessary Necessary
Necessary
In some climates it is recommended that a lower
viscosity "winter weight" oil be used during cold
weather. See Section 9 for recommendations. If
you aren't sure what weight oil you should use,
consult your Hyundai dealer.
C160F01A-AATCheck Spark Plugs and Ignition Check Spark Plugs and IgnitionCheck Spark Plugs and Ignition Check Spark Plugs and Ignition
Check Spark Plugs and Ignition
System SystemSystem System
System
Inspect your spark plugs as described in Section
6 and replace them if necessary. Also check all
ignition wiring and components to be sure they
are not cracked, worn or damaged in any way.
C160G01A-AAT
To Keep Locks from Freezing To Keep Locks from FreezingTo Keep Locks from Freezing To Keep Locks from Freezing
To Keep Locks from FreezingTo keep the locks from freezing, squirt an ap-
proved de-icer fluid or glycerine into the key
opening. If a lock is covered with ice, squirt it with
an approved de-icing fluid to remove the ice. If
the lock is frozen internally, you may be able to
thaw it out by using a heated key. Handle the
heated key with care to avoid burning the fingers.
C160H01A-AATUse Approved Anti-Freeze in Window Use Approved Anti-Freeze in WindowUse Approved Anti-Freeze in Window Use Approved Anti-Freeze in Window
Use Approved Anti-Freeze in Window
Washer System Washer SystemWasher System Washer System
Washer System
To keep the water in the window washer system
from freezing, add an approved anti-freeze solu-
tion in accordance with instructions on the con-
tainer. Window washer anti-freeze is available
from Hyundai dealers and most auto parts out-
lets. Do not use engine coolant or other types of
anti-freeze as these may damage the finish.
C160I01A-AAT
Don't Let Your Parking Brake Freeze Don't Let Your Parking Brake FreezeDon't Let Your Parking Brake Freeze Don't Let Your Parking Brake Freeze
Don't Let Your Parking Brake FreezeUnder some conditions your parking brake can
freeze in the engaged position. This is most likely
to happen when there is an accumulation of snow
or ice around or near the rear brakes or if the
brakes are wet. If there is a risk the parking brake
may freeze, apply it only temporarily while you
put the gear selector lever in "P" (automatic) or in
first or reverse gear (manual transaxle) and
block the rear wheels so the car cannot roll. Then
release the parking brake.
C160K01A-AAT
Carry Emergency Equipment Carry Emergency EquipmentCarry Emergency Equipment Carry Emergency Equipment
Carry Emergency EquipmentDepending on the severity of the weather where
you drive your car, you should carry appropriate
emergency equipment. Some of the items you
may want to carry include tire chains, tow straps
or chains, flashlight, emergency flares, sand, a
shovel, jumper cables, a window scraper, gloves,
ground cloth, coveralls, a blanket, etc.
C160J01A-AAT
Don't Let Ice and Snow Accumulate Don't Let Ice and Snow AccumulateDon't Let Ice and Snow Accumulate Don't Let Ice and Snow Accumulate
Don't Let Ice and Snow Accumulate
Underneath UnderneathUnderneath Underneath
Underneath
Under some conditions, snow and ice can build
up under the fenders and interfere with the steer-
ing. When driving in severe winter conditions
where this may happen, you should periodically
check underneath the car to be sure the move-
ment of the front wheels and the steering compo-
nents is not obstructed.
C170A01A-AAT
HIGHER SPEED MOTORING HIGHER SPEED MOTORINGHIGHER SPEED MOTORING HIGHER SPEED MOTORING
HIGHER SPEED MOTORING
Pre-Trip Inspections Pre-Trip InspectionsPre-Trip Inspections Pre-Trip Inspections
Pre-Trip Inspections
1. Tires:
Adjust the tire inflation pressures to specifica-
tion. Low tire inflation pressures will result in
overheating and possible failure of the tires.
Avoid using worn or damaged tires which may
result in reduced traction or tire failure.

VEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTSVEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTS
VEHICLE MAINTENANCE REQUIREMENTS
5-3 Note:
*1 - IN CASE OF REMOVING INJECTOR FOR INSPECTION, INSULATOR AND O-RING OF INJECTOR SHOULD BE CHANGED
WITH NEW ONE.
*2 - REPLACE EVERY 100,000 MILES OR 10 YEARS
F030A01A-AAT
SCHEDULED MAINTENANCE SCHEDULED MAINTENANCESCHEDULED MAINTENANCE SCHEDULED MAINTENANCE
SCHEDULED MAINTENANCEThe following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services
to protect your emission warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first.
F030B04E-AATR :Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary.
DESCRIPTION
EMISSION CONTROL ITEMS
ENGINE OIL AND FILTER
FUEL FILTER
FUEL LINES, FUEL HOSES AND CONNECTIONS
INSULATOR OF FUEL INJECTOR (2.0 L SULEV Only)
VACUUM AND CRANKCASE VENTILATION HOSES
VAPOR HOSE AND FUEL FILLER CAP
AIR CLEANER FILTER
SPARK PLUGS
VALVE CLEARANCE No.
1
2
3
4
5
6
7
8MILES X 1000
KILOMETERS X 1000
MONTHS7.5
12
6
R15
24
12
R22.5
36
18
R30
48
24
R
I
I*
1
I
R37.5
60
30
R45
72
36
R52.5
84
42
R
R
I60
96
48
R
I
R
I
R
R
I67.5
108
54
R75
120
60
R82.5
132
66
R90
144
72
R
I
I*
1
I
R97.5
156
78
R105
168
84
R
R
I112.5
180
90
R120
192
96
R
I
R
I
R
R
I127.5
204
102
R135
216
108
R142.5
228
114
R150
240
120
R
I
I*
1
I
R
PLATINUM COATED (2.0L)
IRIDIUM COATED (2.0L SULEV)
See Note *2

VEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTSVEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTS
VEHICLE MAINTENANCE REQUIREMENTS
5-5
MAINTENANCE UNDER SEVERE USAGE CONDITIONS MAINTENANCE UNDER SEVERE USAGE CONDITIONSMAINTENANCE UNDER SEVERE USAGE CONDITIONS MAINTENANCE UNDER SEVERE USAGE CONDITIONS
MAINTENANCE UNDER SEVERE USAGE CONDITIONSThe following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the
appropriate maintenance intervals.
R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary
F040A02E-AAT
MAINTENANCE ITEM
F - More than 50% driving in heavy city traffic during hot
weather above 90°F (32°C)
G - Driving in mountainous areas
H - Towing a trailer
I - Driving as a patrol car, taxi, or other commercial use
or vehicle towing
J - Driving over 100 MPH SEVERE DRIVING CONDITIONS SEVERE DRIVING CONDITIONSSEVERE DRIVING CONDITIONS SEVERE DRIVING CONDITIONS
SEVERE DRIVING CONDITIONS
A - Repeated short distance driving
B - Extensive idling
C - Driving in dusty, rough roads
D - Driving in areas using salt or other corrosive materials or in very cold weather
E - Driving in sandy areasMAINTENANCE INTERVALS
ENGINE OIL AND FILTER
AIR CLEANER FILTER
SPARK PLUGS
BRAKE PADS, CALIPERS AND ROTORS
REAR BRAKE DRUMS/LININGS/PADS,
PARKING BRAKE
STEERING GEAR RACK, LINKAGE & BOOTS/
LOWER ARM BALL JOINT
DRIVESHAFTS AND BOOTS
MANUAL TRANSAXLE OIL
AUTOMATIC TRANSAXLE FLUID
AIR FILTER (IN FRONT OF BLOWER UNIT)R
R
R
I
I
I
I
R
R
REVERY 3,000 MILES (4,800 KM) OR 3 MONTHS
MORE FREQUENTLY
MORE FREQUENTLY
MORE FREQUENTLY
MORE FREQUENTLY
MORE FREQUENTLY
EVERY 7,500 MILES (12,000 KM) OR 6 MONTHS
EVERY 60,000 MILES (96,000 KM)
EVERY 30,000 MILES (48,000 KM)
MORE FREQUENTLY MAINTENANCE
OPERATION
A, B, C, F, H
C, E
B, H
C, D, G, H
C, D, G, H
C, D, E, F, G
C, E, F
A, C, D, E, F, G, H, I, J
A, C, E, F, G, H, I
C, EDRIVING
CONDITION

VEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTSVEHICLE MAINTENANCE REQUIREMENTS VEHICLE MAINTENANCE REQUIREMENTS
VEHICLE MAINTENANCE REQUIREMENTS
5- 6
F060A01A-AAT
EXPLANATION OF SCHEDULED EXPLANATION OF SCHEDULEDEXPLANATION OF SCHEDULED EXPLANATION OF SCHEDULED
EXPLANATION OF SCHEDULED
MAINTENANCE ITEMS MAINTENANCE ITEMSMAINTENANCE ITEMS MAINTENANCE ITEMS
MAINTENANCE ITEMS
F060M01A-AAT
o oo o
o
Engine Oil and Filter Engine Oil and FilterEngine Oil and Filter Engine Oil and Filter
Engine Oil and FilterThe engine oil and filter should be changed at
the intervals specified in the maintenance
schedule. If the car is being driven in severe
conditions, more frequent oil and filter changes
are required.
F060C01A-AAT
o oo o
o
Fuel Filter Fuel FilterFuel Filter Fuel Filter
Fuel FilterA clogged filter can limit the speed at which the
vehicle may be driven, damage the emission
system and cause hard starting. If an exces-
sive amount of foreign matter accumulates in
the fuel tank, the filter may require replace-
ment more frequently.
After installing a new filter, run the engine for
several minutes, and check for leaks at the
connections. Fuel filters should be installed by
trained technicians.
F060B01A-AAT
o oo o
o
Drive Belts Drive BeltsDrive Belts Drive Belts
Drive BeltsInspect all drive belts for evidence of cuts,
cracks, excessive wear or oil saturation and
replace if necessary. Drive belts should be
checked periodically for proper tension and
adjusted as necessary.
F060D01A-AATo oo o
o
Fuel Lines, Fuel Hoses and Fuel Lines, Fuel Hoses andFuel Lines, Fuel Hoses and Fuel Lines, Fuel Hoses and
Fuel Lines, Fuel Hoses and
Connections ConnectionsConnections Connections
Connections
Check the fuel lines, fuel hoses and connec-
tions for leakage and damage. Have a trained
technician replace any damaged or leaking
parts immediately.
F060G01A-AAT
o oo o
o
Vapor Hose and Fuel Filler Cap Vapor Hose and Fuel Filler CapVapor Hose and Fuel Filler Cap Vapor Hose and Fuel Filler Cap
Vapor Hose and Fuel Filler CapThe vapor hose and fuel filler cap should be
inspected at those intervals specified in the
maintenance schedule. Make sure that a new
vapor hose or fuel filler cap is correctly re-
placed.
F060F01A-AATo oo o
o
Vacuum, Crankcase Vacuum, CrankcaseVacuum, Crankcase Vacuum, Crankcase
Vacuum, Crankcase
Ventilation Hoses Ventilation HosesVentilation Hoses Ventilation Hoses
Ventilation Hoses
Inspect the surface of hoses for evidence of
heat and/or mechanical damage. Hard and
brittle rubber, cracking, tears, cuts, abra-
sions, and excessive swelling indicate dete-
rioration. Particular attention should be paid to
examine those hose surfaces nearest to high
heat sources, such as the exhaust manifold.
Inspect the hose routing to assure that the
hoses do not come in contact with any heat
source, sharp edges or moving component
which might cause heat damage or mechani-
cal wear. Inspect all hose connections, such
as clamps and couplings, to make sure they
are secure, and that no leaks are present.
Hoses should be replaced immediately if there
is any evidence of deterioration or damage.
F060H01A-AAT
o Air cleaner filter o Air cleaner filtero Air cleaner filter o Air cleaner filter
o Air cleaner filterA Genuine Hyundai air cleaner filter is recom-
mended when the filter is replaced.
F060J01A-AAT
o Spark plugs o Spark plugso Spark plugs o Spark plugs
o Spark plugsMake sure to install new spark plugs of the
correct heat range.
F060E01A-AAT
o oo o
o
Timing belt Timing beltTiming belt Timing belt
Timing beltInspect all parts related to the timing belt for
damage and deformation. Replace any dam-
aged parts immediately.
F070C01A-AAT
o Engine coolant o Engine coolanto Engine coolant o Engine coolant
o Engine coolantThe coolant should be changed at the
intervals specified in the maintenance sched-
ule.
F060N02E-AAT
o oo o
o
Valve Clearance Valve ClearanceValve Clearance Valve Clearance
Valve ClearanceInspect excessive valve noise and/or engine
vibration and adjust if necessary. A qualified
technician should perform the operation.

DO-IT-YOURSELF MAINTENANCE DO-IT-YOURSELF MAINTENANCEDO-IT-YOURSELF MAINTENANCE DO-IT-YOURSELF MAINTENANCE
DO-IT-YOURSELF MAINTENANCE
6-7
CHAMPION
NGKRC10PYP4
PFR5N-11
IFR5G-11 Your engine was originally equipped with plati-
num or iridium-tipped spark plugs.
Platinum or iridium-tipped spark plugs will last
longer than conventional type spark plugs and
can be identified by blue lines (platinum only)
on the ceramic shell.NOTE: NOTE:NOTE: NOTE:
NOTE:Do not clean or regap platinum or iridium- Do not clean or regap platinum or iridium-Do not clean or regap platinum or iridium- Do not clean or regap platinum or iridium-
Do not clean or regap platinum or iridium-
tipped spark plugs. tipped spark plugs.tipped spark plugs. tipped spark plugs.
tipped spark plugs.
G050D04E
5. Start the engine, top off the radiator with
water and then add engine coolant to the
reservoir until the level is between "LOW"
and "FULL".
6. Replace the radiator and reservoir caps and
check to be sure the drain cocks are fully
closed and not leaking.
WARNING: WARNING:WARNING: WARNING:
WARNING:The cooling fan is controlled by engine cool- The cooling fan is controlled by engine cool-The cooling fan is controlled by engine cool- The cooling fan is controlled by engine cool-
The cooling fan is controlled by engine cool-
ant temperature and may sometimes oper- ant temperature and may sometimes oper-ant temperature and may sometimes oper- ant temperature and may sometimes oper-
ant temperature and may sometimes oper-
ate even when the engine is not running. ate even when the engine is not running.ate even when the engine is not running. ate even when the engine is not running.
ate even when the engine is not running.
Use extreme caution when working near the Use extreme caution when working near theUse extreme caution when working near the Use extreme caution when working near the
Use extreme caution when working near the
blades of the cooling fan so that you are not blades of the cooling fan so that you are notblades of the cooling fan so that you are not blades of the cooling fan so that you are not
blades of the cooling fan so that you are not
injured by a rotating fan blade. As the en- injured by a rotating fan blade. As the en-injured by a rotating fan blade. As the en- injured by a rotating fan blade. As the en-
injured by a rotating fan blade. As the en-
gine coolant temperature decreases, the fan gine coolant temperature decreases, the fangine coolant temperature decreases, the fan gine coolant temperature decreases, the fan
gine coolant temperature decreases, the fan
will automatically shut off. This is a normal will automatically shut off. This is a normalwill automatically shut off. This is a normal will automatically shut off. This is a normal
will automatically shut off. This is a normal
condition. condition.condition. condition.
condition.
SSA6060A
0.039 ~ 0.043 in. (1.0 ~ 1.1 mm)
G060A03Y-AAT
SPARK PLUGS SPARK PLUGSSPARK PLUGS SPARK PLUGS
SPARK PLUGS
PLATINUM
PLATINUM
IRIDIUM*
G060B02E-AAT
Replacing the Spark Plugs Replacing the Spark PlugsReplacing the Spark Plugs Replacing the Spark Plugs
Replacing the Spark PlugsThe spark plugs should be changed at the
intervals specified in the vehicle maintenance
schedule in Section 5 or whenever engine per-
formance indicates they should be changed.
Symptoms that suggest poor spark plug perfor-
mance include engine misfiring under load, loss
of fuel economy, poor acceleration, etc. When
spark plugs are replaced, always use spark
plugs recommended by Hyundai. The use of
other spark plugs can result in loss of perfor-
mance, radio interference or engine damage.
NOTE: NOTE:NOTE: NOTE:
NOTE:When replacing the spark plugs, genuine When replacing the spark plugs, genuineWhen replacing the spark plugs, genuine When replacing the spark plugs, genuine
When replacing the spark plugs, genuine
Hyundai replacement parts are recom- Hyundai replacement parts are recom-Hyundai replacement parts are recom- Hyundai replacement parts are recom-
Hyundai replacement parts are recom-
mended. mended.mended. mended.
mended.
Recommended Spark Plugs: Recommended Spark Plugs:Recommended Spark Plugs: Recommended Spark Plugs:
Recommended Spark Plugs:
* 2.0L SULEV Only.

DO-IT-YOURSELF MAINTENANCE DO-IT-YOURSELF MAINTENANCEDO-IT-YOURSELF MAINTENANCE DO-IT-YOURSELF MAINTENANCE
DO-IT-YOURSELF MAINTENANCE
6-8
WARNING: WARNING:WARNING: WARNING:
WARNING:It is recommended that the engine be cool It is recommended that the engine be coolIt is recommended that the engine be cool It is recommended that the engine be cool
It is recommended that the engine be cool
or cold when changing the spark plugs. If or cold when changing the spark plugs. Ifor cold when changing the spark plugs. If or cold when changing the spark plugs. If
or cold when changing the spark plugs. If
the engine is hot, you could burn yourself the engine is hot, you could burn yourselfthe engine is hot, you could burn yourself the engine is hot, you could burn yourself
the engine is hot, you could burn yourself
on the insulated connector, the spark plug on the insulated connector, the spark plugon the insulated connector, the spark plug on the insulated connector, the spark plug
on the insulated connector, the spark plug
or the engine itself. or the engine itself.or the engine itself. or the engine itself.
or the engine itself.
4. When preparing to remove the old spark
plug, guide the socket down over the spark
plug, being careful not to damage the ce-
ramic insulator.
5. To remove the spark plug, turn the wrench
handle in a counterclockwise direction.
6. To replace the new spark plug, guide the
socket down over the spark plug, being
careful not to damage the ceramic insulator.You will find it easier to change spark plugs if
the engine is cold. Always change one spark
plug at a time. This helps avoid getting the wires
mixed up.
1. Remove the center cover on the engine
rocker cover.
2. Using a clean cloth, remove any dirt that has
accumulated around the spark plug so it
cannot fall into the cylinder when the spark
plug is removed.
3. To remove the spark plug cable, pull straight
up on the insulated connector, not the cable.
Pulling on the cable may damage the carbon
core conductor.
HGK257 G060C01S-AAT
Changing the Spark Plugs Changing the Spark PlugsChanging the Spark Plugs Changing the Spark Plugs
Changing the Spark Plugs
HGK256
HGK258
NOTE: NOTE:NOTE: NOTE:
NOTE:Spark plugs should be tightened firmly. Over- Spark plugs should be tightened firmly. Over-Spark plugs should be tightened firmly. Over- Spark plugs should be tightened firmly. Over-
Spark plugs should be tightened firmly. Over-
tightening can damage the threads in the tightening can damage the threads in thetightening can damage the threads in the tightening can damage the threads in the
tightening can damage the threads in the
aluminum cylinder head. Leaving them too aluminum cylinder head. Leaving them tooaluminum cylinder head. Leaving them too aluminum cylinder head. Leaving them too
aluminum cylinder head. Leaving them too
loose can cause the spark plugs to get very loose can cause the spark plugs to get veryloose can cause the spark plugs to get very loose can cause the spark plugs to get very
loose can cause the spark plugs to get very
hot and possibly result in damage to the hot and possibly result in damage to thehot and possibly result in damage to the hot and possibly result in damage to the
hot and possibly result in damage to the
engine. engine.engine. engine.
engine.
7. Replace the cable by pushing the insulated
connector directly down onto the electrode.
Check to be sure it has snapped into place
and can't fall off.
