2003 HONDA ELEMENT fuse box

All the electrical circuits in your
vehicle have fuses to protect them
f rom a short circuit or overload.
These f uses are located in two f use
boxes.The under-hood f use box is located
in the engine compartment on the
driver’s side. To open it, push the
tabs as shown.The interior f use box is underneath
the steering column. To remove the
f use box lid, turn the knobs
counterclockwise and pull the lid out
of its hinges.
Fuses
T aking Care of t he Unexpect ed295
UNDER-HOOD
TAB INTERIOR

If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pagesand , or the diagram on the
fuse box lid, which fuse or fuses
control that component. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
not the cause. Replace any blown
f uses and check the component’s
operation. Check each of the large f uses in
the under-hood f use box by
looking through the top at the wire
inside. Removing these f uses
requires a Phillips-head screw-
driver.
Remove the cover f rom the f use
box. Turn the ignition switch to LOCK
(0). Make sure the headlights and
all other accessories are off.
3.
1.
2.
300
299
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed296
FUSE
BLOWN

CONT INUED
Look f or a burned wire inside the
f use. If it is burned, replace it with
oneof thesparefusesof thesame
rating or lower.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse box by
pulling out each f use with the f use
puller provided in the under-hood
fuse box. If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
5.
4.
Fuses
T aking Care of t he Unexpect ed297
FUSE PULLER BLOWN

µµ
µ
µ
µ
Î Î
Î
No. No.
CONT INUED
Amps. Circuits ProtectedAmps. Circuits Protected
1
2
3
4
5 6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
15 A
10 A
10 A
10 A
Ignition Coil
Accessory Power Socket
Daytime running lights
ACG
Not Used 7.5 A
20 A
7.5 A 10 A
7.5 A
7.5 A
7.5 A 10 A
10 A
20 A
15 A
15 A
7.5 A 20 A
20 A
20 A Power Window Relay
AMP
Accessory, Radio
Rear Wiper
Meter
ABS
Daytime running lights
SRS
Remote Control Mirrors
LAF Heater
Not Used
Fuel Pump
Accessory Power Socket
Turn Signal Lights
Front Wiper
Not Used
Front Right Power Window
Front Left Power Window
Not Used
Not Used
: On Canadian models
Fuses
T aking Care of t he Unexpect ed299
INTERIOR FUSE BOX

µ
µ
µ
No.Circuits Protected
Amps.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 Condenser Fan
Small Light
Interior Light
Cooling Fan Motor
Hazard
IGP
Horn, Stop
Not Used
Back Up
ABS Motor
Rear Defroster
Heater Motor
Power Window
Option
Lef t Headlight
Door Lock
Right Headlight
ABS F/S
Battery
Ignition 1
Spare Fuses
30 A
15 A
7.5 A 20 A
15 A
15 A
15 A
10 A
30 A
20 A
40 A
40 A
40 A
15 A
20 A
15 A
30 A
100 A 50 A
21 257.5A 30A
T aking Care of t he Unexpect ed
Fuses
300
UNDER-HOOD FUSE BOX

µµµ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Specif ications
T echnical Inf ormation307
Air Conditioning
Tires Alignment Fuses
Battery Lights HFC-134a (R-134a)
16.9 18.7 oz (480 530 g) SP-10
12 V 60/55 W (H4/HB2)
12 V 12 V
12 V
12 V
12 V
12 V
12 V
8W
4CP
8W
5W
18 W (21 CP)
21/5 W
21 W
Refrigerant type
Charge quantity
Lubricant type
P215/70R16 99S
Size
Pressure Toe-in
Camber
Caster 1°50’1°
0°13’
0.08 in (2.0 mm) 0.0in(0mm)
Interior
Under-hood
12 V 21/5 W
12 V 3 CP
12 V 21 W
Capacity See page
299or the fuse label
attached to the inside of the fuse
box door under the steering
column.
See page 300or the fuse box
cover.
32 psi (220 kPa , 2.2 kgf/cm
)
34 psi (235 kPa , 2.4 kgf/cm)
Headlights
Front turn signal/parking
lights
Front side marker lights
Rear turn signal lights
Brake/Taillights
Back-up lights
License plate lights
Ceiling light
Spotlights
Cargo area light
High-mount brake light
45 AH/20 HR
12 V Front
Rear
Front
Rear
Front
Front/Rear
Front
Rear

.............
