2003 HONDA ACCORD SEDAN display

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your Honda. All the essential
controls are within easy reach............................
Control Locations .56
...............................
Indicator Lights .57
.............................................
Gauges .63
...............................
Speedometer .63
.................................
Tachometer .63
Odometer/Outside ...........
Temperature Indicator . 63
.....................................
Odometer .63
...................................
Trip Meter .64
...................
Temperature Gauge . 64
..................................
Fuel Gauge .65
Maintenance Required ...................................
Indicator .65
Controls Near the Steering .......................................
Wheel .67
...................................
Headlights .68
Automatic Lighting Off .....................................
Feature .69 ............
Daytime Running Lights . 69
....
Instrument Panel Brightness . 69
................................
Turn Signals .70
.....................
Windshield Wipers .70
..................
Windshield Washers . 72
..........................
Hazard Warning .72
.............
Rear Window Def ogger . 72
......
Steering Wheel Adjustment . 73
...............................
Keys and Locks .74
..............................................
Keys .74
....................
Immobilizer System . 76
............................
Ignition Switch .77
..................................
Door Locks .78
...................
Remote Transmitter . 80
..............
Childproof Door Locks . 84
...........................................
Trunk .84
........
Emergency Trunk Opener . 85
....................................
Glove Box .86
............................
Seat Adjustments .87
.............
Front Seat Adjustments . 87
Driver’s Seat Manual Height ..............................
Adjustment .88
Driver’s Seat Power Height ..............................
Adjustment .88
Driver’s Seat Full Power ............................
Adjustments .89 ...........
Driver’s Lumbar Support . 90
Front Passenger’s Seat ............................
Adjustments .91
..........................
Head Restraints .91
.......................
Folding Rear Seat .92
.................
Rear Head Restraints . 93
......................
Rear Seat Armrest .93
....................................
Seat Heaters .95
..............................
Power Windows .96
Power Window Control ...............................
Operations .99
.......................................
Moonroof .100
...........................................
Mirrors .101
..
Adjusting the Power Mirrors . 101
...............................
Parking Brake .102
.................
Console Compartment . 103
..........................................
Armrest .103
.........................
Beverage Holders .104
.........................
Center CD Pocket .105
...................................
Coin Pocket .105
........................................
Sun Visor .106
................................
Vanity Mirror .106
........................
Sunglasses Holder .107
............
Accessory Power Sockets . 107
...............................
Interior Lights .108
Instruments and Controls
Inst rument s and Cont rols55

The appropriate light comes on in
this display if the trunk or any door
is not closed tightly.
All the lights in the monitor display
come on f or a f ew seconds when you
turn the ignition switch to ON (II).The lef t or right turn signal light
blinks when you signal a lane change
or turn. If the light does not blink or
blinks rapidly, it usually means one
of the turn signal bulbs is burned out
(see page ). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signaling.
WhenyouturnontheHazard
Warning switch, both turn signal
lights blink. All turn signals on the
outside of the car should f lash.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II). If it comes
on and stays on when the Traction
Control System (TCS) is on, there is
a problem with the TCS. For more
inf ormation on the TCS, see page
.
232 315
On all V6 models
Indicator L ights
Inst rument s and Cont rols
Traction Control System
(T CS) Indicator
Door Monitor
T urn Signal and
Hazard Warning
Indicators
60

The tachometer shows the engine
speed in revolutions per minute
(rpm). To protect the engine f rom
damage, never drive with the
tachometer needle in the red zone.
This shows your speed in miles per
hour (mph). The smaller inner
numbers are the speed in kilometers
per hour (km/h).
This shows your speed in kilometers
per hour (km/h). The smaller inner
numbers are the speed in miles per
hour (mph). The odometer and the outside
temperature indicator use the same
display. To switch the display
between the odometer and the
outside temperature, press the
Select/Reset knob. When you turn
the ignition switch to ON (II), what
you last selected is displayed.
The odometer shows the total dis-
tance your car has been driven. It
measures miles in U.S. models and
kilometers in Canadian models.
It is illegal under U.S. f ederal law and
Canadian provincial regulations to
disconnect, reset, or alter the
odometer with the intent to change
the number of miles or kilometers
indicated.U.S. Models
Canadian Models
Speedometer T achometer Odometer/Outside T emperature
Indicator
Odometer
Gauges
Inst rument s and Cont rols63
TACHOMETER
SPEEDOMETER FUEL GAUGE
TEMPERATURE
GAUGE
MAINTENANCE
REQUIRED
INDICATOR
TRIP METER
U.S. model is shown. SELECT/RESET
KNOB
ODOMETER/OUTSIDE
TEMPERATURE INDICATOR

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise into the
upperhalfofthegauge.Ifitreaches
the red (Hot) mark, pull safely to the
side of the road. Turn to page f or
instructions and precautions on
checking the engine’s cooling
system.
This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace. The temperature sensor is located in
the f ront bumper. Theref ore, the
temperature reading can be af f ected
by heat ref lection f rom the road sur-
f ace, engine heat, and the exhaust
f rom surrounding traf f ic. This can
cause an incorrect temperature read-
ing when your speed is under
19 mph (30 km/h). This indicator displays the outside
temperature in Fahrenheit in U.S.
models, and in Centigrade in
Canadian models. To see the outside
temperature, press and release the
Select/Reset knob until the
temperature is displayed. There are two trip meters: Trip A
and Trip B. Switch between these
displays and the odometer/outside
temperature display by pressing the
Select/Reset knob repeatedly. Each
trip meter works independently, so
you can keep track of two dif f erent
distances.
To reset a trip meter, display it and
then press and hold the Select/Reset
knob until the number resets to ‘‘0.0’’.
Both trip meters will reset if the car’s
battery goes dead or is disconnected. 345On 4-cylinder EX models with leather
interior and all 6-cylinder EX models
Gauges
Inst rument s and Cont rols
Temperature Gauge
Trip Meter
Outside Temperature Indicator
64

Pressing the OFF button shuts the
climate control system completely
of f . Keep the system completely of f
only f or short periods. To keep stale
air and mustiness f rom collecting,
you should have the f an running at
all times.
To put the Automatic Climate
Control in f ully-automatic mode,
press the AUTO button, then set the
desired temperature by turning the
driver’s temperature control dial.
You will see AUTO in the system’s
display.
The system automatically selects the
proper mix of conditioned and/or
heated air that will, as quickly as
possible, raise or lower the interior
temperature f rom its current level to
the set temperature.
When you set the temperature to its
lower limit ‘‘ ’’ or its upper
limit ‘‘ ’’, the system runs at
f ull cooling or heating only. It does
not regulate the interior temperature.
In cold weather, the f an will not
come on automatically until the car
has been driven f or a short time and
the heater starts to develop warm air.
Climat e Cont rol Syst em
Comf ort and Convenience Feat ures
Fully-automatic Operation
Without Navigation System
121
RECIRCULATION BUTTON
OFF BUTTON TEMPERATURE DISPLAY
FAN CONTROL
BUTTONS
AUTO BUTTON DRIVER’S SIDE
TEMPERATURE
CONTROL DIAL PASSENGER’S SIDE
TEMPERATURE
CONTROL DIAL

Press the A/C button to turn the air
conditioningonandoff.Youwillsee
A/C ON or A/C OFF in the display. You can manually select various
f unctions of the Climate Control
system when it is in f ully automatic
mode. All other f eatures remain
automatically controlled. Making any
manual selection causes the word
AUTO in the display to go out.
When you turn the A/C of f , the sys-
tem cannot regulate the inside tem-
perature if you set the dial below the
outside temperature. With the A/C
of f , use the temperature control dial
to adjust the temperature of the air
flow to a comfortable setting. Semi-automatic Operation
A ir Condit ioning (A /C) But t on
Climat e Cont rol Syst em
Comf ort and Convenience Feat ures122
RECIRCULATION BUTTON
DRIVER’S SIDE
TEMPERATURE
CONTROL DIAL
PASSENGER’S SIDE
TEMPERATURE
CONTROL DIAL
AIR CONDITIONING
(A/C) BUTTON

ÛÝ
CONT INUED
You can manually select the f an
speed by pressing the f an control
buttons: to increase the f an’s
speed, or to decrease the f an’s
speed. Use the MODE button to select the
vents the air flows from. Some air
will f low f rom the dashboard corner
vents in all modes; you can turn it of f
with the dial below each vent. Each
time you press the MODE button,
the display shows the mode selected.
Press the button four times to see allthe modes.
This button controls the source of air
going into the system. When the
indicator above this button is lit, air
from the car’s interior is sent
through the system again (Recircula-
tion mode). When the indicator is off,
air is brought in f rom outside the car
(Fresh Air mode).
You can, f or example, manually put
the system in recirculation mode
when driving through an area of
smoke or f umes.
Mode Button
Recirculat ion But t on
Fan Control Buttons
Climat e Cont rol Syst em
Comf ort and Convenience Feat ures123
MODE BUTTON
FAN CONTROL BUTTONS
RECIRCULATION BUTTON

Your car is equipped with two
temperature control dials, one f or
the driver, and one f or the passenger.
Thedriver’ssideandthepassenger’s
side can be controlled independently
by adjusting these dials when the
green indicator in the DUAL button
is lit.
Push the fan, the A/C, the AUTO, or
the button, and the set
temperatures appear in the display.
When the indicator in the DUAL
button is off, you can adjust both
sides to the same temperature by
turning the driver’s control dial.To set the driver’s side temperature
to a different value than the
passenger’s, press the DUAL button,
then turn the driver’s control dial. To
set the passenger’s side to a
different value than the driver’s side,
turn the passenger’s control dial (see
page ). You can adjust the
passenger’s side without pressing
the DUAL button first.125
Climat e Cont rol Syst em
Comf ort and Convenience Feat ures
Dual Temperature Control
T emperature Control Dials
126
PASSENGER’S SIDE
DRIVER’S SIDE
