6. Install the second speed gear bearing spacer and the second speed bearing.
7.
NOTE: Align the slots in the second gear with the tabs on the synchronizer blocking ring.
Install the second gear onto the output shaft.
8. Install the thrust washer and the snap ring.
9. NOTE: If not done so previously, soak the blocking ring in MERCON® Multi- Purpose ATF
Transmission Fluid XT -2-QDX or equivalent for ten minutes. Klj . 6 ba
102003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

21.
NOTE: If not done so previously, soak the blocking ring in transmission fluid for ten minutes.
Install the fifth speed cluster gear, the synchronizer blocking ring, the synchronizer assembly,
and the fifth gear shifter fork as an assembly.
22. CAUTION: To prevent component damage when installing the extension housing
(7A039), the alignment tab on the reverse brake ring (7M000) must engage the alignment
slot in the extension housing.
NOTE: If not done so previously, soak the blocking ring in transmission fluid for ten minutes.
Install the synchronizer blocking ring, the reverse brake ring, the thrust washer, and the fifth
speed synchronizer retaining snap ring.
23. Apply pipe sealant to the reversing lamp switch threads and install the switch.
24. Install the reverse gearshift lever retaining clip. Klj . 8 ba
142003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

16. Remove the snap ring, then using the special tool, press off the first/second gear synchronizer.
Assembly 1. Carry out the following before reassembling: zInspect the gears for broken or cracked teeth. Check for unusual wear patterns.
z Inspect the thrust washers for face wear, cracks, scoring and for signs of heat damage.
z Inspect the bearings, bearing cups and the synchronizers for wear or damage.
z Inspect the output shaft for scoring or worn or damaged splines. Install new components
as necessary.
2. Lubricate all components with the recommended transmission fluid when reassembling.
3. NOTE: Position the output shaft with the output end facing upward.
NOTE: Install the synchronizer assembly with the deeper center flange of the synchronizer hub
facing toward the rear of the output shaft.
Install the first/second synchronizer assembly on the output shaft, then install a new retaining
ring.
zIt may be necessary to press the hub into position on the shaft. Klj . 6 ba
172003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

Item Part Number Description
1 — Countershaft extension bearing cup
2 — Countershaft extension bearing shim
3 — Fluid funnel
4 — Case plug
5 — Reverse idler shaft bracket
6 — Reverse idler gear thrust washer
7 7141 Reverse idler gear
8 — Reverse idler gear needle bearing
9 7140 Reverse idler gear shaft
10 7052 Extension housing seal
11 — Snap ring
12 — Mainshaft bearing cup
13 — Output shaft speed (OSS) sensor
14 — Reverse lockout solenoid
15 — O-
ring Klj . 2 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

5. Remove the reverse idler gear.
6.
NOTE: If the countershaft extension bearing was installed new, install a new bearing cup.
Remove the reverse idler gear needle bearing and countershaft extension bearing cup. zInspect the needle bearing for wear or damage. Install a new bearing as necessary.
z Inspect the bearing cup for wear or damage. Install a new bearing and bearing cup as
necessary.
7. Remove the reverse idler gear thrust washer and the reverse idler gear shaft.
8. Remove the countershaft extension bearing shim and the fluid funnel. Klj . 4 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

Symptom Chart B1446 Wiper Park Sense Circuit
Failure GEM REFER to
Section 501 - 16 .
B1448 Wiper Park Sense Circuit Short
to Battery GEM REFER to
Section 501 - 16 .
B1450 Wiper Wash/Delay Switch
Circuit Failure GEM REFER to
Section 501 - 16 .
B1453 Wiper Wash/Delay Switch
Circuit Short to Ground GEM REFER to
Section 501 - 16 .
B1458 Wiper Washer Pump Motor
Relay Circuit Failure GEM REFER to
Section 501 - 16 .
B1460 Wiper Washer Pump Motor
Relay Coil Circuit Short to Battery GEM REFER to
Section 501 - 16 .
B1462 Safety Belt Switch Circuit
Failure GEM REFER to
Section 413 - 09 .
B1466 Wiper Hi/Low Speed Not
Switching GEM REFER to
Section 501 - 16 .
B1473 Wiper Low Speed Circuit Motor
Failure GEM REFER to
Section 501 - 16 .
B1476 Wiper High Speed Circuit Motor
Failure GEM REFER to
Section 501 - 16 .
B1551 Decklid Release Circuit Failure GEM REFER to
Section 501 - 14B .
B1553 Decklid Release Circuit Short to
Battery GEM REFER to
Section 501 - 14B .
B1555 Ignition Run/Start Circuit
Failure GEM REFER to
Section 211 - 05 .
B1687 Lamp Dome Input Circuit Short
to Battery GEM REFER to
Section 417 - 02 .
B2486 Parklamp Output Relay Driver
Circuit Failure GEM REFER to
Section 419 - 01 .
B2488 Parklamp Output Relay Driver
Short to Battery GEM REFER to
C1189 Brake Fluid Level Sensor Input
Short Circuit to Ground GEM Go To Pinpoint Test O .
C1223 Lamp Brake Warning Output
Circuit Failure GEM Go To Pinpoint Test O .
C1225 Lamp Brake Warning Output
Circuit Short to Battery GEM Go To Pinpoint Test O .
Symptom Chart Condition
Possible Sources Action
z No communication with
the generic electronic
module (GEM) z
Central junction
box (CJB) fuse
(s):
„7 (15A).
„ 39 (5A).
„ 43 z
Go To Pinpoint Test W Klj . 9 ba
412003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

B1450 Wiper Wash/delay Switch
Circuit Failure GEM GO to
Section 501 - 16 .
B1453 Wiper Wash/delay Switch
Circuit Short to Ground GEM GO to
Section 501 - 16 .
B1458 Wiper Washer Pump Motor
Relay Circuit Failure GEM GO to
Section 501 - 16 .
B1460 Wiper Washer Pump Motor
Relay Circuit Short to Battery GEM GO to
Section 501 - 16 .
B1462 Safety Belt Switch Circuit
Failure GEM GO to
Section 413 - 09 .
B1466 Wiper High/low Speed Not
Switching GEM GO to
Section 501 - 16 .
B1473 Wiper Low Speed Circuit
Motor Failure GEM GO to
Section 501 - 16 .
B1476 Wiper High Speed Circuit
Motor Failure GEM GO to
Section 501 - 16 .
B1498 Decklid Punch-
out Sensor
Ground Short GEM GO to
Section 419 - 01 .
B1551 Decklid Release Circuit
Failure GEM GO to
Section 501 - 14B .
B1553 Decklid Release Circuit Short
to Battery GEM GO to
Section 501 - 14B .
B1555 Ignition RUN/START Circuit
Failure GEM GO to
Section 211 - 05 .
B1603 Lamp Anti-
Theft Indicator
Circuit Failure GEM GO to
Section 419 - 01 .
B1605 Lamp Anti-
Theft Indicator
Circuit Short to Battery GEM GO to
Section 419 - 01 .
B1687 Lamp Dome Input Circuit
Short to Battery GEM GO to
Section 417 - 02 .
B1833 Door Unlock Disarm Switch
Circuit Short to Ground GEM GO to
Section 419 - 01 .
B2486 Parklamp Output Relay Driver
Circuit Failure GEM GO to
Section 419 - 01 .
B2488 Parklamp Output Relay Driver
Circuit Short to Battery GEM GO to
Section 419 - 01 .
C1189 Brake Fluid Level Sensor
Input Circuit Short to Ground GEM REFER to
Section 413 - 01 .
C1223 Lamp Brake Warning Output
Circuit Failure GEM REFER to
Section 413 - 01 .
C1225 Lamp Brake Warning Output
Circuit Short to Battery GEM REFER to
Section 413 - 01 .
ICM DIAGNOSTIC TROUBLE CODE (DTC) INDEX DTC Description Source Action
B1343 Heated Backlight Input Circuit Failure ICM GO to
Pinpoint Test H . Klj . 4 ba
322003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Symptom Chart B1458 Wiper Washer Pump Motor
Relay Circuit Failure GEM REFER to
Section 501 - 16 .
B1460 Wiper Washer Pump Motor
Relay Coil Circuit Short to Battery GEM REFER to
Section 501 - 16 .
B1462 Safety Belt Switch Circuit
Failure GEM REFER to
Section 413 - 09 .
B1466 Wiper Hi/Low Speed Not
Switching GEM REFER to
Section 501 - 16 .
B1473 Wiper Low Speed Circuit Motor
Failure GEM REFER to
Section 501 - 16 .
B1476 Wiper High Speed Circuit Motor
Failure GEM REFER to
Section 501 - 16 .
B1551 Decklid Release Circuit Failure GEM GO to
Pinpoint Test D .
B1553 Decklid Release Circuit Short
to Battery GEM GO to
Pinpoint Test D .
B1555 Ignition Run/Start Circuit
Failure GEM REFER to
Section 211 - 05 .
B1687 Lamp Dome Input Circuit Short
to Battery GEM REFER to
Section 417 - 02 .
B2486 LF Side Repeater Lamp Output
Circuit Failure GEM REFER to
Section 417 - 01 .
B1605 Lamp Anti-
Theft Indicator
Circuit Short to Battery GEM REFER to
Section 501 - 16 .
B2488 RF Side Repeater Lamp Output
Circuit Failure GEM REFER to
Section 417 - 01 .
C1189 Brake Fluid Level Sensor Input
Short Circuit to Ground GEM REFER to
Section 413 - 01 .
C1223 Lamp Brake Warning Output
Circuit Failure GEM REFER to
Section 413 - 01 .
C1225 Lamp Brake Warning Output
Circuit Short to Battery GEM REFER to
Section 413 - 01 .
Symptom Chart Condition
Possible Sources Action
z No communication with the
generic electronic module z
Circuitry.
z CJB Fuse 39 (5A).
z GEM. z
GO to
Pinpoint Test A .
z All door locks are inoperative zCJB Fuse 19 (15A).
z BJB Fuse POWER
WINDOWS (40A).
z Circuitry.
z GEM.
z Switches.
z Lock actuators. z
GO to
Pinpoint Test B .
z The doors do not lock/unlock
using the remote transmitter z
Ignition switch.
z GEM. z
GO to
Pinpoint Klj . 5 ba
