Page 57 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace ifnecessary (Minivan, Concorde, Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
62,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 56
Page 58 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
67,000 km
Dealer copy.
Remove and attach to Repair Order 26-92-14-01 3N.
Maint enance Service Sc hedule ÒBÓ
67 ,000 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace if necessary (Minivan, Concorde,Intrepid and 300M only).
l Change the all-wheel-drive overrunning clutch and rear carrier fluid (Minivan only).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% atsustained high speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
03Minivan and Car Maint 1/15/03 9:55 AM Page 57
Page 59 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace ifnecessary (Minivan, Concorde, Intrepid and 300M only).
l Change the all-wheel-drive overrunning clutch and rearcarrier fluid (Minivan only).*
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals thanshown in Schedule B if the vehicle is operated more than 50% at sustainedhigh speeds during hot weather, above 32 ¡C (90 ¡F) or fif used for trailer tow
or commercial service.Maint enance Service Sc hedule ÒBÓ
67 ,000 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 58
Page 60 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
72,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-15-01 3N.
Maint enance Service Sc hedule ÒBÓ
72,0 00 km
lChange engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect and replace, if required, the air cleaner element (PT Cruiser and Neon only).
l Replace the engine air cleaner filter (Minivan, Concorde, Intrepid and 300M only).
l Inspect and replace, if required, the make-up air filter located inside the air cleaner (Neonand PT Cruiser only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4L Minivan only).
l Change the all-wheel-drive power transfer unit fluid (Minivan only).*
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all except Sebring and Sebring Convertible).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% atsustained high speeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or commercial service.
03Minivan and Car Maint 1/15/03 9:55 AM Page 59
Page 61 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary(Sebring, Sebring Convertible only).
l Inspect and replace, if required, the air cleaner element (PT Cruiser and Neon only).
l Replace the engine air cleaner filter (Minivan, Concorde, Intrepidand 300M only).
l Inspect and replace, if required, the make-up air filter locatedinside the air cleaner (Neon and PT Cruiser only).
l Adjust the drive belt tension (Concorde, Intrepid and 300M only).
l Inspect the generator belt, replace if necessary (2.4L Minivan only).
l Inspect and adjust the power steering pump belt tension (2.4LMinivan only).
l Change the all-wheel-drive power transfer unit fluid (Minivanonly).*
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (all except Sebring and Sebring Convertible).
l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
* All-wheel-drive minivans power transfer unit fluid and overrunning clutch/ rear carrier fluid must be changed at more frequent intervals than shown in Schedule B if the vehicle is operated more than 50% at sustained highspeeds during hot weather, above 32 ¡C (90 ¡F) or if used for trailer tow or
commercial service.Maint enance Service Sc hedule ÒBÓ
72,0 00 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 60
Page 62 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
77,000 km
Dealer copy.
Remove and attach to Repair Order 26-92-16-01 3N.
Maint enance Service Sc hedule ÒBÓ
77 ,000 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace if necessary (Minivan, Concorde,Intrepid and 300M only).
l Replace the air conditioning filter (Minivan only).
l Change the automatic transaxle fluid and filter.
l Replace the differential fluid (Concorde, Intrepid and 300M only).
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring and Sebring Convertible only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
03Minivan and Car Maint 1/15/03 9:55 AM Page 61
Page 63 of 131
Odometer Reading
Date
Repair Order No.
DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace ifnecessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace ifnecessary (Minivan, Concorde, Intrepid and 300M only).
l Replace the air conditioning filter (Minivan only).
l Change the automatic transaxle fluid and filter.
l Replace the differential fluid (Concorde, Intrepid and300M only).
l Tires Ð Rotate and check tire pressure.
INSPECT THE FOLLOWING: l Inspect the front and rear brake linings and components (Sebring and Sebring Convertible only).
l Inspect the brake hoses.
l Check the manual transaxle fluid level and fill plugcondition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.Maint enance Service Sc hedule ÒBÓ
77 ,000 km
03Minivan and Car Maint 1/15/03 9:55 AM Page 62
Page 64 of 131
Maintenance Service
Sc hedule ÒBÓ
Odometer Reading
Date
82,0 00 km
Dealer copy.
Remove and attach to Repair Order 26-92-17-01 3N.
Maint enance Service Sc hedule ÒBÓ
82,0 00 km
l Change engine oil and engine oil filter (or every 3 months).
l Inspect and lubricate as required all steering and suspension components.
l Inspect the engine air cleaner filter and replace if necessary (Sebring, Sebring Convertible only).
l Inspect the engine air cleaner filter and replace if necessary (Minivan, Concorde,Intrepid and 300M only).
INSPECT THE FOLLOWING: l Inspect the brake hoses.
l Check the automatic transaxle fluid level.
l Check the manual transaxle fluid level and fill plug condition.
l Check the coolant level, hoses and clamps.
l Inspect the exhaust system.
03Minivan and Car Maint 1/15/03 9:55 AM Page 63
