2003 CHEVROLET SSR spark plug

Additives
To provide cleaner air, all gasolines in the United
States are now required to contain additives that will
help prevent engine and fuel system deposits from
forming, allowing your emission control system to
work properly. You should not have to add anything to
your fuel. Gasolines containing oxygenates, such as
ethers and ethanol, and reformulated gasolines may
be available in your area to contribute to clean air.
General Motors recommends that you use these
gasolines, particularly if they comply with the
specications described earlier.
Notice:Your vehicle was not designed for fuel
that contains methanol. Do not use fuel containing
methanol. It can corrode metal parts in your fuel
system and also damage the plastic and rubber
parts. That damage would not be covered under
your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane-enhancing additive
called methylcyclopentadienyl manganese tricarbonyl
(MMT); ask the attendant where you buy gasoline
whether the fuel contains MMT. General Motors
does not recommend the use of such gasolines.Fuels containing MMT can reduce the life of spark plugs
and the performance of the emission control system
may be affected. The malfunction indicator lamp
may turn on. If this occurs, return to your authorized
GM dealer for service.
Fuels in Foreign Countries
If you plan on driving in another country outside the
United States or Canada, the proper fuel may be hard
to nd. Never use leaded gasoline or any other fuel
not recommended in the previous text on fuel. Costly
repairs caused by use of improper fuel would not
be covered by your warranty.
To check the fuel availability, ask an auto club, or
contact a major oil company that does business in
the country where you will be driving.
5-7

Notice:Ignoring these steps could result in costly
damage to your vehicle that would not be covered
by your warranty.
Trying to start your vehicle by pushing or pulling it
will not work, and it could damage your vehicle.
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
Notice:If the other vehicle’s system is not a 12-volt
system with a negative ground, both vehicles can
be damaged. Only use vehicles with 12-volt systems
with negative grounds to jump start your vehicle.
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren’t touching
each other. If they are, it could cause a ground
connection you don’t want. You wouldn’t be able to
start your vehicle and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake rmly on both vehicles involved in
the jump start procedure. Put your transmission
in PARK (P) before setting the parking brake.
Notice:If you leave your radio or other accessories
on during the jump starting procedure, they could
be damaged. The repairs would not be covered
by your warranty. Always turn off your radio and
other accessories when jump starting your vehicle.3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the accessory power outlets. Turn off
the radio and all lamps that aren’t needed. This will
avoid sparks and help save both batteries. And it
could save your radio.
4. Open the hoods and locate the positive (+) and
negative (−) terminal locations on the other vehicle.
Your vehicle has a remote positive (+) jump starting
terminal and a remote negative (−) jump starting
terminal. You should always use these remote
terminals instead of the terminals on the battery.
The remote positive (+)
terminal is located in the
engine compartment
on the passenger’s side
of the vehicle.
Press inward on the tabs located on the outboard
sides of the remote positive (+) terminal cover
and pull outward to access the terminal.
5-37

Capacities and Specications
Refer toPart D: Recommended Fluids and Lubricants on page 6-15for more information. All capacities are
approximate. When adding uids, be sure to ll to the appropriate level, as recommended in this manual.
Recheck the uid level after lling.
Capacities and Specications
Engine VIN Code Transmission Spark Plug Gap
5.3L V8 T M30 0.040 inches (1.01 mm)
ApplicationCapacities
English Metric
Air conditioning Refrigerant R-134a 2.8 lbs. 1.27 kg
Cooling System 15.3 quarts 14.5 L
Differential Fluid 4.0 quarts 6.6 L
Engine Oil with Filter 6.0 quarts 5.7 L
Fuel Tank 25.0 gallons 94.6 L
Rear Axle 2.4 quarts 2.3 L
Transmission
(Drain and Rell)5.0 quarts 4.7 L
Wheel Nut Torque 100 ft-lbs. 140Y
5-90

Normal Maintenance Replacement Parts
Replacement parts identied below by name, part number, or specication can be obtained from your dealer.
PartNumber
Automatic Transmission Filter Kit 24200796**
Engine Air Cleaner/FilterA2014C*
15036141**
Engine Oil FilterPF44*
25010633**
Fuel FilterGF831*
88983068**
Spark Plugs41–985*
12571164**
Windshield Wiper Blade 20.0 inches (50.8 cm)
*ACDelco
®part number
**GM part number
5-91

90,000 Miles (150 000 km)
❑Change automatic transmission uid and lter if the
vehicle is mainly driven under one or more of these
conditions:
In heavy city traffic where the outside
temperature regularly reaches 90°F (32°C)
or higher.
In hilly or mountainous terrain.
When doing frequent trailer towing.
Uses such as found in taxi, police or delivery
service.
❑Check rear axle uid level and add uid as needed.
❑Replace fuel lter.An Emission Control Service.
(See Footnote †.)
❑Replace engine air cleaner lter. SeeEngine Air
Cleaner/Filter on page 5-20for more information.
An Emission Control Service.
97,500 Miles (162 500 km)
❑Check rear axle uid level and add uid as needed.
100,000 Miles (166 000 km)
❑Inspect spark plug wires.An Emission Control
Service.
❑Replace spark plugs.An Emission Control Service.
150,000 Miles (240 000 km)
❑Drain, ush and rell cooling system (or every
60 months since last service, whichever occurs rst).
SeeEngine Coolant on page 5-24for what to use.
Inspect hoses. Clean radiator, condenser, pressure
cap and neck. Pressure test the cooling system
and pressure cap.An Emission Control Service.
❑Inspect engine accessory drive belt.An Emission
Control Service.
6-8
