2003 CHEVROLET C/K warning light

iv
Vehicle Damage Warnings
Also, in this book you will find these notices:
NOTICE:
These mean there is something that could damage
your vehicle.
In the notice area, we tell you about something that can
damage your vehicle. Many times, this damage would
not be covered by your warranty, and it could be costly.
But the notice will tell you what to do to help avoid
the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different
colors or in different words.
You'll also see warning labels on your vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
Your vehicle may be equipped with components and
labels that use symbols instead of text. Symbols,
used on your vehicle, are shown along with the text
describing the operation or information relating to a
specific component, control, message, gage or indicator.
If you need help figuring out a specific name of a
component, gage or indicator reference the following
topics in the Index:

ªInstrument Panelº

ªComfort Controlsº

ªAudio Systemsº
Also see ªWarning Lights and Gagesº in the Index.

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2-5 Keys
2-7 Door Locks
2-8 Keyless Entry System (If Equipped)
2-12 Switchbanks
2-13 Theft
2-14 New Vehicle ªBreak-Inº
2-15 Ignition Positions
2-16 Starting Your Gasoline Engine
2-19 Starting the Diesel Engine
2-24 Starting Your DURAMAX
Diesel Engine
2-27 Engine Checks Before Operating
2-28 Engine Coolant Heater (If Equipped)
2-30 Diesel Engine Exhaust Brake (If Equipped)
2-31 Two-Speed Rear Axle Electric Shift Control
(If Equipped)
2
-34 Automatic Transmission Operation
2-36 Manual Transmission Operation
2-40 Parking
2-45 Parking Over Things That Burn
2-45 Engine Exhaust2
-46 Running Your Engine While You're Parked
(Automatic Transmission)
2
-47 Horn
2-48 Tilt Wheel (If Equipped)
2-48 Turn Signal/Multifunction Lever
2-55 Inter-Axle Differential Lock Control
(If Equipped)
2
-56 Rear Axle Differential Lock Control
(If Equipped)
2
-57 Exterior Lamps
2-60 Interior Lamps
2-61 Mirrors
2-63 Storage Compartments
2-65 Accessory Power Outlets
2-66 Trailer Connections (C4/C5 Models Only)
(If Equipped)
2
-67 Trailer Connections (C6/C7/C8 Models Only)
(If Equipped)
2
-68 The Instrument Panel-Your
Information System
2
-70 Instrument Panel Cluster
2-73 Warning Lights, Gages and Indicators

2-21 Engine Alarm and Automatic Shutdown
(If Equipped)
Your check gages light will come on if the system senses
high engine temperature or low engine oil pressure. If high
engine temperature or low engine oil pressure is detected,
you will also hear a tone alarm at two beats per second.
The alarm and the light will remain on until the condition
is fixed. If the engine temperature or oil pressure condition
worsens, the tone alarm will go to five beats per second.
If the system senses low engine coolant, the five beat
per second alarm and the low coolant warning light will
come on.
The five beats per second tone alarm means that your
engine will shut down in approximately 25
-30 seconds.
There is also an engine shutdown light to indicate that
the engine will shut down. See ªAutomatic Engine
Shutdown Lightº later in this section.
Pull off the road and shut off the engine. Don't start it
until the reason for the problem is known, and the
problem is fixed. If the engine shuts down when you are
still in traffic, you can restart the engine and get another
25
-30 seconds of operation. Do this only if you have to,
since there is a problem that can harm the engine if it
isn't fixed. Engine automatic shutdown, for gasoline
engines, requires activation by your dealer.
High Idle System (Caterpillar
Diesel
and Gasoline Engines)
Your vehicle has both automatic and manual high idle
capabilities.
Automatic High Idle System (Diesel Engines)
(If Equipped)
The automatic high idle feature will engage whenever
you start your vehicle and the engine is below the preset
operating temperature. This will help decrease engine
warm
-up time.
Idle speed will then return to normal under any of the
following conditions:

The engine reaches the preset operating temperature
or has been operating for at least ten minutes.

The brake pedal is pressed.

The manual transmission clutch pedal is pressed or,
the automatic transmission (if equipped) is shifted
from NEUTRAL (N) or PARK (P).

The vehicle speed exceeds approximately
5 mph (8 km/h).

The throttle is pressed.

2-27
Engine Checks Before Operating
When you've started your engine, let it run for 20 to
30 seconds before you put a load on the engine. But
don't leave the vehicle while the engine is running.
Avoid unnecessary idling of diesel engine equipped
vehicles.
If the engine idles too long, the temperature of the
engine coolant will fall below the normal operating
range. Low engine operating temperature causes several
conditions which affect engine operation and reduce
engine life.
The engine should be permitted to go through a
warm
-up period. Operate the vehicle at a minimum of
600 rpm during the warm
-up period. During this period
and during operation, the following observations should
be made.
During this warm
-up period, check your warning lights
and gages:

If oil pressure doesn't begin to rise within
15 seconds of starting, stop the engine and
find the cause.
If the engine coolant temperature gage needle goes
into the hot area on the gage, stop the engine and
find the cause of the overheating.

If you have air brakes, the dual
-needle air pressure
gage should read at least 115 psi (790 kPa) for both
service systems before you try to move the vehicle.
When air pressure is below 60 psi (420 kPa), the
LOW AIR light will come on and you will hear a
tone alarm. If the pressure doesn't build up or
drops during warm
-up, stop the engine and find
the cause before you try to move the vehicle.
Recommended air pressure before actually driving
away is 120 psi (830 kPa).

The charging system light should come on when
the ignition key is turned to RUN or START and
should go out when the engine is running above idle.
If the light doesn't go out or comes back on during
normal engine operation, have the charging system
checked right away. (This light tells you if the
generator is not charging; it doesn't reflect the
condition of the battery.)

2-41
To set the hand lever parking brake, pull up on the
handle with your right hand, until it stops.
If the ignition is on when the parking brake is set, the
brake system warning light will come on.
To release the foot pedal parking brake, hold the regular
brake pedal down. Pull the brake release handle, located
just above the parking brake pedal, to release the
parking brake.
To release the hand lever parking brake, push down on
the handle until it stops.
If the ignition is on when the parking brake is released,
the brake system warning light will go off.
NOTICE:
Driving with the parking brake on can cause
your rear brakes to overheat. You may have to
replace them, and you could also damage other
parts of your vehicle. Always check to be sure
your parking brake is fully released before
you drive.
Propshaft Park Brake Burnish Procedure
It is recommended that the propshaft-mounted parking
brake be burnished as part of the new vehicle break
-in.
The parking brake will work best after it has been
burnished following these instructions:
Make 10 stops, using the parking brake hand lever or
foot pedal, from 20 mph (32 km/h) about 2 1/2 miles
(4 km) apart. Between stops, drive the vehicle at
20 mph (32 km/h).

2-44
CAUTION:
If you apply any one of the air brake parking
controls while the vehicle is moving, your rig will
stop suddenly. If you are not ready for this, you
or others could be injured. Don't apply any one
of these controls while you're driving, unless you
have to make an emergency stop.
If the air pressure drops below 60 to 70 psi (413 to
482 kPa), the primary brake light and warning buzzer
will come on. If the air pressure drops to 35 to 45 psi
(241 to 310 kPa), the red trailer air supply knob will
automatically pop out and apply the spring brakes on
the trailer.If the air pressure drops to 35 to 45 psi (241 to 310 kPa),
the yellow park brake knob will automatically pop out
and apply the spring brakes on the truck or tractor.
If you ever have a complete loss of air so that your air
brakes automatically apply, there is a way that the tow
operator can release the parking brakes to tow the
vehicle. See ªTowing Your Vehicleº in the Index.
CAUTION:
If your vehicle is left in gear, the engine can start
if the vehicle starts to roll. This can easily happen
if you have the diesel engine. Shift the
transmission into NEUTRAL (N) before you
leave the vehicle.

2-69
The main components of your instrument panel are the following:
A. Vents
B. Instrument Panel Cluster
C. Column Shift Lever (If Equipped)
D. Air Brake Control(s) (If Equipped)
E. Auxiliary Gages (If Equipped)
F. Exterior Lamp Control
G. Turn Signal Multifunction Lever
H. Hazard Warning Flashers ButtonI. Auxiliary Switches (If Equipped)
J. Audio System or Storage Area
K. Auxiliary Warning Lights
L. Comfort Controls
M. Instrument Panel Switchbank
N. Air Bag Off Switch (If Equipped)
P. Accessory Power Outlets

2-73 Tachometer
7.2L Caterpillar
Diesel Engine and
7.8L DURAMAX
Diesel EnginesGasoline and
6.6L DURAMAX
Diesel Engines
This gage shows the engine speed in revolutions per
minute (rpm).
Warning Lights, Gages and
Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
