2003 CHEVROLET C/K differential

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2-5 Keys
2-7 Door Locks
2-8 Keyless Entry System (If Equipped)
2-12 Switchbanks
2-13 Theft
2-14 New Vehicle ªBreak-Inº
2-15 Ignition Positions
2-16 Starting Your Gasoline Engine
2-19 Starting the Diesel Engine
2-24 Starting Your DURAMAX
Diesel Engine
2-27 Engine Checks Before Operating
2-28 Engine Coolant Heater (If Equipped)
2-30 Diesel Engine Exhaust Brake (If Equipped)
2-31 Two-Speed Rear Axle Electric Shift Control
(If Equipped)
2
-34 Automatic Transmission Operation
2-36 Manual Transmission Operation
2-40 Parking
2-45 Parking Over Things That Burn
2-45 Engine Exhaust2
-46 Running Your Engine While You're Parked
(Automatic Transmission)
2
-47 Horn
2-48 Tilt Wheel (If Equipped)
2-48 Turn Signal/Multifunction Lever
2-55 Inter-Axle Differential Lock Control
(If Equipped)
2
-56 Rear Axle Differential Lock Control
(If Equipped)
2
-57 Exterior Lamps
2-60 Interior Lamps
2-61 Mirrors
2-63 Storage Compartments
2-65 Accessory Power Outlets
2-66 Trailer Connections (C4/C5 Models Only)
(If Equipped)
2
-67 Trailer Connections (C6/C7/C8 Models Only)
(If Equipped)
2
-68 The Instrument Panel-Your
Information System
2
-70 Instrument Panel Cluster
2-73 Warning Lights, Gages and Indicators

2-12
Switchbanks
Instrument Panel Switchbank
This switchbank is located in the center of the
instrument panel.
The switchbank may include marker lamp defeat, high
idle, traction control, heated mirrors, power take
-off,
rear air suspension, two
-speed axle (electric), exhaust
brake, two
-speed axle (air), differential lock, rear axle
differential lock and inter
-axle differential lock. If your
vehicle does not have some of the features controlled
by these switches, there will be a blank switch marker in
its place.
For more information, see each of these features in
the Index.

2-55
Inter-Axle Differential Lock Control
(If Equipped)
If your vehicle has this
feature, the switch is located
in the center of the
instrument panel.
If you're approaching a slippery surface where it looks
like one or even all of the wheels may start to slip, you
can press the bottom of this switch. It locks your rear
differentials so that power is transmitted equally to both
rear axles.Let up on the accelerator before you turn on your
inter
-axle differential lock. When you turn on this
control, the diff lock indicator on the center of the
instrument panel will light.
NOTICE:
Activating the inter-axle differential lock when
the rear wheels are actually spinning freely, as
they might on ice or snow, can cause you to lose
control of the vehicle. It can also damage the
axles. Turn on this control only when the wheels
are not spinning freely.

2-56
Rear Axle Differential Lock Control
(If Equipped)
If your vehicle has a
controlled traction or
locking differential axle,
the switch is located in the
center of the instrument
panel. You'll see this
control on single rear
axle vehicles.If you're approaching a slippery surface where it looks
like one or even both wheels may start to slip, you can
press the bottom of this switch. It locks your rear
differential so that power is transmitted equally to both
rear wheels.
Let up on the accelerator before you turn on your rear
axle differential lock.
NOTICE:
Activating the rear-axle differential lock when
the rear wheels are actually spinning freely, as
they might on ice or snow, can cause you to lose
control of the vehicle. It can also damage the axle.
Turn on this control only when the wheels are not
spinning freely.

2-91 Exhaust Brake Indicator Light
(If Equipped)
If your vehicle is equipped
with an exhaust brake, you
will have this light, located
above the comfort controls
in the center of the
instrument panel.
The exhaust brake indicator light will come on and stay
on whenever the diesel engine exhaust brake or exhaust
restrictor is active. For more information, see ªDiesel
Engine Exhaust Brakeº in the Index.
Diff Lock Indicator Light (If Equipped)
This light located in the
center of the instrument
panel is on when the
inter
-axle differential
lock system is in use.
The light will come on momentarily during starting.
If the light fails to come on, have it repaired as soon
as possible so you will be aware when the lock system
is in use.

6-34
Rear Axle
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it. See
ªScheduled Maintenance Servicesº in the Index.
How to Check Lubricant
To get an accurate reading, the vehicle should be on a
level surface.If the level is below the bottom of the filler plug hole,
you'll need to add some lubricant. Add enough lubricant
to raise the level to the bottom of the filler plug hole.
What to Use
Refer to the Maintenance Schedule to determine what
kind of lubricant to use. See ªRecommended Fluids and
Lubricantsº in the Index.
Rear Axle Shift Motor (Option)
When to Check and Change Fluid
If you have an optional air-shift two-speed, controlled
traction, or locking differential type rear axle, a good
time to check the fluid level in the axle shift motor is
when the rear axle lubricant is checked. Use refrigerant
oil (shift motor only).
How to Check Fluid
Remove the plug on the front plate of the axle shift
motor, add enough fluid to raise the level to the bottom
of the filler plug hole, then replace the plug.
What to Use
Refer to your Maintenance Schedule to determine what
kind of lubricant to use. See ªRecommended Fluids and
Lubricantsº in the Index.
