2003 CADILLAC ESCALADE EXT clock

4. Repeat this procedure at least two times. If the
spare tire lowers to the ground, continue with
Step 5 of ªRemoving the Spare Tire and Toolsº
earlier in this section.
5. Turn the wrench counterclockwise until
approximately six inches (15 cm) of cable is
exposed.
6. Stand the wheel blocks
on their shortest ends,
with the backs
facing each other.7. Place the bottom edge of the jack on the wheel
blocks, separating them so that the jack is
balanced securely.
5-90

8. Attach the jack handle, extension, and wheel
wrench to the jack and place it (with the wheel
blocks) under the vehicle towards the front of the
rear bumper. Position the center lift point of the jack
under the center of the spare tire.
9. Turn the wrench clockwise to raise the jack until it
lifts the end ®tting.
10. Continue raising the jack until the spare tire
stops moving upward and is held ®rmly in place.
The secondary latch has released and the spare tire
is balancing on the jack.11. Lower the jack by turning the wheel wrench
counterclockwise. Keep lowering the jack until
the spare tire slides off the jack or is hanging by
the cable.
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack. If the
spare tire does not slide off the jack completely,
make sure no one is behind you or on either
side of you as you pull the jack out from the
spare.
12. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to push
against the spare while ®rmly pulling the jack out
from under the spare tire with the other hand.
If the spare tire is hanging from the cable, insert the
hoist handle, extension and wheel wrench into the
hoist shaft hole in the bumper and turn the wheel
wrench counterclockwise to lower the spare the rest
of the way.
5-91

13. Tilt the retainer at the
end of the cable and
pull it through the
wheel opening.
Pull the tire out from
under the vehicle.
14. If the cable is hanging under the vehicle, turn the
wheel wrench clockwise to raise the cable back up.
Have the hoist assembly inspected as soon as you can.
You will not be able to store a spare or ¯at tire using
the hoist assembly until it has been replaced.
To continue changing the ¯at tire, see ªRemoving the
Flat Tire and Installing the Spare Tireº earlier in
this section.Spare Tire
Your vehicle, when new, had a fully in¯ated spare tire.
A spare tire may lose air over time, so check its
in¯ation pressure regularly. See
In¯ation Ð Tire
Pressure on page 5-67andLoading Your Vehicle on
page 4-48for information regarding proper tire in¯ation
and loading your vehicle. For instruction on how to
remove, install or store a spare tire, see
Changing a Flat
Tire on page 5-76.
After installing the spare tire on your vehicle, you should
stop as soon as possible and make sure the spare is
correctly in¯ated. Have the damaged or ¯at road
tire repaired or replaced as soon as you can and
installed back onto your vehicle. This way, a spare tire
will be available in case you need it again.
If your vehicle has a spare tire that does not match your
vehicle's original road tires and wheels in size and
type, do not include the spare in the tire rotation.
5-92

A
Accessory Power Outlets.................................3-22
Adding Washer Fluid.......................................5-38
Additional Program Information........................... 7-9
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment...........................5-101
Add-On Equipment..........................................4-50
Adjustable Throttle and Brake Pedal..................2-30
Adjusting the Speakers (Balance/Fade)..............3-71
After Off-Road Driving.....................................4-32
Air Bag Systems.............................................1-50
Adding Equipment to Your Air Bag-Equipped
Vehicle...................................................1-65
How Does an Air Bag Restrain?....................1-57
Passenger Sensing System...........................1-60
Servicing Your Air Bag-Equipped Vehicle.........1-64
What Makes an Air Bag In¯ate?....................1-57
What Will You See After an
Air Bag In¯ates?......................................1-58
When Should an Air Bag In¯ate?...................1-55
Where Are the Air Bags?..............................1-53
Air Bag .........................................................3-35
Passenger Status Indicator...........................3-35
Readiness Light..........................................3-34
Air Cleaner/Filter, Engine.................................5-19
Air Conditioning..............................................3-28
All-Wheel Drive (AWD) System.........................2-35All-Wheel Drive...............................................5-50
AM ...............................................................3-99
Analog Clock..................................................3-23
Antenna, Fixed Mast......................................3-101
Antenna, XMŸ Satellite Radio
Antenna System........................................3-101
Anti-Lock Brake, System Warning Light..............3-39
Anti-lock Brake System..................................... 4-7
Appearance Care............................................5-93
Care of Safety Belts....................................5-95
Chemical Paint Spotting...............................5-98
Cleaning the Inside of Your Vehicle................5-93
Cleaning the Outside of Your Vehicle..............5-96
Finish Damage............................................5-98
Sheet Metal Damage...................................5-98
Underbody Maintenance...............................5-98
Vehicle Care/Appearance Materials................5-99
Weatherstrips..............................................5-95
Approaching a Hill..........................................4-23
Ashtrays........................................................3-23
Audio Output..................................................3-90
Audio System(s).............................................3-66
Audio Steering Wheel Controls......................3-98
Care of Your Cassette Tape Player................3-99
Care of Your CD and DVD Player................3-101
Care of Your CD Changer...........................3-101
Care of Your CDs and DVDs.......................3-101
CD Changer...............................................3-95
1

Child Restraints (cont.)
Securing a Child Restraint in the Right
Front Seat Position...................................1-46
Top Strap Anchor Location............................1-41
Top Strap...................................................1-40
Where to Put the Restraint...........................1-38
Cigarette Lighter.............................................3-23
Cleaning Aluminum Wheels..............................5-97
Cleaning Exterior Lamps/Lenses.......................5-96
Cleaning Fabric/Carpet....................................5-93
Cleaning Glass Surfaces..................................5-95
Cleaning Interior Plastic Components.................5-94
Cleaning Leather............................................5-94
Cleaning the Mirror.........................................2-43
Cleaning the Speaker Covers...........................5-95
Cleaning the Top of the Instrument Panel...........5-94
Cleaning the Windshield and
Wiper Blades..............................................5-97
Cleaning Tires................................................5-98
Cleaning Vinyl................................................5-94
Cleaning Wood Panels....................................5-95
Cleaning........................................................5-93
Inside of Your Vehicle..................................5-93
Outside of Your Vehicle................................5-96
Underbody Maintenance...............................5-98
Video Screen............................................3-101
Weatherstrips..............................................5-95Climate Control System...................................3-24
Automatic...................................................3-24
Climate Controls Personalization....................3-30
Outlet Adjustment........................................3-30
Clock............................................................3-23
Compact Disc Changer Errors..........................3-97
Compact Disc Messages..................................3-81
Compass Calibration.......................................2-43
Compass Variance..........................................2-42
Content Theft-Deferrent....................................2-26
Control of a Vehicle.......................................... 4-6
Coolant.........................................................3-40
Engine Temperature Gage............................3-40
Heater, Engine............................................2-31
Surge Tank Pressure Cap.............................5-27
Cooling System..............................................5-30
Cruise Control Light........................................3-45
Cruise Control................................................3-10
Cupholder(s)..................................................2-52
Current and Past Model Order Forms................7-11
Customer Assistance Information........................ 7-7
Courtesy Transportation.................................. 7-7
Customer Assistance for Text Telephone
(TTY) Users.............................................. 7-4
Customer Assistance Offices........................... 7-4
Customer Satisfaction Procedure..................... 7-2
GM Mobility Program for Persons with
Disabilities................................................ 7-5
4
