2003 BUICK RANDEZVOUS power steering fluid

Service............................................................5-3
Doing Your Own Service Work.........................5-3
Adding Equipment to the Outside of
Your Vehicle..............................................5-4
Fuel................................................................5-4
Gasoline Octane............................................5-4
Gasoline Specifications....................................5-5
California Fuel...............................................5-5
Additives.......................................................5-6
Fuels in Foreign Countries...............................5-6
Filling Your Tank............................................5-6
Filling a Portable Fuel Container.......................5-8
Checking Things Under
the Hood......................................................5-9
Hood Release................................................5-9
Engine Compartment Overview.......................5-10
Engine Oil...................................................5-11
Engine Air Cleaner/Filter................................5-15
Automatic Transaxle Fluid..............................5-17
Engine Coolant.............................................5-19
Radiator Pressure Cap..................................5-21
Engine Overheating.......................................5-22
Cooling System............................................5-24
Power Steering Fluid.....................................5-31Windshield Washer Fluid................................5-32
Brakes........................................................5-33
Battery........................................................5-36
Jump Starting...............................................5-36
All-Wheel Drive..............................................5-41
Bulb Replacement..........................................5-42
Halogen Bulbs..............................................5-43
Headlamps..................................................5-43
Front Turn Signal, Sidemarker and
Parking Lamps..........................................5-44
Taillamps, Turn Signal, and Stoplamps............5-45
Taillamps and Back-Up Lamps.......................5-45
Replacement Bulbs.......................................5-46
Windshield Wiper Blade Replacement..............5-47
Tires..............................................................5-48
Inflation -- Tire Pressure................................5-49
Check Tire Pressure System..........................5-49
Tire Inspection and Rotation...........................5-51
When It Is Time for New Tires
.......................5-52
Buying New Tires
.........................................5-53
Uniform Tire Quality Grading
..........................5-54
Wheel Alignment and Tire Balance
..................5-55
Wheel Replacement
......................................5-55
Section 5Service and Appearance Care
5-1
2003 - Rendezvous OM

Engine Compartment Overview
When you lift the hood, you’ll see these items:
A. Underhood Fuse Block
B. Remote Positive (+) TerminalC. Power Steering Fluid Reservoir
D. Automatic Transaxle Fluid Dipstick
5-10
2003 - Rendezvous OM

9. Thenfill the coolant recovery tank to the FULL
COLD mark.
10. Put the cap back on the coolant recovery tank.
Power Steering Fluid
The power steeringfluid reservoir is located to the right
of the windshield washerfluid reservoir, at the back
of the engine compartment.
When to Check Power Steering Fluid
It is not necessary to regularly check power steeringfluid
unless you suspect there is a leak in the system or
you hear an unusual noise. Afluid loss in this system
could indicate a problem. Have the system inspected
and repaired. SeeEngine Compartment Overview
on page 5-10for reservoir location.
5-31
2003 - Rendezvous OM

How to Check Power Steering Fluid
Turn the key off, let the engine compartment cool down,
wipe the cap and the top of the reservoir clean, then
unscrew the cap and wipe the dipstick with a clean rag.
Replace the cap and completely tighten it. Then
remove the cap again and look at thefluid level on the
dipstick.
When the engine compartment is hot, the level should
be at the H (hot) mark. When it’s cold, the level
should be at the C (cold) mark. If thefluid is at the ADD
mark, you should addfluid.
What to Use
To determine what kind offluid to use, seePart D:
Recommended Fluids and Lubricants on page 6-15.
Always use the properfluid. Failure to use the proper
fluid can cause leaks and damage hoses and seals.
Windshield Washer Fluid
What to Use
When you need windshield washerfluid, be sure to read
the manufacturer’s instructions before use. If you will
be operating your vehicle in an area where the
temperature may fall below freezing, use afluid that has
sufficient protection against freezing. SeeEngine
Compartment Overview on page 5-10for reservoir
location.
Adding Washer Fluid
Open the cap with the
washer symbol on it. Add
washerfluid until the
tank is full.
Notice:
•When using concentrated washerfluid,
follow the manufacturer’s instructions for
adding water.
•Don’t mix water with ready-to-use washerfluid.
Water can cause the solution to freeze and
damage your washerfluid tank and other parts
of the washer system. Also, water doesn’t
clean as well as washerfluid.
•Fill your washerfluid tank only three-quarters
full when it’s very cold. This allows for
expansion if freezing occurs, which could
damage the tank if it is completely full.
5-32
2003 - Rendezvous OM

Part D: Recommended Fluids and
Lubricants
Fluids and lubricants identied below by name, part
number or specication may be obtained from your
dealer.
Usage Fluid/Lubricant
Engine OilEngine oil with the American
Petroleum Institute Certied for
Gasoline Engines starburst symbol
of the proper viscosity. To determine
the preferred viscosity for your
vehicle’s engine, seeEngine Oil on
page 5-11.
Engine Coolant50/50 mixture of clean, drinkable
water and use only
DEX-COOL
®Coolant. SeeEngine
Coolant on page 5-19.
Hydraulic Brake
SystemDelco Supreme 11 Brake Fluid or
equivalent DOT-3 brakeuid.
Windshield
Washer SolventGM Optikleen
®Washer Solvent or
equivalent.
Power Steering
SystemGM Power Steering Fluid (GM Part
No. U.S. 1052884, in Canada
993294, or equivalent).
Usage Fluid/Lubricant
Automatic
TransaxleDEXRON®-III Automatic
Transmission Fluid.
Key Lock
CylindersMulit-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Carrier
Assembly—
Differential
(Rear Drive
Module)
and Transfer
Case (Power
Transfer Unit)VERSATRAK™Fluid (GM Part No.
U.S. 12378514, in Canada
88901045).
Hood Latch
Assembly,
Secondary
Latch, Pivots,
Spring Anchor
and Release
PawlLubriplate Lubricant Aerosol (GM
Part No. U.S. 12346293, in Canada
992723, or equivalent) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Hood and Door
Hinges, Rear
Folding SeatMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474, or equivalent).
Weatherstrip
ConditioningDielectric Silicone Grease (GM Part
No. U.S. 12345579, in Canada
10953014, or equivalent).
6-15
2003 - Rendezvous OM

A
About Driving Your Vehicle.....................................ii
Accessory Inflator...........................................5-57
Accessory Power Outlets.................................3-23
Adding Washer Fluid.......................................5-32
Additional Program Information........................... 7-8
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment............................5-85
Adjusting the Captain’s Chairs
(Second Row).............................................1-12
Adjusting the Speakers....................3-67, 3-74, 3-84
Air Bag
Readiness Light..........................................3-37
Air Bag Systems.............................................1-67
How Does an Air Bag Restrain?....................1-73
Servicing Your Air Bag-Equipped Vehicle.........1-76
What Makes an Air Bag Inflate?....................1-73
What Will You See After an Air Bag Inflates?......1-74
When Should an Air Bag Inflate?...................1-72
Where Are the Air Bags?..............................1-70
Air Cleaner/Filter, Engine.................................5-15
All Overseas Locations...................................... 7-4
All-Wheel Drive......................................5-41, 5-77
All-Wheel Drive Disable Warning Message..........3-49
All-Wheel-Drive (AWD) System.........................4-11
Aluminum or Chrome-Plated Wheels..................5-82
AM .............................................................3-108
Antenna, Integrated Windshield.......................3-110Antenna, XM™ Satellite Radio Antenna System . . . 3-110
Anti-lock Brake System (ABS)............................ 4-8
Anti-Lock Brake, System Warning Light..............3-39
Appearance Care............................................5-77
Care of Safety Belts....................................5-80
Chemical Paint Spotting...............................5-83
Cleaning the Inside of Your Vehicle................5-78
Cleaning the Outside of Your Vehicle..............5-80
Finish Damage............................................5-83
GM Vehicle Care/Appearance Materials..........5-83
Sheet Metal Damage...................................5-82
Underbody Maintenance...............................5-83
Weatherstrips..............................................5-80
Arming with the Power Lock Switch...................2-15
Arming with the Remote Keyless Entry
Transmitter
.................................................2-16
Ashtrays
........................................................3-24
Audio Speakers
..............................................3-95
Audio System(s)
.............................................3-64
Audio Steering Wheel Controls
....................3-107
Care of Your Cassette Tape Player
...............3-108
Care of Your CD and DVD Player
................3-109
Care of Your CDs and DVDs
.......................3-109
Integrated Windshield Antenna
.....................3-110
Radio with Cassette and CD
.........................3-71
Radio with CD
............................................3-65
Radio with Six-Disc CD
................................3-82
Rear Seat Audio (RSA)
...............................3-105
1
2003 - Rendezvous OM

Erasing HomeLink®Buttons..............................2-36
Exit Lighting...................................................3-16
Exiting Programming Mode.......................2-51, 3-64
Express-Down Window....................................2-14
Extender, Safety Belt.......................................1-44
Exterior Lamps...............................................3-12
F
Fabric/Carpet.................................................5-78
Filter
Engine Air Cleaner......................................5-15
Finding a PTY Station.....................................3-68
Finding a PTY Station (RDS and XM™) .....3-74, 3-85
Finding a Station............................3-66, 3-73, 3-83
Finish Care....................................................5-81
Finish Damage...............................................5-83
Flash-to-Pass................................................... 3-8
Flat Tire........................................................5-58
Flat Tire, Changing.........................................5-59
Floor Console Fuse Block................................5-87
Fluid
Automatic Transaxle.....................................5-17
Power Steering...........................................5-31
Windshield Washer......................................5-32
FM Stereo....................................................3-108
Fog Lamps ....................................................3-14
Folding or Reclining the Seatbacks.............1-7, 1-12
Folding the Seatback.......................................1-16
Following Distance..........................................4-38Footnotes........................................................ 6-5
Four-Way Manual Driver Seat............................ 1-2
Front Armrest Storage Area..............................2-38
Front Console Storage Area.............................2-38
Front Reading Lamps......................................3-17
Fuel............................................................... 5-4
Additives...................................................... 5-6
California Fuel.............................................. 5-5
Filling a Portable Fuel Container..................... 5-8
Filling Your Tank........................................... 5-6
Fuels in Foreign Countries.............................. 5-6
Gage .........................................................3-43
Gasoline Octane........................................... 5-4
Gasoline Specifications.................................. 5-5
Low Warning Message.................................3-50
System Inspection.......................................6-13
Fuses
Fuses and Circuit Breakers...........................5-86
Windshield Wiper.........................................5-86
G
Gage
Engine Coolant Temperature.........................3-40
Fuel..........................................................3-43
Speedometer..............................................3-35
Tachometer.................................................3-36
Garage Door Opener.......................................2-34
Gasoline
Octane........................................................ 5-4
6
2003 - Rendezvous OM

Gasoline (cont.)
Specifications............................................... 5-5
Gate Operator and Canadian Programming........2-36
Glass Surfaces...............................................5-80
Glove Box.....................................................2-37
GM Mobility Program for Persons with
Disabilities.................................................... 7-5
H
Hatch Ajar Warning Message............................3-48
Hazard Warning Flashers................................... 3-5
Head Restraints............................................... 1-6
Headlamp Exit Delay.......................2-47, 3-15, 3-57
Headlamp High/Low-Beam Changer.................... 3-8
Headlamp Wiring............................................5-86
Headlamps....................................................5-43
Bulb Replacement.......................................5-42
Halogen Bulbs............................................5-43
Headphones...................................................3-94
Head-Up Display (HUD)...................................3-18
Heated Seats................................................... 1-4
Highbeam Out Warning Message......................3-53
Highway Hypnosis
...........................................4-23
Hill and Mountain Roads
..................................4-24
Hitches
..........................................................4-37
HomeLink
®Transmitter
....................................2-34
HomeLink®Transmitter, Programming
................2-34Hood
Checking Things Under.................................. 5-9
Release....................................................... 5-9
Horn ............................................................... 3-6
How the System Works...................................3-22
How to Add Coolant to the Coolant
Recovery Tank............................................5-26
How to Add Coolant to the Radiator..................5-28
How to Add Fluid............................................5-18
How to Check........................................5-17, 5-49
How to Check Power Steering Fluid..................5-32
How to Inspect the Engine Air Cleaner/Filter.......5-16
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-24
Hydroplaning..................................................4-19
I
If No Steam Is Coming From Your Engine..........5-23
If Steam Is Coming From Your Engine...............5-22
If the Light Is Flashing.....................................3-41
If the Light Is On Steady.................................3-42
If You Are Stuck in Sand, Mud, Ice or Snow.......4-30
If You Do Decide To Pull A Trailer.....................4-35
If You’re Caught in a Blizzard...........................4-28
Ignition Positions.............................................2-19
Ignition Transaxle Lock Check..........................6-12
Infants and Young Children, Restraints...............1-47
Inflation -- Tire Pressure..................................5-49
7
2003 - Rendezvous OM
