’02 HIGHLANDER_U (L/O 0108)
2722002 MY HIGHLANDER_U (OM48429U)
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
To prevent yourself from burning,
do not replace the light bulbs while
they are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogged up in the rain. However,
if there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer. Light bulbsBulb
No.WTy p e
Headlights (low)900651B
Headlights (high)900560A
Front fog lights—35C
Front turn signals/
parking and front
side marker lights
—21/5F
Rear turn signal
lights—21E
Stop/tail lights744321/5D
Rear side marker4CP5D
Back up lights744021D
License plate light4CP5D
High mounted stop
light92118D
Interior lights—8G
Personal light—10F
Vanity lights—1.5G
Door courtesy
lights—5D
Glove box light—1.2F
Replacing light bulbs—
’02 HIGHLANDER_U (L/O 0108)
2742002 MY HIGHLANDER_U (OM48429U)
3. Insert the bulb base into the mount-
ing hole by turning it clockwise.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer. If either the left or right front fog, front
turn signal/parking or rear side marker
lights burns out, contact your Toyota
dealer.
NOTICE
Do not try to replace any of the light
bulbs mentioned above by yourself.
You may damage the vehicle.
—Front fog, front turn signal/
parking and rear side marker
lights
—Rear turn signal, stop/tail
and back up lights
