2002 TOYOTA CAMRY fuse

AP_Camry_U (L/O 0201)
2662002 MY CAMRY_U (OM33567U)
If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
If any washer does not work or low
windshield washer fluid level warning
light comes on, the washer tank may be
empty. Add washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
To prevent yourself from burning,
do not replace the light bulbs while
they are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
Adding washer fluidReplacing light bulbs—

AP_Camry_U (L/O 0201)
2732002 MY CAMRY_U (OM33567U)
SPECIFICATIONS
Dimensions and weight274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Engine 274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 275
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 275
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 278
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 278
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

AP_Camry_U (L/O 0201)
2782002 MY CAMRY_U (OM33567U)
Engine compartment
Tires
Tire size
P205/65R15 92T Front
P205/65R15 92H
P215/60R16 94V 200 (2.0, 29)
200 (2.0, 29)
200 (2.0, 29) Rear
200 (2.0, 29)
200 (2.0, 29)
200 (2.0, 29) Wheel size
15 61/2 JJ
15 61/2 JJ
16 61/2 JJ
When driving under the above vehicle conditions at sustained high speeds above 160
km/h (100 mph), in countries where such speeds are permitted by −law, inflate the
front and rear tires to 240 kPa (2.4 kgf/cm
2 or bar, 35 psi) provided that it does
not exceed the maximum cold tire pressure molded on the tire sidewall.
Compact spare tire kPa (kgf/cm
2 or bar, psi) Wheel size
T145/80R16 105M 450 (45, 65) 16  4T
Trailer driving kPa (kgf/cm
2 or bar, psi)
Tire size
P205/65R15 92T
P205/65R15 92H P215/60R16 94V Front Rear
220 (2.2, 32)
220 (2.2, 32)
200 (2.0, 29) 220 (2.2, 32)
220 (2.2, 32)
200 (2.0, 29)
Wheel nut torque, N·m (kgf·m, ft·lbf): 104 (10.5, 77)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire pressure” through “Aluminum wheel precautions”, pages
255 through 260, in Section 7 −2.
Tire size and pressure:
Normal driving kPa (kgf/cm
2 or bar, psi)
Fuses

AP_Camry_U (L/O 0201)
2792002 MY CAMRY_U (OM33567U)
Engine compartment
(with vehicle skid control system)
Fuses (type A)1. HEAD LH LWR 15 A: Left−hand head-
light (low beam)
2. HEAD RH LWR 15 A: Right−hand
headlight (low beam)
3. DRL 5 A: Daytime running light system
4. A/C 10 A: Air conditioning system
5. SPARE 10 A: Spare fuse
6. SPARE 15 A: Spare fuse
7. SPARE 5 A: Spare fuse
8. AM2 30 A: Starting system, “IGN” and
“IG2” fuses
Instrument panel
9. HEAD LH UPR 10 A: Left−hand head-
light (high beam)
10. HEAD RH UPR 10 A: Right−hand
headlight (high beam)
11. ST 5 A: Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
12. TEL 5 A: No circuit
13. ALTS 5 A: Charging system
14. IGN 15 A: Starting system 15. IG2 10 A:
Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, SRS airbag system, front seat
belt pretensioners, cruise control sys-
tem
16. DOOR1 25 A: Multiplex communication
system (power door lock system, auto −
door locking system, wireless remote
control system)
17. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
18. HORN 10 A: Horns
19. D.C.C 30 A: “ECU−B”, “RAD NO.1”
and “DOME” fuses
20. A/F 25 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
21. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
22. HAZ 15 A: Emergency flashers
23. ABS NO.4 7.5 A: Anti−lock brake sys-
tem, vehicle skid control system, trac-
tion control system, brake assist sys-
tem

AP_Camry_U (L/O 0201)
2802002 MY CAMRY_U (OM33567U)
24. ECUB 10 A: Multiplex communication
system (power door lock system, secu-
rity system, auto −door locking system,
automatic light control system, head-
light delay off system, tail light auto
cut system, illuminated entry system,
daytime running light system, wireless
remote control system), air conditioning
system
25. DOME 7.5 A: Ignition switch light, inte-
rior light, personal lights, trunk light,
vanity lights, garage door opener,
clock, outside temperature gauge, mul-
ti −information display
26. CIG 15 A: Cigarette lighter
27. ECUACC 5 A: Power rear view mir-
rors, clock, multi −information display
28. RAD NO.2 10 A: Car audio system,
navigation system
29. POWER POINT 15 A: Power outlets
30. RAD NO.1 20 A: Car audio system,
navigation system
31. GAUGE1 10 A: Gauges and meters,
clock, outside temperature gauge, mul-
ti −information display, shift lock system,
seat belt reminder lights
32. ECUIG 10 A: SRS airbag system,
power windows, anti −lock brake system
33. WIPER 25 A: Windshield wipers 34. HTR 10 A:
Air conditioning systems
35. MIR HTR 10 A: Outside rear view mir-
ror heaters
36. AM1 5 A: Starting system
37. FOG 15 A: Front fog lights
38. SUNSHADE 15 A: No circuit
39. GAUGE2 10 A: Auto anti−glare inside
rear view mirror, compass, electric
moon roof, back −up lights, automatic
transmission indicator lights, automatic
light control system, cruise control sys-
tem
40. PANEL 10 A: Glove box light, clock,
outside temperature gauge, multi −infor-
mation display, instrument cluster
lights, instrument panel lights, over-
drive− off indicator light
41. TAIL 10 A: Tail lights, parking lights,
license plate lights
42. PWR NO.4 20 A: Rear passenger ’s
power window (left side)
43. PWR NO.2 20 A: Front passenger ’s
door lock system, front passenger ’s
power window
44. OBD 7.5 A: On−board diagnosis sys-
tem
45. SEAT HTR 20 A: Seat heaters
46. WASHER 15 A: Windshield washer 47. FAN RLY 10 A:
Electric cooling fans
48. STOP 15 A: Stop lights, high mounted
stoplight, anti −lo
ck brake system,
cruise control system
49. FUEL OPEN 5 A: No circuit
50. DOOR NO.2 25 A: Multiplex commu-
nication system (power door lock sys-
tem, auto −door locking system, wire-
less remote control system)
51. AMP 25 A: No circuit
52. PWR NO.3 20 A: Rear passenger’s
power window (right side)
Fuses (type B)
53. MAIN 40 A: “HEAD LH LWR”, “HEAD
RH LWR”, “HEAD LH UPR”, “HEAD LH
UPR” and “DRL” fuses
54. ABS NO.2 40 A: Anti−lock brake sys-
tem, vehicle skid control system, trac-
tion control system, brake assist sys-
tem
55. RDI 30 A: Electric cooling fan
56. CDS 30 A: Electric cooling fan
57. HTR 50 A: Air conditioning system
58. ADJ PDL 30 A: Power adjustable ped-
als

AP_Camry_U (L/O 0201)
2812002 MY CAMRY_U (OM33567U)
59. ABS NO.3 40 A: Anti−lock brake sys-
tem, vehicle skid control system, trac-
tion control system, brake assist sys-
tem
60. PWR SEAT 30 A: Power seats
61. PWR NO.1 30 A: Driver ’s door lock
system, driver’s power wi ndow, electric
moon roof
62. DEF 40 A: Rear window defogger
Fuses (type C)
63. ALT 100 A (with 2AZFE engine) or ALT 120 A (with 1MZFE engine):
“DEF”, “PWR NO.1”, “PWR NO.2”,
“PWR NO.3”, “PWR NO.4”, “STOP”,
“DOOR NO.2”, “OBD”, “PWR SEAT”,
“FUEL OPEN”, “FOG”, “AMP”, “PANEL”,
“TAIL”, “AM1”, “CIG”, “POWER POINT”,
“RAD NO.2”, “ECU −ACC”, “GAUGE1”,
“GAUGE2”, “ECU −IG”, “WIPER”,
“WASHER”, “HTR (10 A)”, “SEAT HTR”,
and “SUN −SHADE” fuses
64. ABS NO.1 60 A: Anti−lock brake sys-
tem, vehicle skid control system, trac-
tion control system, brake assist sys-
tem
