2002 SUBARU IMPREZA WRX warning

Seat, seatbelt and SRS airbags
1-52
HS0351
WARNING
Never allow a child to kneel on the front pas-
senger’s seat facing the side window or to
wrap his/her arms around the front seatback.In the event of an accident, the force of theSRS side airbag deployment could injure thechild seriously because his/her head or armsor other body parts are too close to the SRSside airbag. Since your vehicle is also equipped with a passenger ’s SRS frontal air-
bag, children aged 12 and under should be
placed in the rear seat anyway and should beproperly restrained at all times.
HB0354
HB0355

Seat, seatbelt and SRS airbags
1-53
– CONTINUED –
WARNING
Do not attach accessories to the door trim or near either SRS side airbags and do not placeobjects near the SRS side airbags. In the
event of the SRS side airbag deployment, they could be propelled dangerously toward the
vehicle’s occupants and cause injuries.
HS0353
WARNING
Do not put any kind of cover or clothes or oth- er objects over either front seatback and donot attach labels or stickers to the front seat
surface on or near the SRS side airbag. They could prevent proper deployment of the SRS side airbag, reducing protection available tothe front seat ’s occupant.
HS0347
The SRS side airbag is stored in the door side of
each front seatback, which bears an “SRS AIRBAG ”
label.
In a moderate to severe side impact collision, the SRS side airbag on the impacted side of the vehicle

Seat, seatbelt and SRS airbags
1-59
– CONTINUED –
SRS airbag system monitors
A diagnostic system continually monitors the readi- ness of the SRS airbag system while the vehicle is
being driven. The SRS airbag system warning light
“AIRBAG” will show normal system operation by
lighting for about 6 seconds when the ignition key is
turned to the “ON” position.
HG1016BA
The following components are monitored by the indi- cator:Front sub sensor (Right hand side)
Front sub sensor (Left hand side)
Airbag control module (including impact sensors)
Frontal airbag module (Driver ’s side)
Frontal airbag module (Passenger ’s side)
Side airbag sensor (Driver ’s side — if equipped)
Side airbag sensor (Passenger ’s side — if
equipped) Side airbag module (Driver ’s side — if equipped)
Side airbag module (Passenger ’s side — if
equipped) Seatbelt pretensioner (Driver ’s side)
Seatbelt pretensioner (Passenger ’s side)
All related wiring
In the event of a malfunction indicated by any of fol-
lowing, the vehicle should be taken promptly to your
nearest SUBARU dealer to have the system
checked. Unless checked and repaired, the SRS
airbags will not function reliably: Flashing or flickering of the indicator light.
No illumination of the warning light when the igni-
tion switch is first turned to the “ON” position.
Continuous illumination of the warning light.
Illumination of the warning light while driving.

Seat, seatbelt and SRS airbags
1-60
SRS airbag system servicing
WARNING
When discarding an airbag module or scrap-
ping the entire car damaged by a collision,
consult your SUBARU dealer. The SRS airbag has no user-serviceable
parts. Do not use electrical test equipment on any circuit related to the SRS airbag system.For required servicing of the SRS airbag, see
your nearest SUBARU dealer. Tampering withor disconnecting the system ’s wiring could re-
sult in accidental inflation of the SRS airbag
or could make the system inoperative, which
may result in serious injury. The wiring har-
nesses of the SRS airbag system are coveredwith yellow insulation and system connectorsare yellow for easy identification.
CAUTION
If you need service or repair in areas listed be-
low, we recommend that you have an autho-
rized SUBARU dealer perform the work. The
SRS airbag control module, impact sensors
and airbag modules are stored in these areas. Under the center console
Inside each front fender
Steering wheel and column and nearby
areas Top of the dashboard on front passenger ’s
side and nearby areas Each front seat and nearby area (only for ve-
hicle with SRS side airbags) Inside each center pillar
In the event that the SRS airbag is deployed, re-
placement of the system should be performed
only by an authorized SUBARU dealer. When the
components of the SRS airbag system are re-
placed, use only genuine SUBARU parts.
To ensure their long-term reliability, the SRS airbags must be inspected by a SUBARU dealer ten years
after the date of manufacture, which is shown on the
certification plate attached to the driver ’s door jamb.

Seat, seatbelt and SRS airbags
1-61
– CONTINUED –
NOTE In the following cases, contact your SUBARU dealer as soon as possible.The front part of the vehicle was involved in an
accident in which the SRS frontal airbags did not
deploy. The pad section of the steering wheel or front
passenger’ s frontal airbag cover is scratched,
cracked, or otherwise damaged. In addition, if your vehicle is equipped with SRS side airbags, contact your SUBARU dealer assoon as possible in the following cases. Either center pillar or a nearby area of the ve-
hicle was involved in an accident in which the
SRS side airbag did not deploy. The fabric or leather of either front seatback is
cut, frayed, or otherwise damaged.
Precautions against vehicle modifica- tion
WARNING
To avoid accidental activation of the system
or rendering the system inoperative, which
may result in serious injury, no modifications should be made to any components or wiring of the SRS airbag system.This includes following modifications: Installation of custom steering wheels
Attachment of additional trim materials to
the dashboard Installation of custom seats (for vehicles
with SRS side airbags only) Replacement of seat fabric or leather (for
vehicles with SRS side airbags only) Installation of additional fabric or leather
on the front seat (for vehicles with SRS side airbags only)
Installation of additional electrical/electronic
equipment such as a mobile two-way radio on or near the SRS airbag system componentsand/or wiring is not advisable. This could in-
terfere with proper operation of the SRS air- bag system.

Keys and doors
2-4
NOTE
Make sure that you do not leave the key inside the vehicle when locking the doors from the out-
side without the key. Locking and unlocking from the inside
HB2001BC
1) Lock 2) Unlock
To lock the door from the inside, rotate the lock lever
rearward. To unlock the door from the inside, rotate
the lock lever forward.
The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked
door.
Always make sure that all doors and the rear gate
(wagon) are closed before starting to drive.
WARNING
Keep all doors locked when you drive, espe-
cially when small children are in your vehicle.Along with the proper use of seat belts and child restraints, locking the doors reduces the
chance of being thrown out of the vehicle inan accident.It also helps prevent passengers from fallingout if a door is accidentally opened, and in-
truders from unexpectedly opening doors and entering your vehicle.

Keys and doors
2-13
– CONTINUED –
breaking glass or forced entry). Note that there are
two alarm levels for shock: warning and alarm. In
warning mode, the alarm detects lower level vibra-
tions and triggers 2 warning chirps on the horn and
two flashes on the lights as a deterrent to would be
vandals. In alarm mode, higher levels of shock are
detected and the system will go into full alarm. Ignition switch being turned on while in armed
state. Arming the system
To arm the system using remote transmitter
1. Close all windows.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk
lid) are locked.
5. Close all doors (and the rear gate on the wagon).
HB1000EC
1) Press to Arm the system.
2) Press to Disarm the system.
HG2017BA
Security system indicator light

Keys and doors
2-17
– CONTINUED –
WARNING
Do not disconnect or tamper with any yellow connector and/or any harness covered withyellow insulation and/or tape.Doing so could result in accidental inflation of the SRS airbag or could make the SRS airbag
system inoperative, which may result in seri-
ous injury.
Arming the system
1. Turn the ignition switch to the “ON” position.
HB2031BC
1) ON 2) LOCK 2. Turn the ignition switch from
“ON” to “LOCK”
position and remove the key from the ignition switch.
HB2024DB
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with theinside door lock levers.
5. Close the doors. The system will automatically
arm after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming
will take place immediately regardless of whether ornot the passive mode has been selected.
