In case of emergency
9-3
– CONTINUED –
Temporary spare tire (if equipped)
WARNING
Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not
designed to sustain the towing load. Use ofthe temporary spare tire when towing canresult in failure of the spare tire and/or less
stability of the vehicle and may lead to an accident.
The temporary spare tire is smaller and lighter than
a conventional tire and is designed for emergency
use only. Remove the temporary spare tire and re-
install the conventional tire as soon as possible be-
cause the spare tire is designed only for temporary use.
Check the inflation pressure of the temporary spare
tire periodically to keep the tire ready for use. The
correct pressure is 60 psi (4.2 kg/cm2
, 420 kPa) .
When using the temporary spare tire, note the fol-lowing:
Do not exceed 50 mph (80 km/h).
Do not put a tire chain on the temporary spare tire.
Because of the smaller tire size, a tire chain will not
fit properly. Do not use two or more temporary spare tires at
the same time. Do not drive over obstacles. This tire has a smaller
diameter, so road clearance is reduced.
HG0106
1) Tread wear indicator bar
2) Indicator location mark
When the wear indicator appears on the tread, re-
place the tire.

In case of emergency
9-15
– CONTINUED –
Confirm that the cooling fan is turning. If the fan is
not turning, immediately turn the engine off and con-
tact your authorized dealer for repair.
3. After the engine coolant temperature has
dropped, turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.If the coolant level is below the “MIN” mark, add
coolant up to the “MAX” mark.
5. If there is no coolant in the reserve tank, add
coolant to the reserve tank. Then remove the radia- tor cap and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator,
first wrap a thick cloth around the radiator cap, then
turn the cap counterclockwise slowly without press-
ing down until it stops. Release the pressure from
the radiator. After the pressure has been fully re-
leased, remove the cap by pressing down and turn-ing it. Towing
If towing is necessary, it is best done by your
SUBARU dealer or a commercial towing service.
Observe the following procedures for safety.
HG9000BA
WARNING
Never tow AWD vehicles (both AT and MT) with the front wheels raised off the groundwhile the rear wheels are on the ground, orwith the rear wheels raised off the ground while the front wheels are on the ground. This will cause the vehicle to spin away due to the

In case of emergency
9-16
operation or deterioration of the center differ- ential.
Towing and tie-down eyes
The towing eyes should be used only in an emer-
gency (e.g., to free a stuck vehicle from mud, sand or snow). Front towing eye:
HG9006BA

In case of emergency
9-17
– CONTINUED –
1. Take out the towing eye, screwdriver and wheel
nut wrench from the on board tool bag.
2. Pry off the cover on the front bumper using a
screwdriver, and you will find a threaded hole for at-
taching the towing eye.
3. Screw the towing eye into the threaded hole until
its thread can no longer be seen.
4. Tighten the towing eye securely with a wheel nut
wrench.
After towing, remove the towing eye from the vehicle
and stow it in the tool bag. Put the threaded hole
cover on the front bumper.
WARNING
Do not use the towing eye except when tow-
ing your vehicle. Be sure to remove the towing eye after tow-
ing. Leaving the towing eye mounted on the
vehicle could interfere with proper operationof the SRS airbag system in a frontal collision. Rear towing eye:
HG9004CA
CAUTION
Do not apply excessive lateral load to the tow- ing eyes.

In case of emergency
9-18
Tie-down eyes:
HG9011BB
1) Tie-down eye
2) Towing and tie-down eye
CAUTION
Never use the tie-down eye on the underside of the vehicle closest to the muffler for towing purposes.
Using a flat-bed truck
HG9002AA
This is the best way to transport your vehicle. Use
the following procedures to ensure safe transporta-tion.
1. Shift the selector lever into the “P” position for au-
tomatic transmission vehicles or “1st” for manual
transmission vehicles.
2. Pull up the parking brake lever firmly.

In case of emergency
9-19
– CONTINUED –
3. Secure the vehicle onto the carrier properly with safety chains. Each of safety chain should be
equally tightened and care must be taken not to pull
the chains so tightly that the suspension bottomsout.
CAUTION
If your vehicle has a front underspoiler and rear underspoiler (both optional), be carefulnot to scrape them when placing the vehicleon the carrier and when removing the vehicle
from the carrier.
Towing with all wheels on the ground
HG9001AA
1. Check the transmission and differential oil levels
and add oil to bring it to the upper level if necessary.
2. Release the parking brake and put the transmis-sion in neutral.
3. The ignition switch should be in the “ACC” posi-
tion while the vehicle is being towed.
4. Take up slack in the towline slowly to prevent
damage to the vehicle.
WARNING
Never turn the ignition switch to the “LOCK”
position while the vehicle is being towed be-
cause the steering wheel and the direction ofthe wheels will be locked. Remember that the brake booster and pow-
er steering do not function when the engine is not running. Because the engine is turned off,
it will take greater effort to operate the brakepedal and steering wheel.

In case of emergency
9-20
CAUTION
If transmission failure occurs, transport
your vehicle on a flat-bed truck. Do not run the engine while being towed in
this method. Transmission damage could re- sult if the vehicle is towed with engine run-ning. For vehicles with automatic transmission,
the traveling speed must be limited to less than 20 mph (30 km/h) and the traveling dis- tance to less than 31 miles (50 km). Forgreater speeds and distances, transport your
vehicle on a flat-bed truck. Maintenance tools
HG9010AA
Your vehicle is equipped with the following mainte-
nance tools:
Wheel cover remover (vehicles with wheel covers)
Screwdriver
Towing eye
Wheel nut wrench

Maintenance and service
11-6
HGB000BA
2. Release the secondary hood release located
under the front grille by moving the lever toward theleft.
HBB003BA
Lift up the hood, release the hood prop from its
retainer and put the end of the hood prop into theslot in the hood.
To close the hood:
1. Lift the hood slightly and remove the hood prop
from the slot in the hood and return the prop to its
retainer.
2. Lower the hood until it approaches about 6 in.
(15 cm) from the closed position and let it drop.
3. After closing the hood, be sure the hood is
securely locked.
If this does not close the hood, release it from a
slightly higher position. Do not push the hood forci-
bly to close it. It could deform the metal.
WARNING
Always check that the hood is properly locked before you start driving. If it is not, it might flyopen while the vehicle is moving and block
your view, which may cause an accident and
serious bodily injury.
