Driving tips
8-8
Off road driving
WARNING
Always maintain a safe driving speed ac-
cording to the road and weather conditions in order to avoid having an accident on a sharpturn, during sudden braking or under othersimilar conditions. Always use the utmost care in driving –
overconfidence because you are driving an allwheel drive vehicle could easily lead to a seri-ous accident.
All AWD models except OUTBACK SPORT
Your AWD vehicle is neither a conventional off-road
vehicle nor an all terrain vehicle. It is a passenger
car designed primarily for on-road use. The AWD
feature gives it some limited off-road capabilities in
situation in which driving surfaces a relatively level,
obstruction-free and otherwise similar to on-road driving conditions. Operating it under other than those conditions could subject the vehicle to exces-
sive stress which might result in damage not eligible for repair under warranty. If you do take your
SUBARU off road, you should review the common
sense precautions in the next section (applicable to
the OUTBACK SPORT) for general guidance. Butplease keep in mind that your vehicle
’s off-road ca-
pabilities are more limited than those of the OUT-
BACK SPORT.
Never attempt to drive through pools and puddles,
or roads flooded with water. Water entering the
engine air intake or the exhaust pipe or water
splashing onto electrical parts may damage your
vehicle and may cause it to stall. OUTBACK SPORT
Because of the AWD feature and higher ground
clearance, your Subaru can be driven on ordinary
roads or off-road. But please keep in mind that an
AWD SUBARU is a passenger car and is neither a
conventional off-road vehicle nor an all-terrain ve-
hicle. If you do take your Subaru off-road, certain
common sense precautions such as the following should be taken: Make certain that you and all of your passengers
are wearing seat belts. Carry some emergency equipment, such as a
towing rope or chain, a shovel, wheel blocks, first

Driving tips
8-21
– CONTINUED –
F) Front of vehicle
1) T30 torx head screw
2) Front arrow label
3) Front crossbar
4) 100LBS load label
5) Lower clamp
6) Roof rail end support
7) Joint line
8) 3 inches (76 mm)
9) Front arrow label
1. Before placing the crossbar on the roof rails,
make sure that the T-30 torx head screw is
removed from the top of each crossbar end support.
2. Rotate the lower clamp on the bottom of each
end support downward approximately 90 °.
3. With the front direction arrow label on the top
right side of the crossbar pointing toward the front of
the vehicle, carefully place the crossbar across the
top of the vehicle so that the crossbar end supports
rest on the top of the roof rails approximately 3
inches (76 mm) rearward from the seam (joint)
between the front roof rail support and the roof rail.
4. Rotate (raise) the lower clamp up to the bottom of
the roof rail and loosely tighten the T-30 torx head
screw with the torx wrench provided, through the
top of the end support and into the threaded insert
in the lower clamp on each end of the crossbar. NOTE It may be necessary to squeeze the lower clamp and the end support together to compress thepads and gain a better alignment of the pieces
while trying to start the screw. Use care not tocrossthread the screw in the insert.
5. Adjust the alignment of the crossbar on the roof
rails, and if available, use a T-30 torx
bit and
torque wrench and tighten the T-30 torx head
screws to 30 to 35 inch lbs. (3.4 to 4.0 N-m, 0.35 to
0.41 kg-m) of torque (or tighten securely with thetorx wrench provided).

Driving tips
8-23
– CONTINUED –
checked, and retightened if necessary to 35 inch
lbs. (4.0 N-m, 0.41 kg-m), as outlined in Step #5above. Trailer hitch (if equipped) The trailer hitch is designed to tow a Class 1 rated
load. A maximum of
2,000 lbs. (906 kg) gross trailer
weight and a maximum of 200 lbs. (90 kg) gross
tongue weight are permissible for the trailer hitch.
When you tow a trailer, follow the instructions in the next section “Trailer towing ”.
WARNING
Never exceed the maximum weight specified
for the trailer hitch. Exceeding the maximum weight could cause an accident resulting inserious personal injuries. Permissible trailerweight changes depending on the situation.Refer to the next section “Trailer towing ” for
possible recommendations and limitations. Trailer brakes are required when the towing
load exceeds 1,000 lbs. (453 kg). Be sure yourtrailer has safety chains and that each chainwill hold the trailer ’s maximum gross weight.
Towing trailers without safety chains could create a traffic safety hazard if the trailer sepa- rates from the hitch due to coupling damageor hitch ball damage. Be sure to check the hitch pin and safety pin

Driving tips
8-24
for positive locking placement before towing a
trailer. If the ball mount comes off the hitch re-
ceiver, the trailer could get loose and create atraffic safety hazard.Use only the ball mount supplied with this
hitch. Use the hitch only as a weight carrying
hitch. Do not use with any type of weight dis- tributing hitch.
Connecting a trailer
1. Remove the receiver cover from the hitch receiv-
er tube. Then insert the ball mount into the hitch re- ceiver tube.
2. Insert the hitch pin into the hole on the hitch re-
ceiver tube so that the pin passes through the ballmount.
HB8018BA
3. Insert the safety pin into the hitch pin securely.
HB8019BA

Driving tips
8-26
HB8022BA
8. Connect the hitch wire harness’s black four –pin
wire connector to the towing trailer ’s wire harness
HB8021BA
Hitch harness connector 9. Confirm proper function of the hitch wire harness
by individually activating the brake, right turn signal,
left turn signal, stop, and parking lights on the trailer. NOTE Always disconnect the trailer wire harness be- fore launching or retrieving a watercraft.
When you do not tow a trailer
Remove the ball mount from the hitch receiver
tube and insert the receiver cover onto the hitch re- ceiver tube. Place the dust cap over the four –pin connector of
the hitch wire harness to protect against possibledamage. Occasionally lubricate terminals of the four –pin
connector using the terminal grease.

Driving tips
8-27
– CONTINUED –
Trailer towing
Your car is designed and intended to be used pri-
marily as a passenger-carrying vehicle. Towing a
trailer puts additional loads on your car ’s engine, dri-
vetrain, brakes, tires and suspension and has an
adverse effect on fuel economy.
If you do decide to tow a trailer, your safety and sat-
isfaction depend upon proper use of correct equip-
ment and cautious operation of your vehicle. Seekthe advice of your SUBARU dealer to assist you in
purchasing a hitch and other necessary towing
equipment appropriate for your vehicle. In addition,
be sure to follow the instructions on correct installa-
tion and use provided by the trailer and other towing
equipment manufacturers.
SUBARU assumes no responsibility for injuries or
vehicle damage that result from trailer towing equip-
ment, or from any errors or omissions in the instruc- tions accompanying such equipment or for your fail-
ure to follow the proper instructions. Warranties and maintenance
SUBARU warranties do not apply to vehicle damage or malfunction caused by trailer towing. If you use
your vehicle to tow a trailer, more frequent mainte-
nance will be required due to the additional load. (Refer to
“Maintenance schedule under severe driv-
ing conditions ” in the “Warranty and Maintenance
Booklet”.)
Under no circumstances should a trailer be towedwith a new vehicle or a vehicle with any new power-
train component (engine, transmission, differential, wheel bearings, etc.) for the first 1,000 miles (1,600 km) of driving. Maximum load limits
WARNING
Never exceed the maximum load limits ex-
plained below. Exceeding the maximum loadlimits could cause personal injury and/or ve-hicle damage.
CAUTION
Adequate size trailer brakes are required
when the trailer and its cargo exceed 1,000 lbs (453 kg) total weight. Before towing a trailer, check the trailer total
weight, GVW, GAWs and tongue load. Make sure the load and its distribution in your
vehicle and trailer are acceptable.

Driving tips
8-28
Total trailer weight
The total trailer weight (trailer weight plus its cargo load) must never exceed the maximum weight
shown below.
Model
ConditionsMaximum
total trailer
weight
MT modelsWhen towing a trailer with- out brakes.1,000 lbs(453 kg)
When towing a trailer with brakes.2,000 lbs
(906 kg)
AT modelsWhen towing a trailer with- out brakes.1,000 lbs (453 kg)
When towing a trailer with brakes.2,000 lbs
(906 kg)
When towing a trailer on a long uphill grade continu- ously for over 5 miles (8km) with an outside tem-perature of 104 °F (40 °C) or
above.1,000 lbs (453 kg)
OM-H2781
Total trailer weight
Gross Vehicle Weight (GVW) and Gross
Vehicle Weight Rating (GVWR)
The Gross Vehicle Weight (GVW) must never
exceed the Gross Vehicle Weight Rating (GVWR).
Gross Vehicle Weight (GVW) is the combined total of
the weight of the vehicle, driver, passengers, lug-gage, trailer hitch, trailer tongue load and any other
optional equipment installed on your vehicle. There-
fore, the GVW changes depending on the situation.
Determine the GVW each time before going on a trip by putting your vehicle and trailer on a vehiclescale.
GVWR is shown on the certification label located onthe driver ’s door of your vehicle.

Driving tips
8-30
HGS028CA
Certification label
To check both GVWR and GAWR and to confirm that
the total weight and weight distribution are within safe driving limits, you should have your vehicle and
trailer weighed at a commercial weighing station.
Be sure that all cargo is firmly secured to prevent a
change in weight distribution while driving. Tongue load
Ensure that the trailer tongue load is from 8 to 11
percent of the total trailer weight and does not exceed the maximum value of 200 lbs (90 kg).
The tongue load can be weighed with a bathroom
scale as shown in the illustration below. When
weighing the tongue load, be sure to position the towing coupler at the height at which it would beduring actual towing, using a jack as shown.OM-H2785
Tongue load
