2002 SUBARU IMPREZA WRX clock

Maintenance and service
11-61
– CONTINUED –
Front fog light (if equipped)
CAUTION
Halogen fog light bulbs become very hot while
in use. If you touch the bulb surface with barehands or greasy gloves, finger prints orgrease on the bulb surface develop into hotspots, causing the bulb to break. If there are finger prints or grease on the bulb surface,
wipe them away with soft cloth moistenedwith alcohol.
HGB016BA
1. Remove the front fog light assembly by removing
the three bolts. 2. Disconnect the connector.
HGA002BA
3. Remove the front fog light case cap by turning it
counterclockwise.

Maintenance and service
11-62
OM-H0412
1) Spring
2) Connector
4. Disconnect the connector behind the case cap.
5. Release the retainer spring.
6. Replace the bulb with a new one. Then reconnect
the connectors and reinstall the removed parts in
the reverse order of removal.
Front side marker lightHGB020BA
1. Remove the front side marker light assembly by
prying the edge of the lens with a regular screwdriv-
er. At this time, use a cloth to protect the body from
being damaged by the screwdriver.
2. Remove the bulb holder from the front side mark-
er light assembly by turning it counterclockwise.
3. Pull the bulb out of the socket. Install a new bulb.
4. Set the bulb holder into the front side marker light
assembly and turn it clockwise until it locks.
5. Reinstall the front side marker light assembly
onto the side of the front fender.

Maintenance and service
11-63
– CONTINUED –
Rear combination lights
Sedan
HGB011BA
1. Remove the clip from the rear trunk trim with a
regular screwdriver.
HGB012BB
1) Backup light
2) Rear turn
signal light 3) Brake light
4) Tail light
5) Brake/tail light
2. Open the rear portion of the side trunk trim panel.
3. Remove the bulb holder from the rear combina-
tion light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it
and turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Secure the rear trunk trim panel with the clips.

Maintenance and service
11-65
– CONTINUED –
HGB015CB
1) Tail/stop light
2) Rear turn signal light
3) Backup light
4) Rear side marker light
3. Remove the bulb holder from the rear combina-
tion light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it
and turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Close the cover and latch the lock.
7. Reinstall the rear combination light assembly and
its side cover.
License plate light
HGF012FA
1. Remove the mounting screws using a phillips
screwdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.

Maintenance and service
11-68
Wagon
HBB028BA
1. Remove the mounting screw covers by prying
the edge with a screwdriver.
2. Remove the mounting screws using a phillips
screwdriver and then remove the high mount stop
light cover.
3. Remove the bulbs from the socket by pushing it
and turning counterclockwise. Install a new bulb.
4. Reinstall the cover.
5. Tighten the mounting screws then reinstall the covers. NOTE
Other bulbs may be difficult to replace. Have your
SUBARU dealer replace these bulbs if necessary.

Specifications
12-8
Fuse panel located in the engine compartment
HGC002BB
A) FWD socket (except Turbo model)
B) Main fuse Fuse panel
Fuse ratingCircuit
120A
Radiator cooling fan (Main)
220ARadiator cooling fan (Sub)
330AABS motor
420ARear window defog- ger
515AHazard warning flasher
Horn
615ATurn signal lights
710AAutomatic transmis- sion control unit
810AAlternator
915AHeadlight (right side)
1015AHeadlight (left side)
1120ALighting switch
1215AClock
Interior light

Index
14-3
CHECK ENGINE warning light/ Malfunction indicator lamp 3-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking air conditioning system before summer season 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-33 . . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-34 . .
Checking the clutch function 11-34 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-35 . . . . . . . . . . . .
Checking the fluid level 11-24, 11-29, . . . . . . . . . . . . . . . . . . .
11-30, 11-31
Checking the gear oil level 11-27 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-9, 11-23, 11-26 . . . . . . . . . . . . . .
Child restraint systems 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child safety locks 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter (if equipped) 6-9 . . . . . . . . . . . . . . . . . . . .
Cigarette lighter socket (if equipped) 6-9 . . . . . . . . . . .
Cleaning aluminum wheels 10-3 . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the interior 10-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning ventilator grille 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Climate control system 4-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 3-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch pedal (MT vehicles) 11-34 . . . . . . . . . . . . . . . . . . . . . . . .
Compact disc player operation 5-8 . . . . . . . . . . . . . . . . . . .
Connecting a trailer 8-24, 8-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control panel 4-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cooling and dehumidifying in high humidity and
low temperature weather condition 4-11 . . . . . . . . . .
Cooling system 11-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Corrosion protection 8-13, 10-4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise control (if equipped) 7-27 . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D
Daytime running light system 3-17 . . . . . . . . . . . . . . . . . . . . .
Dimensions 12-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming the system 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disc brake pad wear warning indicators 7-22 . . . . . . .
Dome light 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door locks 2-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door open warning lights 3-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving in foreign countries 8-6 . . . . . . . . . . . . . . . . . . . . . . . .
Driving on snowy and icy roads 8-12 . . . . . . . . . . . . . . . . . .
Driving tips 7-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving tips for AWD vehicles 8-6 . . . . . . . . . . . . . . . . . . . . .
E
Efficient cooling after parking in direct sunlight 4-10 Electrical power socket located on the lower part of the instrument panel 6-8 . . . . . . . . . . . . . . . . . . .
Electrical system 12-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Locking Retractor (ELR) 1-12 . . . . . . . . . . . .
