2002 SUBARU IMPREZA WRX clock

Climate control
4-6
2. Set the air flow control dial to the “” position.
3. Turn the temperature control dial all the way to the right.
4. Set the fan speed control dial to the highestspeed.
If your vehicle is equipped with an air conditioner, when the “
” position is selected, the air condi-
tioner automatically operates regardless of the posi-
tion of the air conditioner button. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out- lets, turn the corresponding knob clockwise.
Heating and defrosting
HG4024AA
To direct warm air toward the floor and the wind- shield:
1. Set the air inlet selection lever to the “
”
position.
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the most com-
fortable level.
4. Set the fan speed control dial to the desiredspeed. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out- lets, turn the corresponding knob clockwise.
Heating
HG4025AA

Climate control
4-7
– CONTINUED –
To direct warm air toward the floor:
1. Set the air inlet selection lever to the “”
position
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the most com-
fortable level.
4. Set the fan speed control dial to the desired speed. NOTE
Warm air also comes out from the right and left
air outlets. To stop warm air flow from these out-lets, turn the corresponding knob clockwise.
Bi-level heating
HG4026AA
This setting allows you to direct air of different tem-
peratures from the instrument panel and foot outlets.
The air from the foot outlets is slightly warmer than
from the instrument panel outlets.
1. Set the air inlet selection lever to the “
”
position.
2. Set the air flow control dial to the “
” position.
3. Set the temperature control dial to the desired
temperature level.
4. Set the fan speed control dial to the desiredspeed.
Setting the temperature control dial fully turned to
the red area or blue area decreases the temperature
difference between the air from the instrument panel
outlets and the air from the foot outlets.

Audio
5-6
DisplayControl mode
HB5036BA
Turn counterclockwiseTurn clockwise
BASBass controlFor less bassFor more bass
TRETreble controlFor less trebleFor more treble
BALBalance con- trolTo increase left speaker volume and decreaseright speaker volumeTo increase right speaker volume anddecrease left speaker volume
FA DFader controlTo increase rear speaker volume and decrease
front speaker volumeTo increase front speaker volume anddecrease rear speaker volume
VOLVolume con- trolFor less volumeFor more volume
FM/AM selection button (FM/AM)
Push the “FM/AM” button (4) when the radio is off to
turn on the radio. Push the
“FM/AM” button when the radio is on to
select FM1, FM2 or AM reception. Each time this
button is pressed, the band will change in the fol-
lowing order:

Audio
5-15
– CONTINUED –
Power switch and volume/bass/treble/fader/ balance control (PWR/VOL)
The dial (7) is used for both power (ON/OFF) and
volume control. The radio is turned ON and OFF by
pushing the dial and the volume is controlled by
turning the dial. This dial is used for bass/treble controls when the
“BAS/TRE”
button (8) is in the depressed position. It
is also used for fader/balance controls when the
“BAL/FAD” button (6) is in the depressed position.
Display
Control mode
HB5036BA
Turn counterclockwiseTurn clockwise
BASBass controlFor less bassFor more bass
TRETreble controlFor less trebleFor more treble
BALBalance controlTo increase left speaker volume and decrease right speaker volumeTo increase right speaker volume and decrease left speaker volume
FA dFader controlTo increase rear speaker volume anddecrease front speaker volumeTo increase front speaker volume and decrease rear speaker volume
VOLVolume controlFor less volumeFor more volume

Audio
5-17
– CONTINUED –
Manual tuning (TUNE)
HS5005BA
: Tuning to a higher frequency
: Tuning to a lower frequency
❚: Seeking the next higher station
❚ : Seeking the next lower station
n Manual tuning
Turn the tuning knob (4) clockwise and release it im-
mediately to increase the tuning frequency and turn
the tuning knob counterclockwise and release it im-
mediately to decrease the tuning frequency.
Each time the knob is turned, the frequencychanges 10 kHz in the AM waveband and 0.2 MHzin the FM waveband. n
Seek tuning
Turn the tuning knob (4) and hold it for more than a
half second. Seek tuning will operate and stop auto-
matically on the next station.
Continue this operation until you find the desiredstation.
Automatic tuning (SCAN)
Press the “SCAN” button (3) to change the radio to
the SCAN mode. In this mode, the radio scans
through the radio band until a station is found. Theradio will stop at the station for five seconds while
displaying the frequency, after which scanning will
continue until the entire band has been scanned
from the low end to the high end.
Press the “SCAN” button again to cancel the SCAN
mode and to stop on any displayed frequency.
When the “SCAN” button is pressed for automatic
tuning, stations are scanned in the direction of low
frequencies to high frequencies only.
Automatic tuning may not function properly if the sta-
tion reception is weakened by distance from the sta-
tion or proximity to tall buildings and hills.
Selecting preset stations
Presetting a station with a preset button (5) allowsyou to select that station in a single operation. Up to
six AM, FM1 and FM2 stations each may be preset.

Audio
5-25
– CONTINUED –
nSkipping forward
Turn the “TRACK” knob (24) clockwise and release it
immediately to skip to the beginning of the next
track. Each time the knob is turned and released,
the indicated track number will increase.
n Skipping backward
Turn the “TRACK” knob (24) counterclockwise and
release it immediately to skip to the beginning of the
current track. If you continue to turn and release the
knob, the indicated truck number will decrease.
n Fast forwarding
Turn the “TRACK” knob (24) clockwise and hold it
continuously for more than 2 seconds to fast forwardthe disc.
Release the knob to stop fast forwarding.
n Fast reversing
Turn the “TRACK” knob (24)
counterclockwise and
hold it continuously for more than 2 seconds to fast
reverse the disc.
Release the knob to stop fast reverse.
Repeat playback
Press the “RPT” button (25) while a song is playing
to play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To cancel the repeat mode, press the button again.
Then the
“RPT” indicator goes out, and normal play-
back mode is restored.
Random playback
Press the “RDM” button (23) while a disc is being
played back to play all songs on the disc in a ran-
dom order. The “RDM” indicator will come on and all
songs on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal
playback mode is restored.
Scan
When the “SCAN” button (19) is pressed while the
disc is being played back, you can hear the first 10
seconds of each track to search for the desired pro-
gram. To continue listening to the program, pressthe “SCAN” button again. After all tracks on the disc
have been scanned, normal playback mode is re-
stored.
How to unload CDs from the player
n Ejecting a CD from the player
Of the discs loaded, you can select and removeonly one disc.
1. Press the “DISC SELECT ” button (26) of the disc

Interior equipment
6-5
– CONTINUED –
Storage compartment
CAUTION
Always keep the storage compartment
closed while driving to reduce the risk of inju- ry in the event of sudden stops or an accident. Do not store spray cans, containers with
flammable or corrosive liquids or any otherdangerous items in the storage compartment.
Glove compartment
HS0090
1) Lock 2) Unlock To open the glove compartment, pull the handle. To
close it, push the lid firmly upward.
To lock the glove compartment, insert the key and
turn it clockwise.
Center console
HG6003BA
To open the lid, push the release button.

Starting and operating
7-5
– CONTINUED –
2. Remove the fuel filler cap by turning it slowly
counterclockwise.
WARNING
Gasoline vapor is highly flammable. Before
refueling, always first stop the engine and
make sure that there are no lighted cigarettes,open flames or electrical sparks in the adja-cent area. When opening the cap, do not remove the
cap quickly. Fuel may be under pressure andspray out of the fuel filler neck especially in
hot weather, which may cause injury.
3. Stop filling the tank after the fuel filler pump auto-
matically stops. Do not add any more fuel.
4. Put the cap back on, turn it clockwise until you
hear a clicking noise. Be certain not to catch the
tether under the cap while tightening.
5. Close the fuel filler lid completely.
If you spill any fuel on the painted surface, rinse it
off immediately. Otherwise, the painted surface
could be damaged. NOTE If the fuel filler cap is not tightened until it clicks or if the tether is caught under the cap, the CHECK ENGINE warning light may come on. Re-fer to the
“Warning and indicator lights ” section
located in chapter 3.CAUTION
Never add any cleaning agents to the fuel
tank. The addition of a cleaning agent may
cause damage to the fuel system. Make sure that the cap is tightened until it
clicks to prevent fuel spillage in the event ofan accident. Do not let fuel spill on the exterior surfaces
of the vehicle.Fuels may cause paint damage, which is not
covered under the SUBARU Limited Warranty. Always use a genuine SUBARU fuel filler
cap. If you use the wrong cap, it may not fit orhave proper venting, and your fuel tank and
emission control system might be damaged.
