Keys and doors
2-15
– CONTINUED –
Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The
driver’ s door will unlock, the horn will sound two
times, the parking lights will flash two times and the
indicator light will go off.
To unlock all doors (and the rear gate on the
wagon), briefly press the “UNLOCK/DISARM” button
a second time.
Emergency disarming
If you cannot disarm the system using the transmit-
ter (i.e. the transmitter is lost, broken or the transmit-
ter battery is too weak), you can disarm the system
without using the transmitter.
To disarm the system:
1. Unlock the door with the key and then open the
door.
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from the “LOCK” to the “ON” position three (3) times
within 5 seconds .
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .To deactivate it, press the
“LOCK/ARM” button or
“UNLOCK/DISARM” button.
The parking lights will also flash when the alarm is activated.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds. Valet mode
When you choose the valet mode, the security sys-
tem does not operate. In valet mode, the remotetransmitter is used only for locking and unlocking
the doors (and rear gate on the wagon) and panicactivation.
To enter the valet mode, open the driver ’s door and
keep the “UNLOCK/DISARM” button depressed for
more than two seconds . The indicator light repeat-
edly flashes two times while the system is in valet mode.
To exit valet mode, open the driver ’s door and keep
the “UNLOCK/DISARM” button pressed for more
than two seconds. The indicator will stop flashing.
Passive arming
When passive arming mode has been programmed
by the dealer, arming of the system is automatically
accomplished without using the remote transmitter.

Keys and doors
2-18
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
below or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing. The indicator light provides the following indications.Flashing one time:
Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position.

Keys and doors
2-25
– CONTINUED –
Trunk lid release handle
The trunk lid release handle is a device designed to
open the trunk lid from inside the trunk. In the event
children or adults become locked inside the trunk,the handle allows them to open the lid. The handle islocated on the inside of the trunk lid.
To open the trunk lid from inside the trunk, press the
yellow handle downward as indicated by the arrow on the handle.
HBS070BA
This operation unlocks the trunk lid. Then, push up the lid.
The handle is made of material that remains lumi-
nescent for approximately an hour in the dark trunk
space after it is exposed to ambient light even for a short time.
WARNING
Never allow any child to get in the trunk and
play with the release handle. If the driver starts the vehicle without knowing that a child
is inside the trunk and the child opens the lidusing the release handle, the child could fallout and be killed or seriously injured.
CAUTION

Do not close the lid while gripping the re-
lease handle. The handle may be damaged. Do not use the handle as a hook to fasten
straps or ropes to secure your cargo in the trunk. Such use may result in damage of the handle. Load the trunk so that cargo can not strike
the release handle. If the cargo hits the handlewhile the vehicle is being driven, the handlemay be pushed down and the trunk lid may open. That may cause cargo to fall out of the trunk, which could create a traffic safety haz-ard.

Instruments and controls
3-30
Tilt steering wheel
HB4002BA
1. Adjust the seat position. Refer to the “Front seat ”
section (chapter 1).
2. Pull the tilt lock lever down.
3. Move the steering wheel to the desired level.
4. Push the lever up to lock the steering wheel inplace.
5. Make sure that the steering wheel is securely locked by moving it up and down.
WARNING
Do not adjust the steering wheel tilt position while driving. This may cause loss of vehicle
control and result in personal injury.

Interior equipment
6-11
– CONTINUED –
Floor mat (if equipped)
A retaining pin is located on the drivers side of the
vehicle next to the fuel filler door release.
HB6016BA
The floor mat is secured using the built-in grommet,
by placing the grommet over the pin and pushing
downward.
CAUTION
Make sure the driver ’s floor mat is placed
back in its proper location and correctly se- cured on its retaining pin. If the floor mat slips
forward and interferes with the movement ofthe pedals during driving, it could cause anaccident.
HB6015BA

Interior equipment
6-14
Cargo anchorage eyelets (if equipped)
HG6011BA
The cargo area is equipped with four anchorage
eyelets so that luggage can be secured with a lug-
gage net or ropes.
When using the anchorage eyelets, turn them down
out of the storing recesses. When not in use, put the
eyelets up into the storing recesses.
CAUTION
The cargo anchorage eyelets are designed only for securing light luggage. Never try to secure luggage that exceeds the capacity of the hooks. The maximum load capacity is 44lb (20 kg) per an eyelet.

Driving tips
8-9
– CONTINUED –
aid kit and portable phone or citizens band radio. Drive carefully. Do not take unnecessary risks by
driving in dangerous areas or over rough terrain. Slow down and employ extra caution at all times.
When driving off-road, you will not have the benefit
of marked traffic lanes, banked curves, traffic signs and the like. Do not drive across steep slopes. Instead, drive
either straight up or straight down the slopes. A ve-
hicle can much more easily tip over sideways than it
can end over end. Avoid driving straight up or down
slopes that are too steep. Avoid sharp turning maneuvers, especially at
higher speeds. Do not grip the inside or spokes of the steering
wheel. A bad bump could jerk the wheel and injureyour hands. Instead drive with your fingers andthumbs on the outside of the rim. If driving through water, such as when crossing
shallow streams, first check the depth of the water
and the bottom of the stream bed for firmness and
ensure that the bed of the stream is flat. Drive slowly
and completely through the stream. The water
should be shallow enough that it does not reach the
vehicle’ s undercarriage. Water entering the engine
air intake or the exhaust pipe or water splashing
onto electrical parts may damage your vehicle and may cause it to stall. Never attempt to drive through
rushing water; regardless of its depth, it can wash
away the ground from under your tires, resulting in
possible loss of traction and even vehicle rollover.
Always check your brakes for effectiveness im-
mediately after driving in sand, mud or water. Do
this by driving slowly and stepping on the brake
pedal. Repeat that process several times to dry outthe brake discs and brake pads. Do not drive or park over or near flammable mate-
rials such as dry grass or fallen leaves, as they may
burn easily. The exhaust system is very hot while en- gine is running and right after the engine stops. This
could create a fire hazard. After driving through tall grass, mud, rock, sand,
rivers, etc., check that there is no grass, bush, pa-
per, rags, stones, sand, etc. adhering to or trapped
on the underbody. Clear off any such matter from
the underbody. If the vehicle is used with these ma-
terials trapped or adhering to the underbody, a
mechanical breakdown or fire could occur. Secure all cargo carried inside the vehicle and
make certain that it is not piled higher than the seat-
backs. During sudden stops or jolts, unsecured car-
go could be thrown around in the vehicle and cause
injury. Do not pile heavy loads on the roof. Thoseloads raise the vehicle ’s center of gravity and make

Driving tips
8-16
WARNING
When you carry something inside the ve-
hicle, secure it whenever you can to prevent it from being thrown around inside the vehicleduring sudden stops, sharp turns or in an ac- cident. Do not pile heavy loads on the roof. These
loads raise the vehicle ’s center of gravity and
make it more prone to tip over. Secure skis and other lengthy items proper-
ly to prevent them from shooting forward and
causing serious injury during a sudden stop. Never exceed the maximum load limit. If you
do, some parts on your vehicle can break, or itcan change the way your vehicle handles.This could result in loss of control and cause
personal injury. Also, overloading can shorten the life of your vehicle. Do not place anything on the rear shelf
behind the rear seatback (for sedan) or the ex-
tended luggage cover (for wagon). Such itemscould tumble forward in the event of a suddenstop or a collision. This could cause serious
injury.
CAUTION
Do not carry spray cans, containers with flam- mable or corrosive liquids or any other dan- gerous items inside the vehicle.
NOTE
For better fuel economy, do not carry unneeded cargo. Vehicle capacity weight
HB8015BA
